4. Menu Tree & Adjustment
[1] Menu Tree
• OSD(On-Screen Display) Menu helps to
use varous different functions.
• This Picture is the menu structure for
R-Series.
PICTURE 같이
BRIGHT
CONTRAST
CHROMA
SHARPNESS
PEAKING BOOST
3D LUT LOAD
3DLUT SYNC
3DLUT IMPORT 1
3DLUT IMPORT 2
3DLUT IMPORT 3
[2] Menu Control
• User may control various functions using
the MENU, UP, DOWN, ENTER buttons on
the bottom front of the monitor.
R-5T
+90
+90
+90
+24
+24
DEFAULT
SYNCHRONIZATION
NONE01
NONE01
NONE01
[3] Menu Control Sequence
• Menu control sequence follows the order
below.
1. Press the MENU button to activate the OSD
menu.
2. Move to a desired menu with the UP/DOWN
button.
3. Press the ENTER button to select a menu and
move to a sub-menu with the UP/DOWN
button.
4. Press the ENTER button to select the desired
sub-menu. (The selected sub-menu will be
highlighted.)
5. Press the ENTER button or the MENU button
to save the new value after adjusting the
value with the UP/DOWN button.
6. Press the MENU button to return to the
previous menu and if there is no previous
menu, the OSD menu will be removed from
the screen.
