Section 2: Basic Setup & Settings

Auto Start

The REGLO has an auto start that will resume pump operation when power is restored after a power outage.
To enable auto start:
1. Tap SETTINGS
2. SCROLL
3. Tap the AUTO START toggle to select either ON or OFF.
Dispense & Batch Completion Alerts
When Sound Dispense is enabled a short beep will sound at the completion of each pump dispense. When
Sound Batch is enabled a single long beep will sound at the completion of each batch cycle.
To enable or disable the dispense completion alert:
1. Tap SETTINGS
2. SCROLL
3. Tap the SOUND DISPENSE toggle to select either ON or OFF.
To enable or disable the batch cycle completion alert:
1. Tap SETTINGS
2. SCROLL
3. Tap the SOUND BATCH toggle to select either ON or OFF.

Analog Output

The REGLO supports and controls analog output through the pump drive's 25-pin connection (for further
information see "DB-25 Electrical
1. Tap SETTINGS
2. SCROLL
3. Tap ANALOG OUTPUT. The Analog Output screen will be displayed.
4. Tap the desired analog output type from the available list.
5. If using either ANALOG: VOLTAGE or ANALOG: CURRENT:
a. Tap EDIT
b. Select the desired current or voltage operating range from the available list.
c. Tap CONFIRM
displayed.
6. Tap CONFIRM
3-13 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
from any of the mode screens. The Settings screen will be displayed.
through the Settings screen pages to locate AUTO START.
from any of the mode screens. The Settings screen will be displayed.
through the Settings screen pages to locate SOUND DISPENSE.
from any of the mode screens. The Settings screen will be displayed.
through the Settings screen pages to locate SOUND BATCH.
Connections" on page 3-40.
from any of the mode screens. The Settings screen will be displayed.
through the Settings screen pages to locate ANALOG OUTPUT.
. The Analog: Voltage or Analog: Current Edit screen will be displayed.
to save or CANCEL
.
to discard changes. The Analog Output screen will be
