6.6

Serial Communication

The camera is capable of serial communications at baud rates up to 115.2 Kbps via the on-board serial port built
into the camera's GPIO connector. The serial port uses TTL digital logic levels. If RS signal levels are required, a
level converter must be used to convert the TTL digital logic levels to RS voltage levels.
Related Knowledge Base Articles
Configuring and testing the RS-232 serial port
SIO Buffers
Both the transmit and receive buffers are implemented as circular buffers that may exceed the 255 byte
maximum.
The transmit buffer size is 512 B.
n
The receive buffer size is 8 KB.
n
Block reads and writes are both supported. Neither their length nor their address have to be 32- bit aligned or
divisible by 4.
