System processor modules for the 9008-22L, 9009-22A, or
9223-22H
Find information about removing and replacing a system processor module for the IBM Power
L922 (9008-22L), IBM Power System S922 (9009-22A), or IBM Power System H922 (9223-22H) system.
Removing and replacing the system processor module for the
9008-22L, 9009-22A, or 9223-22H
Find information about removing and replacing a processor module in the 9008-22L, 9009-22A, or
9223-22H system.
If your system is managed by the Hardware Management Console (HMC), use the HMC to repair a part
in the system. For instructions, see "Repairing a part by using the HMC" on page 51.
If you do not have an HMC, complete the steps in the following procedures to remove and replace a
system processor module.
Preparing the system to remove and replace the system processor
module in the 9008-22L, 9009-22A, or 9223-22H
To prepare the system to remove and replace a processor module, complete the steps in this procedure.
Before you begin
As part of the system processor module replacement, the heat sink is removed. Before you begin the
removal and replacement procedure, ensure that you have a spare TIM, part number 01ML035, and heat
sink, part number 01ML180, on hand.
Procedure
1. Identify the part and the system that you are working on. For instructions, see "Identifying a part" on
page 26. Use the blue identify LED on the enclosure to locate the system. Ensure that the serial
number of the system matches the serial number to be serviced.
2. Stop the system. For instructions, see "Stopping a system" on page 36.
3. Disconnect the power source from the system by unplugging the power cords from the system. For
instructions, see "Disconnecting the power cords from the 9008-22L, 9009-22A, or 9223-22H system"
on page 47.
Note: The system might be equipped with redundant power supplies. Before you continue with this
procedure, disconnect all power cords that are connected to your system.
(L003)
1
or
