Ordering information

1
2
2.1
2.2
6/38
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Ordering information
To order the 32L152CDISCOVERY ultra-low-power discovery board, refer to
Part number
32L152CDISCOVERY
STM32L-DISCOVERY
1. STM32L-DISCOVERY is replaced by STM32L152C-DISCO.

Conventions

Table 2 provides some definitions used in this user manual.
Convention
Jumper JP1 ON
JP1 OFF
Jumper
SBx ON
Solder bridge
SBx OFF
Solder bridge
The following sections of this user manual are also applicable to the STM32L-DISCOVERY
except specific features of the STM32L152RBT6 microcontroller (128 Kbyte Flash memory,
16 Kbyte RAM, 4 Kbyte data EEPROM).

Quick start

Before using the discovery kit, please accept the Evaluation product license agreement
available on the 32L152CDISCOVERY page of the www.st.com/mcu web site.

Getting started

The following sequence allows to configure the 32L152CDISCOVERY and to launch the
discovery application:
•
Check jumper positions on the board: JP1 and CN3 must be ON (discovery selected)
(see Figure 3).
•
Connect the 32L152CDISCOVERY to a computer with an USB cable to power the
board. The red LEDs LD2 (PWR) and LD1 (COM) are lit up.The Function 1 is executed.
•
Click on user button B1 to change the executed function as described in
4-LED bar shows the function being performed (1 to 4 bars can be switched ON).

Table 1. Ordering information

Order code
STM32L152C-DISCO
(1)
STM32L-DISCOVERY

Table 2. ON/OFF conventions

Jumper placed between pin 2 and 3
Jumper placed between pin 1 and 2
SBx connections closed by solder
SBx connections left open
DocID018789 Rev 4
Table
Description
Discovery kit based on STM32L152RCT6
Discovery kit based on STM32L152RBT6
Definition
Table
UM1079
