Thermo Scientific 49iQ Instruction Manual

Ozone analyzer
Hide thumbs

Advertisement

Quick Links

Download this manual
49iQ
Instruction Manual
Ozone Analyzer
117433-00 • 1Sep2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the 49iQ and is the answer not in the manual?

Questions and answers

Related Manuals for Thermo Scientific 49iQ

Summary of Contents for Thermo Scientific 49iQ

  • Page 1 49iQ Instruction Manual Ozone Analyzer 117433-00 • 1Sep2019...

  • Page 3: Table Of Contents

    Advanced Data Setup ..............3-29   Data Logging Setup ..............3-30   Select Data Logging Variables ............. 3-31   Streaming Data Setup ..............3-32   Select Streaming Variables ............3-33   Settings ..................... 3-34   Thermo Scientific 49iQ Instruction Manual...
  • Page 4 Chapter 4 Calibration ......................4-1     Equipment Required ................4-1   Zero Air Generator ................4-1   Calibration Photometer System ............4-2   Instrument Preparation ............... 4-3   Calibration Photometer System Preparation ........4-3   49iQ Instruction Manual Thermo Scientific...
  • Page 5 Replacement Parts List ................ 7-3   Fuse Replacement ................7-5   Filter Replacement ................7-6   Fan Replacement ................. 7-7   Measurement Side Removal and Replacing ......... 7-9   LCD Module Replacement ............... 7-12   Thermo Scientific 49iQ Instruction Manual...
  • Page 6 Capillary O-Ring Replacement ............7-24   Power Supply Replacement ............... 7-24   Step POL Board Replacement ............7-26   49iQ Photometer DMC..............7-29   Photometer Lamp Replacement ............. 7-30   Photometer DMC Removal ............7-32   Photometer DMC Board Replacement .......... 7-33  ...
  • Page 7 Quick Reference ....................B-1     List of Figures ..................B-1   List of Tables..................B-3   Appendix C GNU Lesser General Public License ............. C-1     GNU Lesser General Public License ........... C-1   Thermo Scientific 49iQ Instruction Manual...

  • Page 9: Chapter 1 Introduction

    Photometric technology to measure the amount of ozone in the air from ppb levels up to 200 ppm. The 49iQ Analyzer is a dual cell photometer, the concept adopted by NIST for the national ozone standard. Because the instrument has both sample and reference flowing at the same time, a response time of 20 seconds can be achieved.

  • Page 10: Figure 1-1. 49Iq Front

    Introduction iQ Series Instrument Platform control mirrors the same GUI look and feel as the instrument touchscreen providing a speedy and familiar operational experience. Figure 1–1. 49iQ Front 49iQ Instruction Manual Thermo Scientific...

  • Page 11: Principle Of Operation

    I = UV light intensity of sample with ozone (sample gas) = UV light intensity of sample without ozone (reference gas) The sample is drawn into the 49iQ through the sample bulkhead and is split into two gas streams, as shown in Error! Reference source not found..

  • Page 12: Figure 1-2. 49Iq Flow Diagram-No Sample/Cal Valve

    Introduction Principle of Operation Figure 1–2. 49iQ Flow Diagram—No Sample/Cal Valve 49iQ Instruction Manual Thermo Scientific...

  • Page 13: Figure 1-3. 49Iq Flow Diagram-Internal Sample/Cal Valve

    Introduction Principle of Operation Figure 1–3. 49iQ Flow Diagram—Internal Sample/Cal Valve Thermo Scientific 49iQ Instruction Manual...

  • Page 14: Figure 1-4. 49Iq Flow Diagram-Internal Ozonator, Manifold, Sample Cal Valve

    Introduction Principle of Operation Figure 1–4. 49iQ Flow Diagram—Internal Ozonator, Manifold, Sample Cal Valve 49iQ Instruction Manual Thermo Scientific...

  • Page 15: Figure 1-5. 49Iq Flow Diagram-Internal Ozonator, Sample/Cal & Zero/Ozone Valves

    Introduction Principle of Operation Figure 1–5. 49iQ Flow Diagram—Internal Ozonator, Sample/Cal & Zero/Ozone Valves Thermo Scientific 49iQ Instruction Manual...

  • Page 16: Specifications

    Introduction Specifications Specifications Table 1–1 lists the specifications for the 49iQ. Table 1–1. 49iQ Specifications Range 0–200 ppm 0–400 mg/m Zero Noise 0.25 ppb RMS (60 second averaging time) Lower Detectable Limit 0.50 ppb Zero Drift <1.0 ppb (24 hour) <2.0 ppb (7 day)

  • Page 17: Dimensions

    Introduction Dimensions Dimensions Figure 1–6. Bench Mount Assembly (dimensions in inches [mm]) Thermo Scientific 49iQ Instruction Manual...

  • Page 18: Figure 1-7. Rack Mount Assembly (Dimensions In Inches [Mm])

    Introduction Dimensions Figure 1–7. Rack Mount Assembly (dimensions in inches [mm]) 1-10 49iQ Instruction Manual Thermo Scientific...

  • Page 19: Figure 1-8. Rack Mount Requirements

    Introduction Dimensions Figure 1–8. Rack Mount Requirements Figure 1–9. Rack Requirements Part 2 Thermo Scientific 49iQ Instruction Manual 1-11...

  • Page 21: Installation And Setup

    ▲ Unpacking and The 49iQ is shipped complete in one container. If there is obvious damage to the shipping container when you receive the instrument, notify the Inspection carrier immediately and hold for inspection. The carrier is responsible for any damage incurred during shipment.

  • Page 22: Cover Removing And Replacing

    2. Press in both latches located on top cover and hold while pulling up to remove. Set upright. Figure 2–1. Removing the Cover 3. To replace, align cover and drop in. Latches will automatically snap in place. 49iQ Instruction Manual Thermo Scientific...

  • Page 23: Mounting Options

    ● Bench Mount Positioned on bench, includes installing feet. See “Figure 2–2”. Equipment required: Slot drive, 5/16-inch 1. Fasten feet in position 1 or 2 to fit to the desired depth. Figure 2–2. Installing Feet Thermo Scientific 49iQ Instruction Manual...

  • Page 24: Rack Mount

    3. Slide ears outwards. 4. Use the same four 8-32 pan head screws to secure it. 5. Install the handles with the four 8-32 flat head screws that came with the handle kit on the backside as shown. 49iQ Instruction Manual Thermo Scientific...

  • Page 25: Figure 2-4. Installing Ears And Handles

    Installation and Setup Mounting Options Figure 2–4. Installing Ears and Handles Thermo Scientific 49iQ Instruction Manual...

  • Page 26: Setup Procedure

    3-90. 4. Plug the instrument into an outlet of the appropriate voltage and frequency. Icon Here The 49iQ is supplied with a three-wire grounding cord. Under no circumstances should this grounding system be defeated. ▲ 49iQ Instruction Manual...

  • Page 27: Figure 2-5. 49Iq Rear Panel

    Installation and Setup Setup Procedure Figure 2–5. 49iQ Rear Panel Figure 2–6. Atmospheric Dump Bypass Plumbing Thermo Scientific 49iQ Instruction Manual...

  • Page 28: Startup

    For more information about instrument parameters, see the “Operation” chapter. 4. Before beginning the actual monitoring, perform a multipoint calibration as described in the “Calibration” chapter. Figure 2–7. Front Panel and Touchscreen Display 49iQ Instruction Manual Thermo Scientific...

  • Page 29: Chapter 3 Operation

    The Status Bar, located at the bottom, includes the Back button, Access Levels, Health Check, Favorites, Date and Time, and Contact Information. Home Screen (single range mode) Title Bar User Interface Status Bar Thermo Scientific 49iQ Instruction Manual 3-1...
  • Page 30 Operation Instrument Display Home Screen (dual or auto range mode) Title Bar User Interface Status Bar 49iQ Instruction Manual Thermo Scientific...
  • Page 31 The user will be directed to the favorites screen where the user chooses the button position. To remove a favorite button from the favorites screen, press and hold button for 2 seconds. Clock: Displays current date and time. ● Thermo Scientific 49iQ Instruction Manual...
  • Page 32 Operation Instrument Display Thermo Scientific Information button: Shows contact information. ● 49iQ Instruction Manual Thermo Scientific...

  • Page 33: Main Menus And Keypads

     Cycle Time  Compensation  Pressure Calibration Communications Instrument Settings  Display Setup  Alarm Setpoints  Language  Clock  Pump Power  Advanced Instrument  Settings  Reboot Instrument Configuration Security Access Levels USB Drive  Firmware Update Via USB  Drive  Download Data to USB Drive  Change USB Password User Contact Information Update Bootloader Thermo Scientific 49iQ Instruction Manual...

  • Page 34: Numeric Keypad

    Enter a new value using the keypad, and then select the Enter button to set the new value or press the Cancel button to exit the keypad screen and return to the previous screen without saving the value. 49iQ Instruction Manual Thermo Scientific...

  • Page 35: Alphanumeric Keypad

    Cancel button to exit the keypad screen and return to the previous screen without saving the value. The alphanumeric keypad is only available when the user needs to enter alphabet characters. Thermo Scientific 49iQ Instruction Manual...
  • Page 36 Operation Instrument Display 49iQ Instruction Manual Thermo Scientific...

  • Page 37: Calibration

    Home Screen>Calibration (dual or auto range mode) The Calibration menu contains the following information: Calibrate Background: Sets the O reading to zero. ● Calibrate Span Coefficient: Sets the span coefficient when in single ● range mode. Thermo Scientific 49iQ Instruction Manual...
  • Page 38 ● automated zero and span checks or adjustments. Custom O Levels: User sets concentration for O levels and standby. ● Advanced Calibration: Calibrates the instrument using manual ● zero/span calibration and provides calibration history. 3-10 49iQ Instruction Manual Thermo Scientific...

  • Page 39: Calibrate Background

    Calculated Background: Read only. Displays what the current user-set ● background will become when the calibrate button is pressed. Calibrate: When pressed, updates the background value, making the ● concentration go to zero. Thermo Scientific 49iQ Instruction Manual 3-11...

