Figure 14 OC-12c/STM-4 Daughter Card with RFI Shield
OC-12c Panel RFI Shield
Installation Procedure
There are four spacer posts on the ATM Interface Carrier Module to
support the daughter cards (Figure 15). Two spacers are located directly
behind the left cutout and two are located directly behind the right
cutout.
Figure 15 Spacers
S pacers
