ZLWK FRPE DLG configuration field
•
If the option ZLWK FRPE DLG is marked, the values of the scale are transferred in
the following order:
1. "Weighed in quantity, combustion aid"
2. "Weighed in quantity, combustion aid + weighed in sample"
UHYHUV configuration field
•
If the UHYHUV configuration field is marked in addition to the :LWK FRPEXVWLRQ DLG
field, the scale values will be transferred in the following order:
1. "Weighed in sample"
2. "Weighed in sample + weighed in combustion aid"
After the second measurement value is transferred, the 1HZ PHDVXUHPHQW dia-
log box appears. The calculated value for extraneous energy is already entered
in this dialog box.
+R >-J@ DLG configuration field
•
In combination with the configuration field ZLWK FRPE DLG, the gross calorific
value of the combustion aid must be entered in this field for the system to be
able to calculate the extraneous energy.
 7XUQLQJ RII WKH V\VWHP
When you want to turn off the calorimeter system, open the System menu and bring
up Exit.
7KHUH PXVW EH QR GHFRPSRVLWLRQ YHVVHO VXVSHQGHG LQ WKH PHDVXULQJ FHOO
FRYHU
8VH RQO\ WKH ([LW LWHP LQ WKH 6\VWHP PHQX WR WXUQ RII WKH GHYLFH 'R QRW XVH
WKH SRZHU VZLWFK DV WKLV ZLOO UHVXOW LQ ORVW GDWD
When the system has shut down, a message to that effect appears on the display.
The message also asks you to turn off the power switch for the calorimeter and
cooler unit.