  • Page 40: Calibrate Span Coefficient

    300-second averaging. Screen>Calibration>Calibrate Span Coefficient (single range mode) Home Screen>Calibration>Calibrate Span Coefficient (dual or auto range mode) 3-12 49iQ Instruction Manual Thermo Scientific...
  • Page 41 Range Span Concentration” value is entered, the new calculated low range span coefficient is displayed when in dual or auto range mode. Calibrate: When pressed, updates the coefficient and the concentration ● should match the span concentration. Thermo Scientific 49iQ Instruction Manual 3-13...

  • Page 42: Zero/Span Schedule

    Zero Duration: Sets how long zero air is sampled by the instrument. ●  Ozonator Level 1 6 Duration: Sets the time duration for ozonator level ● 16. Purge Duration: Sets how long the purge period will be at the end of ● the schedule. 3-14 49iQ Instruction Manual Thermo Scientific...
  • Page 43 The zero/span ratio is allowable between 1 to 99. If 99 is chosen, the schedule should only perform the Span on the 99th iteration. Thermo Scientific 49iQ Instruction Manual 3-15...

  • Page 44: Custom O Levels

    Value: Displays the current value for each item. ● Units: Displays units for each item. ● Down: ● Level 1–6: Displays user-defined concentration levels. ● Standby: Turns ozonator lamp to user defined setpoint when in ● zero or sample modes. 3-16 49iQ Instruction Manual Thermo Scientific...

  • Page 45: Advanced Calibration

    Home Screen>Calibration>Advanced Calibration The Advanced screen contains the following information: Manual Calibration: The user manually adjusts the background or span ● coefficient. Calibration History: Lists all calibrations performed and calibration ● checks. Thermo Scientific 49iQ Instruction Manual 3-17...

  • Page 46: Manual Calibration

    The Manual Calibration screen contains the following information: Adjust Background: Allows the user to manually adjust the zero ● background. Adjust Span Coefficient: Allows the user to manually adjust the span ● coefficient when in single range mode. 3-18 49iQ Instruction Manual Thermo Scientific...
  • Page 47 Adjust Low Range Span Coefficient: Allows the user to manually adjust ● the low range span coefficient when in dual or auto range mode. Reset Background to 0.000 and Span Coefficient to 1.000: Resets all ● backgrounds and coefficients. Thermo Scientific 49iQ Instruction Manual 3-19...
  • Page 48 The Adjust Background screen contains the following information: Adjust Background: User manually adjusts zero background. ● Adjusted Concentration: Read only. Shows adjusted concentration based ● on adjusted zero background. Calibrate: Calibrates zero background by saving the newly adjusted ● zero. 3-20 49iQ Instruction Manual Thermo Scientific...
  • Page 49 The Adjust Span Coefficient screen contains the following information: Adjust Span Coefficient: User manually adjusts span coefficient when in ● single range mode. Adjusted Concentration: Read only. Shows adjusted concentration based ● on adjusted span coefficient when in single range mode. Thermo Scientific 49iQ Instruction Manual 3-21...
  • Page 50 Adjusted High Range Concentration: Read only. Shows adjusted low ● range concentration based on adjusted low range span coefficient when in dual or auto range mode. Calibrate: Calibrates span coefficient by saving the newly adjusted span ● coefficient. 3-22 49iQ Instruction Manual Thermo Scientific...

  • Page 51: Calibration History

    Event: Lists the type of calibration event. ● Result: Concentration result. ● Target: Concentration setpoint value. ● Units: Displays units for each item. ● Average Time: Averaging time used during the calibration or calibration ● check. Thermo Scientific 49iQ Instruction Manual 3-23...

  • Page 52: Data

    View Data Log (User Defined Time): User selects the start and end time ● for viewing the data. Table shows most recent data on top. Advanced Data Setup: Allows the user to set up the parameters of how ● the data is stored. 3-24 49iQ Instruction Manual Thermo Scientific...

  • Page 53: View Data Log (Last Hour)

    ▲ The View Data Log (Last Hour) screen contains the following options: Graph: Displays data graph for the column selected. The graph time ● axis is defined by the data set in the table. Thermo Scientific 49iQ Instruction Manual 3-25...

  • Page 54: View Data Log (Last 24 Hours)

    The View Data Log (Last 24 Hours) screen contains the following options: Graph: Displays data graph for the column selected. The graph time ● axis is defined by the data set in the table. 3-26 49iQ Instruction Manual Thermo Scientific...

  • Page 55: View Data Log (User Defined Time)

    Time: Sets time of data logging start time. ● Save Data Logging Start Time: Pressing this button saves the start time ● and follows directly to the end time selection for the data logging screen. Thermo Scientific 49iQ Instruction Manual 3-27...
  • Page 56 Time button saves the end time and follows directly to the data logging table. Note End time should not be greater than 1 year from start time . ▲ Note The datalogging table is limited to 10,000 points. ▲ 3-28 49iQ Instruction Manual Thermo Scientific...

  • Page 57: Advanced Data Setup

    The Advanced Data Setup screen contains the following information: Data Logging Setup: User selects the parameters for collecting logged ● data. Streaming Data Setup: User selects the parameters for streaming data to ● a computer in real time. Thermo Scientific 49iQ Instruction Manual 3-29...

  • Page 58: Data Logging Setup

    When set to minimum or maximum, the minimum or maximum value during the period will be recorded. Erase Data Log Records: Allows the user to erase all values in the data log ● and updates the data logging table. 3-30 49iQ Instruction Manual Thermo Scientific...

  • Page 59: Select Data Logging Variables

    Use the  and  buttons to select the variables. Next, press the Commit Changes button to save selections. Yellow buttons indicate that the variable is selected. More than one can be chosen. Home Screen>Data>Advanced>Data Logging Setup>Select Data Logging Variables Thermo Scientific 49iQ Instruction Manual 3-31...

  • Page 60: Streaming Data Setup

    Show Labels: Toggles enabled/disabled. When enabled, shows variable ● labels to the right of the variable values. Show Timestamp: Toggles enabled/disabled. When enabled, shows ● timestamp at the beginning of each row of data. 3-32 49iQ Instruction Manual Thermo Scientific...

  • Page 61: Select Streaming Variables

    Use the  and  buttons to select the variables. Next, press the Commit Changes button to save selections. Yellow buttons indicate that the variable is selected. More than one can be chosen. Home Screen>Data>Advanced>Streaming Data Setup>Select Streaming Variables Thermo Scientific 49iQ Instruction Manual 3-33...

  • Page 62: Settings

    USB Drive: User can update instrument firmware, download data, and ● change USB password. User Contact Information: User sets up their contact information. ● Update Bootloader: Used to update bootloader when an update to the ● bootloader is available. 3-34 49iQ Instruction Manual Thermo Scientific...

  • Page 63: Health Check

    The iQ360 feature is a paid subscription enabling or disabling ● the instrument to send automated emails to technical support when an alarm or alert is triggered. Firmware Version: Shows the instrument’s firmware version. ● Thermo Scientific 49iQ Instruction Manual 3-35...

  • Page 64: Status And Alarms

    Photometer Bench: Displays photometer bench alarms and faults. ● Ozonator: Displays ozonator alarms and faults. ● Intensity Check: Displays intensity check alarms and faults. ● Pressure Check: Displays pressure check alarms and faults. ● 3-36 49iQ Instruction Manual Thermo Scientific...
  • Page 65 Valve and Pump Resets: User can reset valve and pump power. ● Analog I/O: Displays analog input/output alarms and faults. ● Digital I/O: Displays digital input/output alarms and faults. ● Serial Numbers: Displays all the serial numbers for the instrument. ● Thermo Scientific 49iQ Instruction Manual 3-37...

