Using This Manual

U T
SING HIS
This manual provides installation, configuration and management procedures
for using the ADC Campus
RS interface card. It includes procedures to:
•
install the card in either a Campus-RS
150-1158-02, 150-1158-51, or 150-1158-52) or Campus-Star
(150-1220-01, 150-1220-02, or 150-1220-51)
• configure the Campus-REX2 using the LCD and buttons
•
configure the Campus-REX2 using the command-line interface
•
monitor the Campus-REX2 performance
•
perform testing on the Campus-REX2
•
contact ADC for assistance
D
OCUMENT
Messages identified by icons shown below may appear in the text.
Notes contain information about special circumstances.
Cautions indicate the possibility of personal injury or
equipment damage.
The Electrostatic Discharge (ESD) symbol indicates that a
device or assembly is susceptible to damage from
electrostatic discharge.
iv
M
ANUAL
®
Remote Ethernet eXpress2 (Campus-REX2
C
ONVENTIONS
™
desktop unit (150-1158-01,
Campus-REX2 RS Interface Card User Manual
®
)
®
chassis
