Pos: 40.11.1 /Überschriften/Überschriften 2/A-E/AAnziehdrehmomente @ 202\mod_1385711894606_78.docx @ 1693123 @ 2 @ 1
12.3

Tightening torques

Pos: 40.11.2 /Überschriften/Überschriften 3/K-O/MMetrische Gewindeschrauben mit Regelgewinde @ 322\mod_1424945442462_78.docx @ 2483466 @ 3 @ 1
12.3.1

Metric Thread Screws with Control Thread

Pos: 40.11.3 /BA/Wartung/Drehmomente / Anziehdrehmomente/Anziehdrehmomente Metrische Gewindeschrauben mit Regelgewinde Tabelle @ 321\mod_1424760222607_78.docx @ 2477725 @ @ 1
NOTICE
The table does not apply to countersunk screws with hexagonal socket in case the countersunk
screw is tightened via hexagonal socket.
Tightening torque in Nm (unless
otherwise stated)
A
M4
M5
M6
M8
M10
M12
M14
M16
M20
M22
M24
M27
M30
Pos: 40.11.4 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
Stability class
5.6
8.8
10.9
Tightening torque (Nm)
3.0
4.4
5.9
8.7
10
15
25
36
29
49
72
42
85
125
135
200
210
310
425
610
571
832
730
1050
1100
1550
1450
2100
A = thread size
(stability class can be seen on screw
head)
12.9
5.1
10
18
43
84
145
235
365
710
972
1220
1800
2450
Maintenance
103