  • Page 66: Concentration

    Units: Displays units for each item. ● Down: ● concentration. ● Bkg Check Offset: Displays concentration based on the last ● attempted background calibration. High alarm shows user defined limit for acceptable background check offset. 3-38 49iQ Instruction Manual Thermo Scientific...
  • Page 67 (compared to the span concentration value). Span concentration shows span setpoint. Note If both the low alarm and high alarms are set to zero, then no alarm will show. ▲ Thermo Scientific 49iQ Instruction Manual 3-39...
  • Page 68 User can adjust low and high alarm limits. Cell A Concentration: Displays the current concentration in cell A. ● Alarm limits are not changeable. Cell B Concentration: Displays the current concentration in cell B. ● Alarm limits are not changeable. 3-40 49iQ Instruction Manual Thermo Scientific...
  • Page 69 Lamp Power: Displays current lamp power readings. Alarm ● limits are not changeable. 15 Volts: Displays current voltage readings. Alarm limits are not ● changeable. -15 Volts: Displays current voltage readings. Alarm limits are ● not changeable. Thermo Scientific 49iQ Instruction Manual 3-41...
  • Page 70 Operation Settings 24.0 Volts: Displays current voltage readings. Alarm limits are ● not changeable. Note If both the low alarm and high alarms are set to zero, then no alarm will show. ▲ 3-42 49iQ Instruction Manual Thermo Scientific...
  • Page 71 Lamp Temp Sensor Open: Displays the OK/Fail for lamp ● temperature sensor open status. Lamp Current: Displays the current lamp Current reading. ● Lamp Connection: Displays OK/Fail for lamp connection status. ● Lamp Short: Displays OK/Fail for lamp short status. ● Thermo Scientific 49iQ Instruction Manual 3-43...
  • Page 72 24 V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. Note If both the low alarm and high alarms are set to zero, then no alarm will show. ▲ 3-44 49iQ Instruction Manual Thermo Scientific...
  • Page 73 Check>Intensity A Reference Gas The Intensity Check screen contains the following information: Intensity A Reference Gas: Displays reference gas. ● Intensity A Sample Gas: Displays sample gas. ● Intensity B Reference Gas: Displays reference gas. ● Thermo Scientific 49iQ Instruction Manual 3-45...
  • Page 74 Intensity B Sample Gas: Displays sample gas. ● Cell A Reference Gas Intensity: Read only. ● Cell A Reference Gas Noise: Read only. ● Cell B Reference Gas Intensity: Read only. ● Cell B Reference Gas Noise: Read only. ● 3-46 49iQ Instruction Manual Thermo Scientific...
  • Page 75 Sample Pressure: Read only. Displays the pressure of the sample gas in ● Cell B. Reference Pressure: Read only. Displays the pressure of the reference gas ● in Cell B. Pump Pressure: Read only. Is used to test the pump. ● Thermo Scientific 49iQ Instruction Manual 3-47...
  • Page 76 Photometer Pressure: Displays the current photometer pressure ● reading. User can adjust low and high alarm limits. Pump Pressure: Displays the current pump pressure reading. ● Module Temperature: Displays the current instrument temperature ● reading. 3-48 49iQ Instruction Manual Thermo Scientific...
  • Page 77 3.3V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. 5.0V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. 24V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. Thermo Scientific 49iQ Instruction Manual 3-49...
  • Page 78 Sample/Cal Valve: Displays whether or not the sample/cal valve is ● activated. Sample Valve: Displays whether or not the sample valve is activated. ● Reference Valve: Displays whether or not the reference valve is ● activated. 3-50 49iQ Instruction Manual Thermo Scientific...
  • Page 79 24V Step Board 1: Displays current voltage readings. Alarm limits ● are not changeable. 5V Step Board 2: Displays current voltage readings. Alarm limits are ● not changeable. 24V Step Board 2: Displays current voltage readings. Alarm limits ● are not changeable. Thermo Scientific 49iQ Instruction Manual 3-51...
  • Page 80 Sample/Cal Valve Reset: Resets sample/cal valve. ● Sample Valve Reset: Resets sample valve. ● Reference Valve Reset: Resets reference valve. ● Ozonator Solenoid Valve Reset: Resets ozonator solenoid valve. ● Pump Reset: Resets pump. ● 3-52 49iQ Instruction Manual Thermo Scientific...
  • Page 81 Current Output Channel 1–6: Displays real-time current output for ● each channel. Chip Temperatures: Displays OK/Fail for chip temperatures. ● Chip 1–3 Communication: Displays OK/Fail for each chip ● communication. Test Mode: Displays test mode on or off. ● Thermo Scientific 49iQ Instruction Manual 3-53...
  • Page 82 5.0V Ref Diagnostic: Displays current voltage readings. Alarm ● limits are not changeable. 15V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. -15V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. 3-54 49iQ Instruction Manual Thermo Scientific...
  • Page 83 External Alarm 1–3: Displays OK/Fail for external alarms. ● Relay Test Mode: Displays relay test mode on or off. ● Solenoid Test Mode: Displays solenoid test mode on or off. ● Board Communication: Displays OK/Fail for communication status. ● Thermo Scientific 49iQ Instruction Manual 3-55...
  • Page 84 3.3V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. 5.0V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. 24V Diagnostic: Displays current voltage readings. Alarm limits ● are not changeable. 3-56 49iQ Instruction Manual Thermo Scientific...
  • Page 85 Ozonator: Ozonator serial number. ● Flow and Pressure: Flow and pressure serial number. ● Peripherals Support: Peripherals support serial number. ● Analog I/O: Analog I/O serial number. ● Digital I/O: Digital I/O serial number. ● Thermo Scientific 49iQ Instruction Manual 3-57...

  • Page 86: Predictive Diagnostics

    ▲ Home Screen>Settings>Health Check>Predictive Diagnostics The Predictive Diagnostics screen contains the following information: Sample Pump ● Capillary ● Flow Path ● Sample Valve ● Zero Valve ● Span Valve ● 3-58 49iQ Instruction Manual Thermo Scientific...

  • Page 87: Maintenance

    Change Part: User logs component fix. ● Maintenance History: Shows the log of all recorded component fixes. ● Service Tips: Provides video and procedural service tips. ● Advanced Maintenance: Resets all preventive maintenance items. ● Thermo Scientific 49iQ Instruction Manual 3-59...

  • Page 88: Preventive Maintenance

    Reset button and the “Months Left” value resets to the “Interval in Months” value. Alert: Allows the user to opt out of receiving preventive ● maintenance alerts. Displays Enabled/Disabled for each component. Down: ● Photometer DMC: Service interval for photometer module ● components. 3-60 49iQ Instruction Manual Thermo Scientific...
  • Page 89 Fan Filter: Service interval for fan filter. ● System Components: Service interval for system components. ● Purafil: Service interval for purafil. ● Charcoal: Service interval for charcoal. ● Dri-Rite: Service interval for dri-rite. ● Thermo Scientific 49iQ Instruction Manual 3-61...

  • Page 90: Change Part

    Fix: User chooses from new, rebuilt, cleaned, and unknown. ● Comment: User can write a brief comment, which will be saved to the ● preventive maintenance history table. Commit: User commits and saves the selected part fix. ● 3-62 49iQ Instruction Manual Thermo Scientific...

  • Page 91: Maintenance History

    Fix: The type of maintenance. ● Date: Shows date/time when service was logged. ● Service Months: Amount of time in months since last service. ● Comments: Shows comments entered from time of change. ● Thermo Scientific 49iQ Instruction Manual 3-63...

  • Page 92: File Sharing And Support

    Alert Assistant: With the iQ Alert Assistant enabled, the instrument ● will email Thermo Scientific Technical Support the health check report after each event. After each maintenance alert or predictive diagnostic alert, Customer Service will produce a quote for the components that require service.
  • Page 93 Status and Renewal Request: Allows the user to access the iQ360 menu ● once the subscription has been enabled. Cancel and Return to the Home Screen: Exits screen and returns to the ● Home Screen. Thermo Scientific 49iQ Instruction Manual 3-65...
  • Page 94 Enter Subscription Access Code: Allows the user to enter the subscription ● passcode to enable an iQ360 subscription. Exit and Return to the Home Screen: Exits screen and returns to the ● Home Screen. 3-66 49iQ Instruction Manual Thermo Scientific...
  • Page 95 Subscription Expiration Date: Informs the user when the ● subscription will expire. iQ360 Test Connection: Allows the user to verify the network ● connection is working. iQ360 Subscription Renewal: Allows the user to request a subscription ● renewal via email. Thermo Scientific 49iQ Instruction Manual 3-67...

  • Page 96: Measurement Settings

    Range Mode Selection: User can choose between the various range ● modes: single, dual, or auto. For more information, see “Range Mode Selection” on page 3-72 Range Setting: Sets the concentration range for the analog outputs when ● in single range mode. 3-68 49iQ Instruction Manual Thermo Scientific...
  • Page 97 Gas Units: Defines the units in which O concentration reading is ● expressed. Dilution Ratio: Serves as a multiplier when dilution gas is utilized. ● Advanced Measurement Settings: Advanced settings affecting O ● readings. Thermo Scientific 49iQ Instruction Manual 3-69...

  • Page 98: Averaging Time

    At the same time it will preserve the representative nature of the filtered data to the conditions being sampled. Note When Dynamic Filtering is selected, the user selected Averaging Time button is disabled. ▲ Home Screen>Settings>Measurement Settings (single range mode) 3-70 49iQ Instruction Manual Thermo Scientific...
  • Page 99 High Range Averaging Time: Sets high averaging time when in dual or ● auto range mode and when dynamic filtering is disabled. Low Range Averaging Time: Sets low averaging time when in dual or ● auto range mode and when dynamic filtering is disabled. Thermo Scientific 49iQ Instruction Manual 3-71...

  • Page 100: Range Mode Selection

    500 ppb are output based on high range selection. When the low range is active, the range mode selection status output is at 0 volts. When the 3-72 49iQ Instruction Manual Thermo Scientific...
  • Page 101 This is especially necessary if the two ranges are not close to one another. For example, the low O range is set to 0–50 ppb and the high O range is set to 0–20,000 ppb.   Thermo Scientific 49iQ Instruction Manual 3-73...

  • Page 102: Range Setting

    Range Setting or Low Range Setting, brings up a numeric keypad whereby the user can select a range. Settable ranges according to unit selection include: 50200,000 ppb 0.05200 ppm 0.0000050.02 % μg/m 100400,000 μg/m mg/m 0.1400 mg/m 4.0x10 1.0x10 3-74 49iQ Instruction Manual Thermo Scientific...

  • Page 103: Gas Mode

    Sample: Sets the instrument to measure sample gas. ● Zero: Used when calibrating the background of the instrument. When ● pressed, sets the instrument to zero mode.  Level 1 6: Sets the instrument to user-defined concentration levels. ● Thermo Scientific 49iQ Instruction Manual 3-75...

  • Page 104: Gas Units

    The Gas Units screen contains the following information: ppb: parts per billion. ● ppm: parts per million. ● %: percent. ● μg/m3: micrograms per meter cubed. ● mg/m3: milligrams per meter cubed. ● g/m3: grams per meter cubed. ● 3-76 49iQ Instruction Manual Thermo Scientific...

  • Page 105: Advanced Measurement Settings

    Cycle Time: Toggles cycle time to either 4 seconds or 10 seconds. ● Compensation: Allows the user to compensate for changes in ● temperature and pressure concentration. Pressure Calibration: Calibrates pressure. ● Thermo Scientific 49iQ Instruction Manual 3-77...
  • Page 106 Across: ● Description: Defines the actions the user can do. ● Detector Cal: User can manually set or automatically calibrate ● detector 1 and 2. Intensity (Hz): Displays the current intensity in Hz. ● 3-78 49iQ Instruction Manual Thermo Scientific...
  • Page 107 User can stop calibration by pressing the Stop button. End Cal: When Stop is pressed, the auto calibration is interrupted ● and the value does not change. Default Values: When pressed, the default values are saved. ● Thermo Scientific 49iQ Instruction Manual 3-79...
  • Page 108 The Ozonator Lamp Power to Concentration screen contains the following information: Across: ● Description: Lists items in table. ● Lamp Power to Concentration: User can initiate calibration by ● pressing Start, and end calibration prematurely by pressing Stop. 3-80 49iQ Instruction Manual Thermo Scientific...
  • Page 109 Please allow up to 60 minutes for calibration to complete. User can stop calibration by pressing the Stop button. End Cal: When Stop is pressed, the auto calibration is interrupted ● and the value does not change. Thermo Scientific 49iQ Instruction Manual 3-81...
  • Page 110 Standard Temperature for Gas Units: Allows the user to enter a value ● between 0 and 30 °C to correct the g/m , mg/m , and g/m concentration calculations. 3-82 49iQ Instruction Manual Thermo Scientific...
  • Page 111 Under the column labeled reading, the user enters the pressure in mmHg. Under the column labeled Calibration, the user presses the Start button to calibrate the low point of the sensor. Reset all values: Resets values to default. ● Thermo Scientific 49iQ Instruction Manual 3-83...

