Section 3: Operation

SECTION 3: OPERATION
WARNING: Tube breakage may result in fluid being sprayed from the pump. Use appropriate
!
measures to protect operator and equipment.
CAUTION: Keep fingers away from the rotor while the pump is in operation. Stop the pump
before loading or unloading tubing.
CAUTION: Hot Surface. Do not touch.
CAUTION: To avoid electrical shock, the power cord protective grounding conductor must be
connected to ground. Not for operation in wet locations as defined by EN61010-1.

MODE SELECTION SCREEN

The Mode Selection screen allows access to the drive's four basic operation modes (CONTINUOUS, TIME,
VOLUME, and REMOTE) as well as the New Program screen and user defined programs. The Mode
Selection screen can be accessed from any of the mode screens by tapping the MODE NAME BANNER.
Remote Mode
Add New Program
Tap the desired mode or program to access individual mode or program screens.
3-15 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
Time Mode
Continuous Mode
Volume Mode
Page Scroll
Settings
