26 C 3: I
HAPTER NSTALLING AND
Beige Bridge Connector
R D
EMOVING THE AUGHTER
Figure 3 shows an OC-3c/STM-1 card with its protective plugs and
Figure 4 shows an OC-3c SMLR card with its protective plugs. To install an
OC-12c/STM-4 card, see "Installing the OC-12c/STM-4 Daughter Card"
on page 35.
The procedure for installing an OC-3c SMLR card is identical to the
procedure described for installing an OC-3c/STM-1 card.
Figure 3 OC-3c/STM-1 Daughter Card with Protective Plugs
Transmitting Port (Tx)
(Indicates SM or MM)
C
ARDS
Protective Plugs
Model Number
