10. Product Specifications

Size
Resolution
Pixel Pitch
Color Depth
LCD
Viewing Angle
Luminance of white
Contrast Ratio
Display Area
1 X HDMI
Input
1 X BNC
2 X BNC
12G-SDI
6G-SDI
3G-SDI
Input Signal HD-SDI
SD-SDI
HDMI
SMPTE-ST 2082
SMPTE-ST-2081
SMPTE-425M-A/B
SDI Input Signal
SMPTE-274M
Formats
SMPTE-296M
SMPTE-125M
ITU-R BT.656
Power
Power Consumption (Approx.)
Tally Signal In/Out Level
Operating Temperature
Storage Temperature
Main Body Dimensions (mm/inch)
Main Body Dimensions with RMK (mm/inch)
Box Dimensions (mm/inch)
Weight
Basic Accessories
Optional Accessories
* The specification above may be changed without notice.
* When using a DC Adapter other than the one supplied by the manufacturer, please be advised that
the adapter with DC 12V/3A ~ 6A can be compatible with the monitor.
5.5"
1920×1080(16:9)
0.0213(W) x 0.0639(H) mm
16.7M (True)
H : 160 degrees / V : 160 degrees
500 cd/ m (Center)
2
1,000 : 1
122.7(H)x69.0(V) mm
HDMI Input
SDI Input (12G-SDI x 1 / 3G-SDI x 1)
3SDI Output (12G-SDI x 1 / 3G-SDI x 1),
11.88Gbps
5.94Gbps
2.970Gbps
1.485Gbps
270 Mbps
1080p(60/59.94/50/30/25/24/23.98)/1080i(60/59.94/50)/720p(60/50)/480i(60)
/480p(60)/576i(50)/576p(50)
3840x2160(60/50/59.94p)
3840x2160(30/29.97/25/24/23.98p)
1080p(60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
720p (60/59.94/50)
480i (59.94)
576i (50)
DC 12V 2.5A
35W
DC5V ±2V
0℃ to 45℃ (32 ℉ to 113 ℉ )
-20℃ to 60℃ (-4 ℉ to 140 ℉ )
439 X 87.5 X 118.7 (17.28 X 3.44 X 4.67)
480.2 X 87.5 X 141.7 (18.9 X 3.44 X 5.58)
555 X 180 X 250 (21.85 X 7.08 X 9.84)
2.9Kg/6.4lbs
DC Power adapter, Rack Mountable Kit
-
R-5T
HDMI to SDI conversion output
