6. Button Functions

[1] Input Button
SDI A
SDI B
HDMI
NO VIDEO
• The R-Series monitors support the various
input signals.
1. Press the [MENU] button on the front of the
monitor for more than 2 seconds and activate
the OSD menu as shown on the left.
Move to desired input signal by using the [UP]/
[DOWN] buttons and press the [ENTER] button
to select the input signal.
2. Input resolution displays on the bottom of
the OSD screen.
3. Press the [MENU] button again to remove the
OSD menu from the display.
# If no image displays after selecting the desired
input mode, check and make sure that your
connection is not lost or disconnected.