  • Page 112: Communications

    ID number if two or more of instruments of the same model are connected to one computer. Valid instrument ID numbers are from 0 to 127. The 49iQ has a default instrument ID of 1. Bayern Hessen Settings: User selects the registers (measured values) that ●...
  • Page 113 Operation Settings Note Refer to the “Bayern Hessen Protocol” section in the Communications Manual for a detailed description. ▲ Thermo Scientific 49iQ Instruction Manual 3-85...

  • Page 114: Wired Tcp/Dhcp

    The Wired TCP/DHCP screen contains the following information: DHCP: Toggles DHCP enabled/disabled. ● Dynamic IP Address: Dynamic IP address of the instrument. ● Dynamic Netmask: Dynamic Netmask of instrument. ● Dynamic Gateway: Dynamic Gateway of instrument. ● 3-86 49iQ Instruction Manual Thermo Scientific...
  • Page 115 ● DHCP is disabled. DNS Server Address: DNS IP address of instrument. This is settable ● when DHCP is disabled. Wired MAC Address: Instrument MAC address. ● Host Name: Host name of instrument. ● Thermo Scientific 49iQ Instruction Manual 3-87...
  • Page 116 Bits: User selectable between 7 and 8. ● Parity: User selectable between None, Even, and Odd. ● Stop Bits: User selectable between 1 and 2. ● RS 232/485: User selectable between RS-232 and RS-485. ● 3-88 49iQ Instruction Manual Thermo Scientific...

  • Page 117: Analog I/O

    Analog Out Calibration: Allows the user to calibrate the analog out ● voltage and current to account for varying loads attached to the terminals. Thermo Scientific 49iQ Instruction Manual 3-89...

  • Page 118: Digital I/O

    Digital Out (Relays): Allows the user to view relay outputs. ● Digital Out (Solenoids): Allows the user to view solenoid outputs. ● Advanced Digital I/O: Allows user to test the digital out relays and ● solenoids. 3-90 49iQ Instruction Manual Thermo Scientific...

  • Page 119: Email Server (Smtp)

    From Email Address: The email address that goes in the From field in ● emails. SMTP Server Port: Server port of user’s email server. ● Email Password: Password for SMTP server. ● Email UserName: User name that is authorized to send email through ● SMTP server. Thermo Scientific 49iQ Instruction Manual 3-91...

  • Page 120: Bayern Hessen Settings

    Home Screen>Settings>Communications>Bayern Hessen Settings The Bayern Hessen Settings screen contains the following information: Register 1–8: Sets the measured value logged in the respective register ● location, in response to a valid query (DA) command. 3-92 49iQ Instruction Manual Thermo Scientific...
  • Page 121 Use the  and  buttons to scroll through the registers. Select the variable to log by pressing the corresponding cell. The list is based on the instrument’s configuration. Home Screen>Settings>Communications>Bayern Hessen Settings>Register 1–8 Thermo Scientific 49iQ Instruction Manual 3-93...

  • Page 122: Instrument Settings

    ● Alarm Setpoints: View and set all available alarm setpoints. ● Language: Sets language. ● Clock: Sets date and time. ● Pump Power: Manually enables/disables the pump. ● Reboot Instrument: Reboots the instrument. ● 3-94 49iQ Instruction Manual Thermo Scientific...

  • Page 123: Display Setup

    Power Save: Minutes before screen times out. Toggles enabled/disabled. ● Power Save Setting: Option whereby the user can display a black screen ● after a set amount of inactivity. Brightness: Sets the brightness of the display. ● Thermo Scientific 49iQ Instruction Manual 3-95...

  • Page 124: Alarm Setpoints

    Units: Units for each item (not settable). ● Down: ● concentration alarm. ● Bkg Check Offset: User can set the maximum allowable background ● reading offset for calibration and calibration checks. This is set with the high alarm only. 3-96 49iQ Instruction Manual Thermo Scientific...
  • Page 125 Flow: Flow pressure alarm. ● Cell A Intensity: Cell A intensity alarm. ● Cell B Intensity: Cell B intensity alarm. ● Photometer Lamp Temp: Photometer lamp temperature alarm. ● Photometer Lamp Current: Photometer lamp current alarm. ● Thermo Scientific 49iQ Instruction Manual 3-97...
  • Page 126 Operation Settings Language The Language screen allows the user to choose from the following languages. Home Screen>Settings>Instrument Settings>Language The Language screen contains the following information: English ● Chinese ● Spanish ● 3-98 49iQ Instruction Manual Thermo Scientific...

  • Page 127: Clock

    Time: User sets time. ● Time Zone: User chooses time zone. ● Time Server: User can enable/disable the time server to get periodic ● clock updates. Commit: When pressed, clock settings are saved. ● Thermo Scientific 49iQ Instruction Manual 3-99...
  • Page 128 Operation Settings Date The Date screen allows the user to choose date. Use the  and  buttons to move left and right to select month and year. Home Screen>Settings>Instrument Settings>Clock>Date 3-100 49iQ Instruction Manual Thermo Scientific...
  • Page 129 Use the  and  buttons to select. Home Screen>Settings>Instrument Settings>Clock>Date Format The Date Format screen contains the following information: U.S. Format mm/dd/yyyy ● European Format dd/mm/yyyy ● ISO 8601 yyyy-mm-dd ● Thermo Scientific 49iQ Instruction Manual 3-101...
  • Page 130 The Time screen allows the user to choose from the following formats: mm/dd/yyyy or dd/mm/yyyy. Use the  and  buttons to select. Home Screen>Settings>Instrument Settings>Clock>Time The Time screen contains the following information: Hours ● Minutes ● Seconds ● 3-102 49iQ Instruction Manual Thermo Scientific...

  • Page 131: Time Zone

    ● Mountain Daylight Savings(UTC-6) ● Central Time Zone(UTC-6) ● Central Daylight Savings((UTC-5) ● Eastern Time Zone(UTC-5) ● Eastern Daylight Savings(UTC-4) ● Atlantic Time Zone(UTC-4) ● Mid-Atlantic(UTC-3) ● South Georgia(UTC-2) ● Cape Verde Time(UTC-1) ● Thermo Scientific 49iQ Instruction Manual 3-103...
  • Page 132 ● Gulf Standard Time(UTC+4) ● Yekaterinburg Time(UTC+5 ● Omsk Time(UTC+6) ● Indochina Time(UTC+7) ● ASEAN Common Time(UTC+8) ● Japan Standard Time(UTC+9) ● Chamorro Time Zone(UTC+10) ● Sredmnekolymsk Time(UTC+11) ● New Zealand Standard Time(UTC+12) ● 3-104 49iQ Instruction Manual Thermo Scientific...
  • Page 133 Time Server: Enables/Disables periodic clock updates from an NTP ● (Network Time Protocol) source. Set Time Server: User can choose specific time server. ● Set Default: When pressed, default time server will be used. ● Thermo Scientific 49iQ Instruction Manual 3-105...

  • Page 134: Configuration

    Predictive Diagnostics: Enables predictive diagnostics option. ● Communications Board: Enables RS-232 or RS-485 communication ● board option. Analog I/O: Enables analog I/O option. ● Digital I/O: Enables digital I/O option. ● Instrument Warmup: Enables instrument warm up option. ● 3-106 49iQ Instruction Manual Thermo Scientific...

  • Page 135: Security Access Levels

    Password not needed to change settings to view only access. Change Security Access to Full Access: User can switch to full access ● mode. Password is needed to change settings to full access. Thermo Scientific 49iQ Instruction Manual 3-107...
  • Page 136 Operation Settings Change Full Access Security Password: Full access password can have a ● blank value or user selected password. 3-108 49iQ Instruction Manual Thermo Scientific...

  • Page 137: Change Security To View Only Access

    Cancel: Exit screen. ● Note To change security access from view only access to full access, a keypad will be displayed where the user can enter full access password. ▲ Thermo Scientific 49iQ Instruction Manual 3-109...

  • Page 138: Change Full Access Security Password

    The Change Full Access Security Password screen allows the user to set a new password for allowing full access. Security Password Home Screen>Settings>Security Access Levels>Change Full Access Security Password Home Screen>Settings>Security Access Levels>Change Full Access > Security Password Continue 3-110 49iQ Instruction Manual Thermo Scientific...
  • Page 139 Commit New Security Access Password Change: Commits new security ● password. Cancel and Return to the Home Screen: Exits screen and returns to the ● Home Screen without changing password. Thermo Scientific 49iQ Instruction Manual 3-111...

  • Page 140: Usb Drive

    Firmware Update Via USB Drive: If USB is mounted, user can update ● instrument firmware. Download Data To USB Drive: User can download/upload ● information. Change USB Password: User can change the USB password. ● 3-112 49iQ Instruction Manual Thermo Scientific...

  • Page 141: Firmware Update Via Usb Drive

    The Firmware Update Via USB Drive screen contains the following information: Update Firmware: User chooses firmware file from USB and updates ● instrument firmware. Instrument reboots when update is finished. Exit: User exits without updating firmware. ● Thermo Scientific 49iQ Instruction Manual 3-113...

