Driving and Transport
Pos: 34.7 /Überschriften/Überschriften 2/U-Z/VVorbereitungen zur Straßenfahrt @ 25\mod_1244092605963_78.docx @ 254666 @ 2 @ 1
10.1

Preparations for road travel

Pos: 34.8 /BA/Fahren und Transport/SchwaderPrüfen Sie vor der Straßenfahrt, dass Swadro TC 680_TC 760 @ 505\mod_1498745830034_78.docx @ 3474589 @ @ 1
Fig. 56
Before road travel, make certain
• the machine is fully and correctly hitched.
• the PTO shaft is switched off and the rotors have come to a complete stop.
• the rotors are locked.
• the outrigger arms are fully retracted, for the "hydraulic working width adjustment"
version.
• the operation panel is switched off, for the "electrical/hydraulic single-rotor lifting
mechanism".
• the stop cock of the additional rotor is closed, for the "additional rotor" version.
• the machine is in the transport position.
• all hydraulic control units are in neutral position.
• the retaining bolts are correctly engaged in the lockings (1).
• the tine guards (2) have been plugged onto the tines located in transport position below 2
m.
• the lighting system works.
• the lower links are lowered to a height of 35 cm to the ground to maintain the transport
height.
Pos: 34.9 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
88
1
SW700063
2
SW700062_1
