Frequently Asked Questions

5.1.1 What are the differences between the MVI56 and the MVI56E
modules? What does the "E" stand for?
The "E" stands for Enhanced with Ethernet communication capabilities. The new
enhancements are:
PCB: ProSoft Configuration Builder software; a Windows-based configuration
utility providing a graphical user interface for module diagnostics with screen
navigation, improving interoperability with the module.
Seamless Migration: MVI56E products are backward compatible with
existing ladder logic and module configuration files, allowing for a smooth
transition when upgrading MVI56 products.
Personality Module: The MVI56E incorporates a non-volatile CF (Industrial
Compact Flash) memory card for storing the module's setup and network
configuration data (or personality). This feature benefits the end-user with
quick replacement of modules for disaster recovery. Restore a module by a
simple exchange of the Personality Module with absolutely no PC or
configuration requirements.
Ethernet Configuration port: Allows for remote module connectivity.
Replaces the serial communication port, becoming the primary configuration
port with faster access.
LED Display: The LED provides detailed, plain English diagnostics and error
information for the module, backplane communication, and network
conditions.
Discovery Service: Allows PCB configuration software (or separate utility) to
find and display products located on the network with key product attributes
such as name, serial number, and IP address. The user will be able to
change IP address, upload/download, and enter into diagnostics from the list.
CIPconnect
to local and remote chassis installed MVI56E module(s) through a 1756-
ENxT. Multi hop (Ethernet and ControlNet™) connections are supported.
RSLinx OEM is not required.
Page 62 of 72
®
-enabled: Allows end-users to use PCB from remote locations
