8
Figure 1.1
POWER LED
ALARM LED
Console Port
Communication Ports
Failsafe Alarm Relay
Power Supply Terminal Blocks
Chassis Ground Terminal
1.3

Required Tools and Materials

The following tools and materials are required to install the RUGGEDCOM RSG908C:
AC power cord (16 AWG)
USB Type-B console port cable
LC fiber optic cables
Flathead screwdriver
Phillips screwdriver
Torx screwdriver
4 x M5 or #10-24 screws
1.4

Decommissioning and disposal

Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
RUGGEDCOM RSG908C
Equipment Manual, 11/2023, C79000-G8976-1404-15
Chassis Ground Screw
RUGGEDCOM RSG908C
Tools/Materials
Illuminates green during boot up and when power is supplied to the
device.
Illuminates red when an alarm condition exists.
The USB Type-B console port is for interfacing directly with the
device and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device" (Page 19).
Communication ports in general receive and transmit data, as
well as provide access to the RUGGEDCOM ROS Web interface.
For more information about the various ports available, refer to
"Communication Ports" (Page 21).
Latches to default state when a power disruption or other alarm
condition occurs. For more information, refer to:
• "Connecting the Failsafe Alarm Relay" (Page 11)
• "Failsafe Alarm Relay Specifications" (Page 23)
Pluggable terminal blocks for connecting one or
more power sources. For more information, refer to
"Connecting Power" (Page 12) and "Power Supply
Specifications" (Page 23).
Protects the device from power surges and accumulated static
electricity. For information about grounding the device, refer to
"Connecting Power" (Page 12).
For connecting power to the device.
For connecting to the RUGGEDCOM ROS console
interface.
For connecting the device to a LAN.
For mounting the device to a DIN rail.
For mounting the device to a panel.
For attaching mounting brackets to the device.
For mounting the device to a panel.
Introduction
1.3 Required Tools and Materials
Purpose
3
