VIESMANN
Installation and service instructions
for contractors
Vitovalor PT2
Type E11T, E19T, E25T, E32T, 0.9 to 30.8 kW
Fuel cell based micro CHP unit with integral gas condensing boiler and adjacent
cylinder module
Natural gas version
VITOVALOR PT2
Please keep safe.
5835783 GB
5/2019
