Section 3: Operation
J. PRIME: Press and hold to prime the pump drive (for further information see
on page 3-7).
K. START/STOP/PAUSE: During operation, the display will change from START
RESET .
L. FLOW DIRECTION: Tap DIRECTION to select either clockwise
direction.
M. SCREEN LOCK: Locking the screen disables all touchscreen functions. To lock the screen: Press and
hold UNLOCKED
screen. To unlock the screen: Press and hold LOCKED
N. SETTINGS: Tap to access the Settings screen (for further information see "Settings" on page 3-10).

Volume Mode Edit Screen

Mode Name Banner
the previous screen
Tap to access the
Dispense Volume screen
Tap to access the
Flow Rate Edit screen
Tap to access the
Tube Size screen
Tap to access the Anti-Drip screen
(see "Anti-Drip" on page 3-27)

Volume Dispense Mode Operation

General Preparation:
• Confirm the correct tubing has been selected and is properly loaded into the pump drive (for further
information see
• Confirm all fluids and containers are ready.
• Switch the drive on using the power switch located at the rear of the drive. NOTE: The touchscreen
display will revert to the previously used operation mode.
• Confirm that the tubing has been calibrated by checking that Calibration Complete
Volume Mode Edit screen (for further information see
