Section 3: Operation

CUSTOM PROGRAM MODES

Custom programs allow users to create easily accessible programs for frequently used pump mode settings.

Adding a New Program: Continuous Mode

To add a new Continuous Mode program:
1. Tap NEW PROGRAM from the Mode Selection screen. The New Program screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection screen tap SCROLL
additional pages.
2. Tap CONTINUOUS. The Continuous New Program screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
4. Select the desired flow rate and flow units:
a. Tap FLOW RATE to access the Flow Rate screen.
b. Tap UNITS to access the Flow Units screen and select the desired flow unit from the available list.
c. Tap CONFIRM
d. Tap FLOW and enter the desired flow rate using the onscreen keypad.
e. Tap CONFIRM
Program screen.
5. Tap SIZE. The Tube Size screen will be displayed.
a. Select the desired tube size from the available list or SCROLL
custom tube size using the onscreen keypad.
b. Tap CONFIRM
Program screen.
6. Tap DIRECTION to select either clockwise
7. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection screen.
• If there are multiple programs tapping SCROLL

Adding a New Program: Time Mode

To add a new Time Mode program:
1. Tap NEW PROGRAM from the Mode Selection screen. The New Program screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection screen tap SCROLL
additional pages.
2. Tap TIME. The Time New Program screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
3-33 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
to save or CANCEL
to save or CANCEL
to save or CANCEL
to discard changes and return to the Flow Rate screen.
to discard changes and return to the Continuous New
and tap CUSTOM to enter a
to discard changes and return to the Continuous New
or counterclockwise
will display additional pages.
to view
flow direction.
to view
