5.Programmers'Reference

5.4.10. Setting a Static Gateway Address

DIFFERENCE:
Make sure the IP address setting is static:
In case of FW 1.x.x: when the DhcpEnabled property is false you can set a static IP address.
In case of FW 2.x.x: when the IpSetupMode property is static you can set a static IP address.
Command and Response
SET•/MANAGEMENT/NETWORK.StaticGatewayAddress=<gateway_address>
ç
pw•/MANAGEMENT/NETWORK.StaticGatewayAddress=<gateway_address>
æ
Example
ç SET/MANAGEMENT/NETWORK.StaticGatewayAddress=192.168.0.5
æ pw/MANAGEMENT/NETWORK.StaticGatewayAddress=192.168.0.5
ç CALL/MANAGEMENT/NETWORK:applySettings(1)
æ mO/MANAGEMENT/NETWORK:applySettings

INFO: The applySettings method will save and apply the new value and results the extender to reboot.
VINX-1x0-HDMIExtenders–User'sManual

5.5. Encoder-related Commands

5.5.1. Querying the Input Video Signal Presence

The input port can be queried if video signal is present.
Command and Response
ç GET•/MEDIA/VIDEO/<in>.SignalPresent
æ
Parameters
If the
present at the input.
Example
ç GET/MEDIA/VIDEO/I1.SignalPresent
æ pr/MEDIA/VIDEO/I1.SignalPresent=1

5.5.2. Querying the Resolution of the Input Video Signal

The resolution and the refresh rate of the incoming video signal can be queried.
Command and Response
ç GET•/MEDIA/VIDEO/<in>.Resolution
æ
Example
ç GET/MEDIA/VIDEO/I1.Resolution
æ pr/MEDIA/VIDEO/I1.Resolution=1280x720@60Hz

5.5.3. Querying the Active Input Port

DIFFERENCE:
Command and Response
ç GET•/MEDIA/VIDEO.InputSource
æ
Parameters
<source_ID>
Example
ç GET/MEDIA/VIDEO.InputSource
æ pr/MEDIA/VIDEO.InputSource=1
Appliedfirmwarepackage:v2.0.0b27 | LDCsoftware:v1.34.0b2
#status
pr•/MEDIA/VIDEO/<in>.SignalPresent=<signal_present>
<signal_present> parameter is 0, then signal is not present at the port. If the value is 1, then signal is
#resolution
pr•/MEDIA/VIDEO/<in>.Resolution=<resolution@refresh_rate>
Below command is valid for VINX-210AP-HDMI-ENC device only.
pr•/MEDIA/VIDEO.InputSource=<source_ID>
Identifier Parameter description
Identifierofthevideoinputport
Parameter values
0: unknown
1: HDMI
2: VGA
