2. Main Features

R-Series Monitors contain the following features :
• Compatible with various SDI signals
formats (SD/HD/3G/12G)
- This product is compatible with various SDI
signals - 480i, 576i, 720p, 1080i, 1080p, 1080psf
• HDMI(with HDCP) Signal
- This product is compatible with various HDMI
signals.
• All-in-one type system
- Slim and all-in-one type monitor that supports
various functions that requires no other
accessories.
• Waveform/Vectorscope/Audio Level Meter
Function
- Waveform & Vector Scope
- Embedded Audio Level Meter
• BLUE ONLY/MONO/Focus-Assist/H/V delay
• Luma(Y') zone check(Color/Zebra type)/
Range error Function
• Internal pattern generator(0~100% Gray/
Colorbar+Pluge)
• Various Markers & Safety Areas
- Center Marker, Safety Area Marker, Marker Mat,
Marker Size, Fit Marker, Thickness adjustment
• Pixel To Pixel / Zoom
- Pixel To Pixel : Displays the original image
resolution without scaling to match a certain
resolution or an aspect ratio.
- Zoom : Enlarges the original image
- Zoom Split : Zooms the specified area
sequentially.
• RS422 / D-UMD feature support
- This product supports TSL3.1 protocol using
the RS-422 communication.
• Power
- Basically, this product is powered by a normal
DC source.
- The product can be battery-powered.
* DC 6~12V (Typical)
• Additional Features
- 1,000:1 Contrast Ratio, 500cd/
OSD user interface and Rack Mountable
design.
Luminance,
㎡
