Section 3: Operation
then enter the desired program name (up to 8 characters).
4. Tap ON TIME to set the amount of time for each pump operation. The On Time Edit screen will be
displayed.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM
gram screen.
5. Tap OFF TIME to set the amount of time the pump will pause between each operation. The Off Time
Edit screen will be displayed. NOTE: If the off time is set to 0 (zero) the pump drive will require a start
input (from either the touchscreen or a wired input) to start the next dispense.
a. Tap HR, MIN, SEC or TENTHS and enter the desired time using the onscreen keypad.
b. Tap CONFIRM
gram screen.
6. Tap FLOW RATE. The Flow Rate Edit screen will be displayed.
a. Tap UNITS to access the Flow Units screen and select the desired flow unit from the available list.
b. Tap CONFIRM
c. Tap FLOW and enter the desired flow rate using the onscreen keypad.
d. Tap CONFIRM
gram screen.
7. Tap SIZE. The Tube Size screen will be displayed.
a. Select the desired tube size from the available list or SCROLL
custom tube size using the onscreen keypad.
b. Tap CONFIRM
gram screen.
8. Tap DIRECTION to select either clockwise
9. Tap BATCH TOTAL to adjust the number of dispenses in each batch cycle. The Batch Total screen will
be displayed.
a. Enter the desired number of dispenses in a batch using the onscreen keypad. NOTE: If required,
tap INFINITE ∞ to select an infinite number of dispense cycles. If infinite is selected, the pump
will run continuously.
b. Tap CONFIRM
gram screen.
10. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection screen.
• If there are multiple programs tapping SCROLL
3-34 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
to save or CANCEL
to save or CANCEL
to save or CANCEL
to save or CANCEL
to save or CANCEL
to save or CANCEL
to discard changes and return to the Time New Pro-
to discard changes and return to the Time New Pro-
to discard changes and return to the previous screen.
to discard changes and return to the Time New Pro-
and tap CUSTOM to enter a
to discard changes and return to the Time New Pro-
or counterclockwise
to discard changes and return to the Time New Pro-
will display additional pages.
flow direction.