  • Page 142: Download Data To Usb Drive

    USB to the instrument. Restore: Allows the user to upload the configuration files from the USB ● to the instrument. Download All Data: Downloads all reports, logs, histories, and backup ● information. 3-114 49iQ Instruction Manual Thermo Scientific...
  • Page 143 If a USB password has been previously set, you will be prompted to enter the USB password to continue. Press Enter to continue. 2. To continue, select the OK button. 3. The USB Drive will display. Select Download Data To USB Drive. Thermo Scientific 49iQ Instruction Manual 3-115...
  • Page 144 “Success!” message and display the file name as it is stored on the USB flash drive. (The file name format is the instrument serial number, name of download, followed by a date/time stamp.) Remove the USB flash drive and select the OK button to continue. 3-116 49iQ Instruction Manual Thermo Scientific...

  • Page 145: Change Usb Password

    Settings Change USB Password The Change USB Password screen allows the user to set a new password for accessing USB. Home Screen>Settings>USB Drive>Change USB Password Home Screen>Settings>Security Access Levels>Change Standard Access > Password Continue Thermo Scientific 49iQ Instruction Manual 3-117...
  • Page 146 ● password for spelling confirmation. Commit New USB Password Change: Commits new USB password. ● Cancel and Return to the Home Screen: Exits screen and returns to the ● Home Screen without changing password. 3-118 49iQ Instruction Manual Thermo Scientific...

  • Page 147: User Contact Information

    ● Business Address ● Business Shipping Address ● To: User Email Address ● CC: User Email Address 110 ● User Phone Number ● Alternate User Phone Number ● Shelter / Lab Phone Number ● Thermo Scientific 49iQ Instruction Manual 3-119...

  • Page 148: Update Bootloader

    If button is greyed out, no update is needed. Home Screen>Settings>Update Bootloader The Update Bootloader screen contains the following information: Reboot and Update: Update bootloader and reboot instrument. ● Exit: Exits screen. ● 3-120 49iQ Instruction Manual Thermo Scientific...

  • Page 149: Chapter 4 Calibration

    2. Pass air through a large column of activated charcoal to remove residual nitrogen dioxide, ozone, sulfur dioxide, hydrocarbons, and so on. 3. Pass air through a molecular sieve. 4. Pass air through a final particulate filter to remove particulates which originate in scrubbing columns. Thermo Scientific 49iQ Instruction Manual 4-1...

  • Page 150: Calibration Photometer System

    The Thermo Scientific 49iQ Ozone Photometric Primary Standard satisfies the calibration photometer system requirement in a single convenient package. In addition, the 49iQ can be modified to operate as a calibration photometer by removing the ozone scrubber and plumbing zero...

  • Page 151: Instrument Preparation

    2. Allow the instrument to stabilize for a minimum of one hour. 3. Perform the service checks in the “Maintenance” chapter. 4. Connect the 49iQ to the ozone manifold. If a PTFE particulate filter is being used, it must be installed prior to calibration.
  • Page 152 Cell B. From the Home Screen, press Settings>Health Check>Status and Alarms>Intensity Check. From the Intensity Check menu, press Intensity A Reference Gas. Wait for a steady reading and record the intensity as R(b) 49iQ Instruction Manual Thermo Scientific...

  • Page 153: Linearity Check

    Linearity Check Since the 49iQ is inherently linear over the range of interest (0-1 ppm), a linearity test is an effective overall test that the instrument is operating properly. The checks above should identify whether any causes of non- linearity are present.
  • Page 154 = Assay of original concentration = Assay of diluted concentration R = Dilution ratio Note The inherent linearity accuracy of the 49iQ Primary Standard (or a 49iQ modified as described earlier) is greater than the accuracy measurements of the mass flow meters.

  • Page 155: Intercomparability Test

    4. Connect PTFE line from bulkhead labeled OZONE to manifold of ozone source being utilized for intercomparability study. 5. Make sure the same zero air is feeding both the 49iQ Primary Standard and the second photometer being used in study.

  • Page 156: Calibration Procedure

    ● Connect the Instrument Connect the 49iQ to the manifold on the output of the ozonator, as shown Figure 4–2. If an optional sample line filter is used, the calibration must be performed through this filter.

  • Page 157: Zero Adjust

    (URL) of the ozone analyzer (such as, 0.4 or 0.8 ppm for the 0.5 and 1.0 ppm ranges respectively). 2. Allow the instrument to sample this ozone concentration standard until a stable response is obtained. 3. From the Home Screen, choose Calibration>Calibrate Span Coefficient. Thermo Scientific 49iQ Instruction Manual...
  • Page 158 Calibrate button to calibrate the O reading to the O calibration gas. 5. Record the ozone concentration as determined by the calibration photometer and the corresponding analyzer response. 4-10 49iQ Instruction Manual Thermo Scientific...

  • Page 159: Additional Concentration Standards

    If a 49iQ Primary Standard is being used as the calibration photometer, use the ozone concentration as determined by the photometer and not the value of the ozone level number.

  • Page 160: Periodic Zero And Span Checks

    ±6% of fullscale is an indication of a malfunction either of the zero air supply, ozone source, recorder, or analyzer. Since the 49iQ is a ratio instrument and thus does not have an electronic span or zero drift, it is not recommended that any zero adjustment or span adjustment be performed as the result of a zero or span check.
  • Page 161 ±4% for zero and ±6% for span drift, the multipoint calibration above is indicated to isolate the problem. For detailed guidance in setting up a quality assurance program, refer to the Code of Federal Regulations and the EPA Handbook on Quality Assurance. Thermo Scientific 49iQ Instruction Manual 4-13...

  • Page 162: Internal Ozonator Adjustment

    The transfer standard or primary sample will be used to read the O generated by the internal ozonator. Figure 4–3. Ozonator Flow Scheme 2. From the Home Screen, press Calibration>Custom O Levels. 3. Adjust Level 1 for the desired level (typically 80% URL). 4-14 49iQ Instruction Manual Thermo Scientific...
  • Page 163 = Recorder response with precision level, % scale Z = Recorder response with zero air, % scale URL = Upper range limit Note The expected stability of the instrument section is greater then the expected stability of the internal ozonator. ▲ Thermo Scientific 49iQ Instruction Manual 4-15...

  • Page 164: Manual Calibration

    Adjusted Concentration shows what the new O concentration would be based on the changed zero background. Press the Calibrate button to save the adjusted zero background value. 4-16 49iQ Instruction Manual Thermo Scientific...

  • Page 165: Adjust Span Coefficient

    Calibration>Adjust Span Coefficient Reset Bkg to 0.000 The Reset Bkg to 0.000 and Span Coef to 1.000 screen allows the user to reset the calibration configuration values to factory defaults. and Span Coef to 1.000 Thermo Scientific 49iQ Instruction Manual 4-17...

  • Page 166: Zero/Span Schedule

    The Span (Ozonator Level 16) and Purge Duration buttons Duration Minutes look and function the same way as the zero duration button. The span duration buttons are used to set how long the span gas is sampled by the 4-18 49iQ Instruction Manual Thermo Scientific...

  • Page 167: Schedule Averaging Time

    Section 12 also provides information on “Calibration of Primary and Secondary Standards for Flow Measurements”. Specific information on certification of concentration standards is given in EPA Traceability Protocol for Assay and Certification of Gaseous Calibration Standards, available at www.epa.gov. Thermo Scientific 49iQ Instruction Manual 4-19...

  • Page 169: Chapter 5 Maintenance

    2. Flush the filter with warm water and let dry (a clean, oil-free purge will help the drying process) or blow the filter clean with compressed air. 3. Re-install the filter and fan guard. Thermo Scientific 49iQ Instruction Manual 5-1...

  • Page 170: Pump Rebuilding

    4. Lift the head plate and the intermediate plate off the housing. 5. Hold the pump with one hand, so that the diaphragm is pointing downwards. Lift the diaphragm by the opposing side edges, grasp it and unscrew it in the counter-clockwise direction. 49iQ Instruction Manual Thermo Scientific...
  • Page 171 12. Place the head plate on the intermediate plate, in the position indicated by the drawing line; gently tighten the four screws, evenly and diagonally (if a torque screwdriver is available: torque about 0.30 Nm). 13. Let the pump run. Thermo Scientific 49iQ Instruction Manual...

  • Page 172: Figure 5-2. Pump Rebuilding

    Maintenance Pump Rebuilding Figure 5–2. Pump Rebuilding 49iQ Instruction Manual Thermo Scientific...

  • Page 173: Leak Test

    4. Squeeze trigger until gauge reads to pull in 10 in Hg. 5. Observe vacuum gauge for stable reading for 5 minutes. If reading remains at 10 in Hg, no leak is present. Note Acceptable leak rate is .5 in Hg over 10 minutes. ▲ Thermo Scientific 49iQ Instruction Manual...

  • Page 174: Optical Bench Cleaning

    Use the following procedure to clean the mirrors. Cleaning Equipment required: Hex drive, 7/64 1. Unfasten nuts with hands. No tool required. Figure 5–3. Absorption Cleaning Removing Nuts 2. Pull up then pull out the absorption tube. Figure 5–4. Absorption Tube Removal 49iQ Instruction Manual Thermo Scientific...

  • Page 175: Figure 5-5. Absorption Cleaning Pt 3 Clean Tube

    Note Both absorption tubes are identical, so they can be replaced in either position. Replacement of absorption cells is opposite to that of removal. Since the 49iQ is a ratio instrument, and cleaning the absorption tubes does not affect the calibration, it is not necessary to recalibrate the instrument every time the cells are cleaned.

  • Page 176: Figure 5-7. Absorption Cleaning Pt 5 Full Window Clean Option

    It is recommended that the instrument be recalibrated if the optical bench has been completely disassembled. Always leak check the system after any component removal. ▲ Figure 5–7. Absorption cleaning pt 5 full window clean option 49iQ Instruction Manual Thermo Scientific...

