TVLogic R-5T Operation Manual page 37

7. Other Functions
[11] Firmware Upgrade
• The USB(Thumb drive) which contains the
F/W file is needed for Firmware Upgrade.
• Select the SW UPGRADE in the SYSTEM
menu.
1. Connect the USB to the USB Slot on the
front of the monitor.
2. Select what to update among CPU / FPGA
/ ALL in [S/W UPGRADE].
3. When the USB connection is completed,
the S/W upgrade starts and the progress
displays on the bottom left side of the
screen.
4. If the USB doesn't connect properly or
there is no fi le in the specifi ed location,
the error message will be displayed on
the bottom left side of the screen and the
upgrade won't start.
5. In that case, check the USB or the fi le
location and try again.
• After USB connection, turn off and then on
the monitor.
