TVLogic R-5T Operation Manual page 28

5. Menu Operations
[7] SYSTEM / GPI / UMD
Tally Type - Default
●
- S-8C(Single 8 Character) & S-16C(Single 16 Character)
Bit 1 Bit 1
(Tally2) (Tally1)
0
0
1
1
- D-8C(Dual 8 Character)
Bit 1 Bit 1
(Tally4) (Tally3)
0
0
1
1
D-UMD TALLY TPYE - USER COLOR
●
- Used to set the color of the TALLY1 ~ TALLY4.
Activates as follows when the UMD DISPLAY is set to D-UMD(D-8C) and the D-UMD TALLY TYPE
and the TALLY1 ~ TALLY4 COLOR is set to as below.
D-UMD TALLY TYPE
TALLY1 COLOR
TALLY2 COLOR
TALLY3 COLOR
TALLY4 COLOR
CHANNEL1
0
1
0
1
0
1
0
1
Operation
CHANNEL1
CHANNEL1
CHANNEL1
CHANNEL1
Operation
CHANNEL1
CHANNEL1
CHANNEL1
CHANNEL1
USER COLOR
CHANNEL1
RED
GREEN
RED
YELLOW