  • Page 177: Chapter 6 Troubleshooting

    Guide experience an instrument problem. It also lists 49iQ specific troubleshooting information and alarm messages you may see on the graphics display and provides recommendations about how to resolve the alarm condition.
  • Page 178 Low: Excessive low Check external temperature (must be temperature in instrument, above 0 °C); check heater connection ineffective or disconnected for disconnect or crimps. heater, duty cycle temperature at 100% 49iQ Instruction Manual Thermo Scientific...
  • Page 179 One cell excessively Clean cell. contaminated Defective detector Interchange detectors at photometer DMC PCB connectors to determine if detector is defective. Cell A and B Dirty cells Clean cells. frequency low or zero Light adjustment Thermo Scientific 49iQ Instruction Manual...
  • Page 180 Replace ozonator, lamp driver board temp or lamp assembly. Alarm –Lamp temp Defective lamp heater Replace bench lamp driver board or lamp assembly. Alarm – Flow Flow low Check sample capillary for blockage. Replace as necessary. 49iQ Instruction Manual Thermo Scientific...
  • Page 181 (Photometer) Alarm – Lamp Defective lamp Replace lamp as needed. Connection (Photometer) Alarm – Lamp Short Defective lamp Replace lamp as needed. (Photometer) Alarm – Lamp Heater Defective heater Replace heater as needed. Current (Ozone) Thermo Scientific 49iQ Instruction Manual...
  • Page 182 Defective lamp Replace lamp as needed. Connection (Ozone) Defective DMC board Replace DMC board as needed. Alarm – Lamp Short Defective lamp Replace lamp as needed. (Ozone) Reseat if needed. Defective DMC PCB Replace DMC board. 49iQ Instruction Manual Thermo Scientific...

  • Page 183: Chapter 7 Servicing

    Chapter 7 Servicing This chapter describes the periodic servicing procedures that should be performed on the instrument to ensure proper operation and explains how to replace the 49iQ subassemblies. Safety Read the safety precautions before beginning any procedures in this chapter.

  • Page 184: Figure 7-1. Properly Grounded Antistatic Wrist Strap

    When the instrument is unplugged, the chassis is not at earth ground. ▲ Figure 7–1. Properly Grounded Antistatic Wrist Strap Note Ground to unpainted case or outlet as shown. ▲ 49iQ Instruction Manual Thermo Scientific...

  • Page 185: Firmware Updates

    Firmware” in the iQ Series Communications manual. Replacement For a complete list of spare parts, visit the company website at: Parts List www.thermofisher.com/49iQ Refer to Figure 7–2 and Figure 7–3 to identify the component location. Thermo Scientific 49iQ Instruction Manual...

  • Page 186: Figure 7-2. 49Iq Component Layout Top View

    Servicing Replacement Parts List Figure 7–2. 49iQ Component Layout Top View Figure 7–3. 49iQ Component Layout Side View 49iQ Instruction Manual Thermo Scientific...

  • Page 187: Fuse Replacement

    1. Turn instrument OFF and unplug the power cord. 2. Remove fuse drawer, located on the AC power connector. 3. If either fuse is blown, replace both fuses. 4. Insert fuse drawer and reconnect power cord. Figure 7–4. Replacing the Fuses Thermo Scientific 49iQ Instruction Manual...

  • Page 188: Filter Replacement

    2. Starting with top right corner, pull out to remove fan cover. Figure 7–5. Start with Top Right Corner of Fan Cover 3. Replace filter and snap fan cover back in place. Figure 7–6. Removing the Fan Cover 49iQ Instruction Manual Thermo Scientific...

  • Page 189: Fan Replacement

    3. Starting with top right corner, pull out to remove fan cover. 4. Unhook the four latches of the fan cover. 5. Unfasten the four 6-32 screws from the fan housing. 6. Replace fan and reassemble in reverse order. Thermo Scientific 49iQ Instruction Manual...

  • Page 190: Figure 7-8. Replacing The Fan

    Servicing Fan Replacement Figure 7–8. Replacing the Fan 49iQ Instruction Manual Thermo Scientific...

  • Page 191: Measurement Side Removal And Replacing

    Phillips drive, #2 1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Unplug the fan cable J18 (Figure 7–9). Figure 7–9. Unplugging the Fan Cable 3. Unplug DMC cable (Figure 7–10). Thermo Scientific 49iQ Instruction Manual...

  • Page 192: Figure 7-10. Unplugging The Dmc Cable

    Figure 7–10. Unplugging the DMC Cable 4. Gripping from the top corners of the front panel and pull outwards. 5. Remove three 8-32 flat head screws (Figure 7–11). Figure 7–11. Unfasten Hardware Front for Measurement Side Removal 7-10 49iQ Instruction Manual Thermo Scientific...

  • Page 193: Figure 7-12. Unfasten Hardware Rear For Measurement Side Removal

    6. Swing arm open. 7. Unfasten captive hardware. 8. Remove two 8-32 flat head screws. 9. Pull measurement side out. 10. Replace in reverse order. Figure 7–12. Unfasten Hardware Rear for Measurement Side Removal Thermo Scientific 49iQ Instruction Manual 7-11...

  • Page 194: Lcd Module Replacement

    2. Gripping from the top corners of the front panel and pull outwards. 3. Unfasten four nuts (Figure 7–13). Figure 7–13. Replacing the LCD Module 4. Remove cover. 5. Unplug LCD cables from backside of board. 6. Pull board off the standoffs. 7-12 49iQ Instruction Manual Thermo Scientific...

  • Page 195: Figure 7-14. Remove Electrical Cables From Lcd

    Servicing LCD Module Replacement Figure 7–14. Remove Electrical Cables from LCD 7. Replace LCD module and reassemble in reverse order. Thermo Scientific 49iQ Instruction Manual 7-13...

  • Page 196: I/O Replacement

    Use the following procedure to replace the I/O boards. 1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Swing arm open. Figure 7–15. I/O Replacement, Arm 3. Pull board upwards. Figure 7–16. I/O Replacement, Remove Board 7-14 49iQ Instruction Manual Thermo Scientific...

  • Page 197: Figure 7-17. I/O Replacement, Install

    4. During install, make sure to align cutout circular to keyway. 5. Insert board downwards. Figure 7–17. I/O Replacement, Install 6. Close arm. Make sure expansion bracket aligns to the inside of the rectangular cutouts. Figure 7–18. I/O Replacement, Close Arm Alignment Thermo Scientific 49iQ Instruction Manual 7-15...

  • Page 198: Peripherals Support Board And System Controller Board Replacement

    1. Turn instrument OFF, unplug power cord, and remove the cover Controller Board (Figure 2–1). Replacement 2. Pull tab out (two per board). 3. Pull board out. Figure 7–19. Replacing the Peripheral Support board 4. Replace board and reassemble in reverse order. 7-16 49iQ Instruction Manual Thermo Scientific...

  • Page 199: Dmc Pressure And Flow Board

    (Figure 2–1). 2. Unplug cables from the pressure and flow board. Figure 7–20. Flow Pressure Board, Disconnect DMC Cable 3. Disconnect plumbing. 4. Using 7/16 hex drive, unfasten four #6-32 socket cap head screws. Thermo Scientific 49iQ Instruction Manual 7-17...

  • Page 200: Figure 7-21. Flow Pressure Board, Screws

    Servicing DMC Pressure and Flow Board Figure 7–21. Flow Pressure Board, Screws 5. Replace board and reassemble in reverse order. 7-18 49iQ Instruction Manual Thermo Scientific...

  • Page 201: Pump Replacement

    3. Twist opposite direction to unlock tube clamps. Note Push in tube clamp to lock. ▲ 4. Disconnect tubing from pump. 5. Unfasten two captive hardware. 6. Slide pump left until keyway meets opening. Thermo Scientific 49iQ Instruction Manual 7-19...

  • Page 202: Figure 7-22. Remove Pump, Disconnect And Unfasten

    Servicing Pump Replacement Figure 7–22. Remove Pump, Disconnect and Unfasten 7. Pull pump outwards. Note When installing pump, make sure the pump keyway opening goes over the keyway. ▲ 7-20 49iQ Instruction Manual Thermo Scientific...

  • Page 203: Figure 7-23. Pump Removal, Keyway

    Servicing Pump Replacement Figure 7–23. Pump Removal, Keyway 8. Remove two screws. Figure 7–24. Pump replacing, Unfasten Screws 9. Replace pump and reassemble in reverse order. Thermo Scientific 49iQ Instruction Manual 7-21...

  • Page 204: Capillary Cleaning And Or Replacement

    1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Disconnect the plumbing. 3. Using #2 Phillips drive, unfasten captive hardware. Figure 7–25. Remove Capillary, Disconnect and Unfasten 4. Slide capillary plate upwards clearing the partition panel keyway. 7-22 49iQ Instruction Manual Thermo Scientific...

  • Page 205: Figure 7-26. Capillary Plate, Keyway

    Capillary Cleaning and or Replacement Figure 7–26. Capillary Plate, Keyway 5. Using 7/64 hex drive, remove four #6-32 socket cap head screws. 6. Pull apart the capillary blocks. Figure 7–27. Capillary and O-Ring Replace Thermo Scientific 49iQ Instruction Manual 7-23...

  • Page 206: Capillary O-Ring Replacement

    1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Unplug all electrical shown J9, J10, J24, J25, J26, and ground. 3. Unfasten captive hardware. 4. Slide power supply left clearing three case floor plate keyways. 7-24 49iQ Instruction Manual Thermo Scientific...

  • Page 207: Figure 7-28. Removing Power Supply

    Servicing Power Supply Replacement Figure 7–28. Removing Power Supply 5. Pull power supply up. 6. Replace power supply and reassemble in reverse order. Figure 7–29. Replacing Power Supply Thermo Scientific 49iQ Instruction Manual 7-25...

  • Page 208: Step Pol Board Replacement

    1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Unplug Step POL power cable J4. 3. Unplug Step POL signal cable J2. 4. Unplug pump cable J7. 5. Unfasten captive hardware. Figure 7–30. Unplug and Unfasten Step POL Board 7-26 49iQ Instruction Manual Thermo Scientific...

  • Page 209: Figure 7-31. Clear Partition Keyway Step Pol Board

    7–32). If replacing optional step board 2, make sure switch 1 is pointed towards ON and switch 2 is pointed away from ON (Figure 7–33). 8. Replace Step POL board and reassemble in reverse order. Thermo Scientific 49iQ Instruction Manual 7-27...

