Lightware VINX-120AP-HDMI-ENC-DNT User Manual page 3

   
Symbol Legend
The following symbols and markings are used in the document:

WARNING! Safety-related information
recommended to read and keep in every case!

ATTENTION! Useful information to perform a successful procedure;
it is recommended to read.

DIFFERENCE: Feature or function that is available with a specific
firmware/hardwareversionorproductvariant.
INFO:
A notice which may contain additional information. Procedure
can be successful without reading it.
DEFINITION:
The short description of a feature or a function.

TIPS AND TRICKS: Ideas which you may have not known yet but
can be useful.
Navigation Buttons
Go back to the previous page. If you clicked on a link previously,

you can go back to the source page by pressing the button.

Navigate to the Table of Contents.

Step back one page.

Step forward to the next page.
Document Information
All presented functions refer to the indicated products. The
descriptions have been made during testing these functions in
which is highly
accordance with the indicated Hardware/Firmware/Software
environment:
Firmware package version
LightwareDeviceController
Document revision: 1.8
Release date: 22-01-2020
Editor:LaszloZsedenyi
Appliedfirmwarepackage:v2.0.0b27 | LDCsoftware:v1.34.0b2
VINX-1x0-HDMI Extenders – User's Manual
Item Version
2.0.0b27
1.34.0b2
About Printing
Lightware Visual Engineering supports green technologies and
Eco-friend mentality. Thus, this document is made for digital usage
primarily. If you need to print out few pages for any reason, follow the
recommended printing settings:
Pagesize: A4
▪
▪ Outputsize: FittopageorMatchpagesize
▪ Orientation: Landscape

TIPS AND TRICKS: Thankstothesizeoftheoriginalpage,aborder
around the content (gray on the second picture below) makes
possible to organize the pages better. After punching the printed
pages, they can be placed easily into a ring folder.
1 2
Hashtag (#) Keywords in the Document
This user's manual contains keywords with hashtag (#) to help you to
findtherelevantinformationasquickaspossible.
The format of the keywords is the following:
#<keyword>
The usage of the keywords: use the Searchfunction(Ctrl+F/Cmd+F)
of your PDF reader application, type the # (hashtag) character and the
wished keyword.
The #newspecialkeywordindicatesanewfeature/functionthathas
justappearedinthelatestfirmwareorsoftwareversion.
Example
#dhcp
This keyword is placed at the DHCP (dynamic IP address) setting in
thefrontpaneloperation,theLightwareDeviceController(LDC)and
the LW3 programmer's reference section. See the listof allhashtag
keywords of the document in the HashtagKeywordList.
