Installation
Equipment
Item
Flathead countersink
Phillips-head screws - 2.5mm
diameter, 6mm long
Panhead Phillips-head screws
3.0mm diameter, 6mm long
Flat washers
Spring washers
R D
EMOVING THE AUGHTER
Figure 2 ATM Interface Carrier Module Front Panel Cutouts
Left Daughter Card Cutouts
To install a daughter card you need:


A #1 Phillips screwdriver.


The daughter card.


Screws and washers as described in Table 4 (supplied with the
daughter card).
Table 4 Supplied Screws and Washers
C
ARDS
Right Daughter Card Cutouts
Quantity Quantity
(OC-3c/STM-1) (OC-12c/STM-4)
3
2
2
2
Quantity (155
Mbps-over-UTP5)
3 3
1 2
1 2
1 2