  • Page 210: Figure 7-32. Step Pol Board 1 Switch Settings

    Servicing Step POL Board Replacement Figure 7–32. Step POL Board 1 Switch Settings Figure 7–33. Optional Step POL Board 2 Switch Settings 7-28 49iQ Instruction Manual Thermo Scientific...

  • Page 211: 49Iq Photometer Dmc

    Servicing 49iQ Photometer DMC 49iQ Photometer Use the following procedure to service the Photometer DMC and replace the following as necessary: Photometer lamp replacement ● Photometer DMC removal ● Photometer DMC board replacement ● Detector replacement ● Detector board replacement ●...

  • Page 212: Photometer Lamp Replacement

    Servicing 49iQ Photometer DMC Photometer Lamp Use the following procedure to remove and replace the photometer lamp. Replacement Equipment required: Hex drive, 3/32 1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Disconnect lamp connector.
  • Page 213 Servicing 49iQ Photometer DMC 5. Peel insulation back enough to unfasten this screw. 6. Using a 3/32 hex drive, unfasten the #6-32 cap head screw. Figure 7–37. Lamp Removal pt 3 7. Rebuild/install assembly in reverse order. Thermo Scientific 49iQ Instruction Manual...

  • Page 214: Photometer Dmc Removal

    Servicing 49iQ Photometer DMC Photometer DMC Use the following procedure to remove the Photometer DMC and replace the board. Removal Equipment required: Phillips drive, #2 1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Unplug DMC cable, top connector (photometer DMC board to pressure/flow board).

  • Page 215: Photometer Dmc Board Replacement

    Servicing 49iQ Photometer DMC Photometer DMC Use the following procedure to replace the board. Board Replacement Equipment required: Phillips drive, #2 1. Unplug electrical, detector 1, detector 2, thermistor, and heater. 2. Using a #2 Phillips drive, unfasten five 6-32 pan head screws.

  • Page 216: Detector Assembly Replacement

    Servicing 49iQ Photometer DMC Detector Assembly Use the following procedure to remove the pre-amplifier/detector assembly. Replacement Equipment required: Hex drive, 7/64 1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Unplug electrical cable from detector 1 and detector 2.

  • Page 217: Figure 7-41. Replacing The Detector

    Servicing 49iQ Photometer DMC Figure 7–41. Replacing the Detector 4. Replace detector and reassemble in reverse order. Thermo Scientific 49iQ Instruction Manual 7-35...

  • Page 218: Detector Board Replacement

    Servicing 49iQ Photometer DMC Detector Board Use the following procedure to replace the detector board. Replacement Equipment required: Hex drive, 3/32 1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Unplug electrical cable from detector 1 and detector 2.

  • Page 219: Thermistor Replacement

    Servicing 49iQ Photometer DMC Thermistor Use the following procedure to replace the thermistor. Replacement Equipment required: Wrench 1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Unplug the thermistor from the photometer DMC board. 3. Using a wrench, unfasten 1/4 hex nut.

  • Page 220: Scrubber Replacement

    2. Remove temporary shipping nylon tie. 3. Twist opposite direction to unlock tube clamps. Note Push in tube clamp to lock. ▲ 4. Disconnect 2X plumbing. 5. Pull scrubber out. Figure 7–44. Replacing the Scrubber 7-38 49iQ Instruction Manual Thermo Scientific...

  • Page 221: Solenoid Replacement

    (J6), and optional solenoid valve sam/cal (J5). 3. Disconnect 2X plumbing. 4. Using a #2 Phillips drive, unfasten four captive hardware and pull out the solenoid tray. 5. Pull solenoid tray outwards. Figure 7–45. Removing the Solenoid Tray pt 1 Thermo Scientific 49iQ Instruction Manual 7-39...

  • Page 222: Figure 7-46. Removing The Solenoid Tray Pt 2

    Servicing Solenoid Replacement 6. Turn assembly upside down. 7. Unfasten kep nuts (two per valve). Figure 7–46. Removing the Solenoid Tray pt 2 8. Replace solenoids and reassembly in reverse order. 7-40 49iQ Instruction Manual Thermo Scientific...

  • Page 223: Optional Dmc Ozonator

    1. Turn instrument OFF, unplug power cord, and remove the cover (Figure 2–1). 2. Unplug electrical, unplug DMC cable to ozonator board DMC (J4). 3. Disconnect 2X plumbing. 4. Using a #2 Phillips drive, unfasten captive hardware. Thermo Scientific 49iQ Instruction Manual 7-41...
  • Page 224 Servicing Optional DMC Ozonator Figure 7–47. Ozone remove pt 1 5. Slide ozonator assembly left. Note Make sure ozonator plate clears the edge and stud. ▲ Figure 7–48. Ozone remove pt 2 7-42 49iQ Instruction Manual Thermo Scientific...
  • Page 225 Optional DMC Ozonator 6. Slide ozonator assembly upwards. Note Make sure ozonator plate clears the edge. ▲ Figure 7–49. Ozone remove pt 3 7. Pull away from the partition panel. Figure 7–50. Ozone remove pt 4 Thermo Scientific 49iQ Instruction Manual 7-43...

  • Page 226: Lamp Replacement

    Removal” on page 7-41. 2. Using a 3/32 ball-end hex drive (angle alignment of screws), unfasten two #4-40 cap screws. 3. Pull lamp out. Figure 7–51. Replacing the Lamp 4. Replace lamp and reassemble in reverse order. 7-44 49iQ Instruction Manual Thermo Scientific...

  • Page 227: Ozonator Dmc Board Replacement

    2. Unplug heater and lamp cable. 3. Using a #2 Phillips drive, unfasten five #6-32 pan head screws. Figure 7–52. Replacing the Ozonator DMC Board 4. Replace ozonator DMC board and reassemble in reverse order. Thermo Scientific 49iQ Instruction Manual 7-45...

  • Page 228: Ozonator Replacement

    “DMC Ozonator Removal” on page 7-41. 2. Unplug heater and lamp cable. Figure 7–53. Ozonator replace pt 1 3. Using a #2 Phillips drive, unfasten three #6-32 flat head screws. 4. Pull out ozonator 7-46 49iQ Instruction Manual Thermo Scientific...

  • Page 229: Figure 7-54. Replacing The Ozonator

    Servicing Optional DMC Ozonator Figure 7–54. Replacing the Ozonator 5. Replace ozonator and reassemble in reverse order. Thermo Scientific 49iQ Instruction Manual 7-47...

  • Page 230: Ozonator Dmc Install

    2. Slide ozonator assembly right. Note Make sure ozonator plate fits under the stud. ▲ Note Make sure ozonator plate slides into side pocket. ▲ 3. Using a #2 Phillips drive, fasten captive hardware. 7-48 49iQ Instruction Manual Thermo Scientific...
  • Page 231 Servicing Optional DMC Ozonator Figure 7–56. Ozone DMC install pt 2 Thermo Scientific 49iQ Instruction Manual 7-49...

  • Page 232: Optional Pressure Regulator Replacement

    Figure 7–57. Pressure Regulator Note Make sure regulator notch is in the bracket slot before fastening regulator nut. This will prevent the pressure regulator from rotating. ▲ 5. Replace pressure regulator and reassemble in reverse order. 7-50 49iQ Instruction Manual Thermo Scientific...

  • Page 233: Optional Manifold Replacement

    2. Using a wrench, unfasten three nuts. Remove the nuts, front and back ferrules as shown from back panel (Figure 7–58). Figure 7–58. Replacing the Manifold pt 1 3. Disconnect tubing. 4. Using a #2 Phillips drive, unfasten four #8-32 socket cap head screws. Thermo Scientific 49iQ Instruction Manual 7-51...
  • Page 234 Servicing Optional Manifold Replacement Figure 7–59. Replacing the Manifold pt 3 5. Replace the manifold and assemble in reverse order. 7-52 49iQ Instruction Manual Thermo Scientific...

  • Page 235: Chapter 8 System Description

    Chapter 8 System Description The 49iQ deploys a set of modular subsystems that comprise the total instrument function. The core measurements for concentration are contained in Distributed Measurement and Control (DMC) modules. This chapter describes the function and location of the system components in the module framework, including firmware, electronics, and I/O function.
  • Page 236 Supply Common The common electronics contain the core computational and power routing hardware for the 49iQ, and is replicated throughout other iQ series Electronics products (Figure 8–1). It also contains front panel display, the USB ports, the Ethernet port, and the optional I/O interfaces (RS-485, analog, and digital).

  • Page 237: Figure 8-1. Common System Interconnect Diagram

    System Description Common Electronics Figure 8–1. Common System Interconnect Diagram Thermo Scientific 49iQ Instruction Manual...

  • Page 238: Figure 8-2. 49Iq System Interconnect Diagram

    System Description Common Electronics Figure 8–2. 49iQ System Interconnect Diagram 49iQ Instruction Manual Thermo Scientific...

  • Page 239: Power Supply

    All electronics operate from a universal VDC supply, which is capable of auto-sensing the input voltage and working over all specified operating ranges. The 49iQ contains a 24 VDC channel for most electronics operation, including the pump and fan, and a 48 VDC channel dedicated specifically for optical bench heating.

  • Page 240: Peripherals Support System

    Firmware Like the hardware, the firmware is modular and located within microprocessors distributed throughout the instrument. In the 49iQ, microprocessors containing firmware are located as follows: Photometer DMC ●...
  • Page 241 SNMP registers, some of which is interfaced with the front panel Graphical User Interface (GUI). In addition to the operating registers, the 49iQ stores a historical data log in a MySQL database. The memory is provided on the same micro SD card where the operating software resides, for which there is capability to store up to a year of data at 1 minute intervals.

  • Page 243: Chapter 9 Optional Equipment

    Chapter 9 Optional Equipment The 49iQ is available with the following options: Connecting Several components are available for connecting external devices. External Devices These connection options consist of three plug-in boards: Communication Board ● Analog I/O Board ● Digital I/O Board ●...

  • Page 244: Communication Board

    RS-232 or RS-485 communication. Figure 9–2. RS-232/RS-485 Port Table 9–1. RS-232/RS-485 Port Terminal Assignment Terminal Number Signal Name No Connect RX/RS485_RX_P TX/RS485_TX_N No Connect No Connect RTS/RS485_TX_P CTS/RS485_RX_N No Connect 49iQ Instruction Manual Thermo Scientific...

  • Page 245: Figure 9-3. Rs-485 External Accessory Port

    Table 9–2. RS-485 External Accessory Port Terminal Assignment Terminal Number Signal Name EXT_RS485_RX_N EXT_RS485_RX_P +5V (Fused @0.4A) +5V (Fused @0.4A) +5V (Fused @0.4A) EXT_RS485_TX_N EXT_RS485_TX_P +24V (Fused @0.4A) +24V (Fused @0.4A) +24V (Fused @0.4A) +24V (Fused @0.4A) +24V (Fused @0.4A) Thermo Scientific 49iQ Instruction Manual...

  • Page 246: Analog I/O Board

    Figure 9–4. Analog Voltage Inputs Table 9–3. Analog Voltage Inputs Assignment Terminal Number Signal Name Analog In 1 Analog GND Analog In 2 Analog GND Analog In 3 Analog GND Analog In 4 Analog GND 49iQ Instruction Manual Thermo Scientific...

  • Page 247: Analog Voltage Outputs

    Current Output is 1000 Ω. All Voltage Outputs and Current Outputs are continuously monitored separately for accuracy. The Analog Outputs may be used to control and report parameters pertinent to the analyzers’ measured functions. Figure 9–5. Analog Voltage and Current Thermo Scientific 49iQ Instruction Manual...

  • Page 248: Analog Output Calibration

    Note When calibrating the current output when using the 0-20 mA scale, the low level will be set to 4 mA due to the inability to adjust the actual current output to below zero. ▲ Calibrate the output channel full scale. ● 49iQ Instruction Manual Thermo Scientific...
  • Page 249 2. Depending on the output type being used, select either Analog Out Zero Calibration (Voltage) or Analog Out 4.000 mA Calibration (Current). 3. A confirmation screen is presented. Select Continue to proceed with the calibration or Return to Previous Screen. Thermo Scientific 49iQ Instruction Manual...
  • Page 250 6. After making changes to the output levels, the commit button will turn green. To accept the changes, press the Commit button. To revert to the previous values, press the back button to return to the previous analog output calibration screen. 49iQ Instruction Manual Thermo Scientific...
  • Page 251 2. Depending on the output type being used, select either Analog Out Full Scale Calibration (Voltage) or Analog Out 20.000 mA Calibration (Current). 3. A confirmation screen is presented. Select Continue to proceed with the calibration or Return to Previous Screen. Thermo Scientific 49iQ Instruction Manual...
  • Page 252 6. After making changes to the output levels, the commit button will turn green. To accept the changes, press the Commit button. To revert to the previous values, press the back button to return to the previous analog output calibration screen. 9-10 49iQ Instruction Manual Thermo Scientific...

  • Page 253: Digital I/O Board

    The active state can be user defined in firmware. Logic Low Threshold: 0.8 V ● Logic High Threshold: 2.0 V ● Absolute allowable input voltages: -0.5 to 5.5 V ● Figure 9–6. Digital Inputs Thermo Scientific 49iQ Instruction Manual 9-11...

  • Page 254: Table 9-5. Digital Inputs Terminal Assignment

    Digital In 6 Digital In 7 Digital In 8 Digital In 9 Digital In 10 Digital In 11 Digital In 12 Digital In 13 Digital In 14 Digital In 15 Digital In 16 COMMON 9-12 49iQ Instruction Manual Thermo Scientific...

  • Page 255: Digital Relay Switches

    Optional Equipment Connecting External Devices Digital Relay Switches Table 9–6 lists the digital relay switches. Maximum Voltage: 300 VDC ● Maximum Current: 500 mA ● Fuse: 800 mA ● Figure 9–7. Digital Relay Switches Thermo Scientific 49iQ Instruction Manual 9-13...

  • Page 256: Table 9-6. Digital Relay Switch Assignment

    Relay 2B Relay 3A Relay 3B Relay 4A Relay 4B Relay 5A Relay 5B Relay 6A Relay 6B Relay 7A Relay 7B Relay 8A Relay 8B Relay 9A Relay 9B Relay 10A Relay 10B 9-14 49iQ Instruction Manual Thermo Scientific...

  • Page 257: Figure 9-8. Valve Driver Outputs

    Actual Output Voltage: 2224 VDC ● Maximum Current: 300 mA ● Both positive and negative outputs are protected from over voltage and ● over current by 500 mA fuses. Figure 9–8. Valve Driver Outputs Thermo Scientific 49iQ Instruction Manual 9-15...

  • Page 258: Table 9-7. Valve Driver Outputs Assignment

    Valve Drive 7+ Valve Drive 7- Valve Drive 8+ Valve Drive 8- Note Intended for 24 V valves. These outputs will also drive any DC load of 2224 VDC, up to 300 mA. ▲ 9-16 49iQ Instruction Manual Thermo Scientific...

  • Page 259: Ozonator

    Silastic tubing. PTFE Particulate A 5-10 micron pore size, two-inch diameter PTFE element is available for the 49iQ. This filter should be installed just prior to the SAMPLE Filter bulkhead. When using a filter, all calibrations and span checks must be performed through the filter.

  • Page 261: Appendix A Safety, Warranty, And Weee

    ▲ qualified service personnel only.   Equipment Damage Do not attempt to lift the analyzer by the cover or other ▲ external fittings. This adjustment should only be performed by an instrument ▲ service technician. Thermo Scientific 49iQ Instruction Manual...

  • Page 262: Warranty

    Products for which Buyer has requested warranty services are not covered by the warranty hereunder, Buyer shall pay or reimburse Seller for all costs of investigating and responding to such request at Seller's then 49iQ Instruction Manual Thermo Scientific...
  • Page 263 OR WRITTEN, WITH RESPECT TO THE PRODUCTS, INCLUDING WITHOUT LIMITATION ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE. SELLER DOES NOT WARRANT THAT THE PRODUCTS ARE ERROR-FREE OR WILL ACCOMPLISH ANY PARTICULAR RESULT. Thermo Scientific 49iQ Instruction Manual...

  • Page 264: Weee Compliance

    Description Marking of electrical and electronic equipment which applies to electrical and electronic equipment falling under the Directive 2002/96/EC (WEEE) and the ▲ equipment that has been put on the market after 13 August 2005. 49iQ Instruction Manual Thermo Scientific...

  • Page 265: List Of Figures

    Quick Reference List of Figures Figure 1–1. 49iQ Front ..................1-2   Figure 1–2. 49iQ Flow Diagram—No Sample/Cal Valve ........1-4   Figure 1–3. 49iQ Flow Diagram—Internal Sample/Cal Valve ......1-5   Figure 1–4. 49iQ Flow Diagram—Internal Ozonator, Manifold, Sample Cal Valve ........................
  • Page 266 Figure 7–40. Preamp Detector Cover Removal ..........7-34   Figure 7–41. Replacing the Detector ..............7-35   Figure 7–42. Replacing Detector Board ............7-36   Figure 7–43. Replacing the Thermistor ............. 7-37   Figure 7–44. Replacing the Scrubber ..............7-38   49iQ Instruction Manual Thermo Scientific...
  • Page 267 Figure 7–59. Replacing the Manifold pt 3 ............7-52   Figure 8–1. Common System Interconnect Diagram ......... 8-3   Figure 8–2. 49iQ System Interconnect Diagram ..........8-4   Figure 9–1. I/O Expansion Replacement Boards ..........9-1   Figure 9–2. RS-232/RS-485 Port................. 9-2  ...

  • Page 269: Gnu Lesser General Public License

    Our General Public Licenses are designed to make sure that you have the freedom to distribute copies of free software (and charge for this service if you wish); that you receive source code or can get it if you want it; Thermo Scientific 49iQ Instruction Manual...
  • Page 270 We call this license the "Lesser" General Public License because it does Less to protect the user's freedom than the ordinary General Public License. It also provides other free software developers Less of an advantage over competing non-free programs. These disadvantages are the reason we use 49iQ Instruction Manual Thermo Scientific...
  • Page 271 Library or any derivative work under copyright law: that is to say, a work containing the Library or a portion of it, either verbatim or with modifications and/or translated straightforwardly into another language. (Hereinafter, translation is included without limitation in the term "modification".) Thermo Scientific 49iQ Instruction Manual...
  • Page 272 Therefore, Subsection 2d requires that any application-supplied function or table used by this function must be optional: if the application does not supply it, the square root function must still compute square roots.) 49iQ Instruction Manual Thermo Scientific...
  • Page 273 5. A program that contains no derivative of any portion of the Library, but is designed to work with the Library by being compiled or linked with it, is Thermo Scientific 49iQ Instruction Manual...
  • Page 274 Library, with the complete machine-readable "work that uses the Library", as object code and/or source code, so that the user can modify the Library and then relink to produce a modified executable containing the modified Library. (It is 49iQ Instruction Manual Thermo Scientific...
  • Page 275 Give prominent notice with the combined library of the fact that part of it is a work based on the Library, and explaining where to find the accompanying uncombined form of the same work. Thermo Scientific 49iQ Instruction Manual...
  • Page 276 49iQ Instruction Manual Thermo Scientific...
  • Page 277 SHOULD THE LIBRARY PROVE DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY SERVICING, REPAIR OR CORRECTION. 16. IN NO EVENT UNLESS REQUIRED BY APPLICABLE LAW OR AGREED TO IN WRITING WILL ANY COPYRIGHT HOLDER, OR Thermo Scientific 49iQ Instruction Manual...
  • Page 278 You should also get your employer (if you work as a programmer) or your school, if any, to sign a "copyright disclaimer" for the library, if necessary. Here is a sample; alter the names: C-10 49iQ Instruction Manual Thermo Scientific...
  • Page 279 (iii) accessors; and (iv) small macros, templates and inline functions of five lines or less in length. Furthermore, you are not required to apply this additional permission to a modified version of the Library. Thermo Scientific 49iQ Instruction Manual C-11...
