- Page 1 ® OPERATING MANUAL: GEAR ® PUMP DRIVE Model Nos. 75211-12 75211-17 A-1299-1177 Edition 02 (US & Canada only) Toll Free 1-800-MASTERFLEX • 1-800-637-3739 (Outside US & Canada) 1-847-549-7600 • 1-847-381-7050 www.masterflex.com • techinfo@masterflex.com...
- Page 2 © 2019 Cole-Parmer Instrument Company LLC. All rights reserved. Masterflex – Reg TM Cole-Parmer Instrument Company. ® Trademarks bearing the symbol in this publication are registered in the U.S. and in other countries. PUMP FOR LIQUIDS ORIGINAL INSTRUCTIONS Masterflex MASTERFLEX ®...
- Page 3 EXPLANATION OF CAUTION: Risk of Danger. Consult Operator’s manual for nature of hazard and corrective actions. SYMBOLS CAUTION: Risk of electric shock. Consult Operator’s manual for nature of hazard and corrective actions. Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual...
- Page 4 CAUTION: Replace the fuse only with one of the same type and rating. The fuse rating and type are stated on the rear panel. 7. The Pump Drives should not be used in outdoor or hazardous locations. Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual...
-
Page 5: Table Of Contents
Technical Assistance ......... . .6-2 Masterflex MASTERFLEX ®... - Page 7 Fuse Replacement ..........3-2 Masterflex MASTERFLEX ®...
-
Page 9: Introduction
Pump Drives, as well as operating and servicing at the user level. The following chart provides basic information on models covered in this manual. Drive Catalog Number Output rpm Flow Rate Power Requirement 75211-12 90 to 130V AC 2.5-5450 mL/min 50 to 5000 (purchase pump head 75211-17... -
Page 11: Installation And Setup
5. Install the pump below the level of the supply liquid. the liquid must be under atmospheric conditions. 6. This completes the basic setup. Figure 2-1. View of Rear Drive A. IEC Power Entery Module B. Power Switch C. External Start/Stop Connector Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual... -
Page 12: Setup And Drive Operation
Replace the power cord only with one of the same type and rating. The minimum power ratings are stated on the rear panel. Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual... -
Page 13: External Start/Stop Control
Reserved – Not Used Start/ Stop Start/ Stop Reserved – Not Used Reserved – Not Used NOTE: Jumper must be be installed for pump to run. Figure 2-4. DB-9 Connector Jumper Installation. Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual... -
Page 15: Maintenance
5. Insert brushes and install brush cap. 6. Install housing and secure with the screws on each side. 7. Connect the AC power input line cord to the AC receptacle. Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual... -
Page 16: Fuse Replacement
2. Disconnect the AC power input line cord from the receptacle. 3. Remove and check the fuse and replace if defective. Figure 3-2. Fuse Replacement Item Description IEC Power Entry Module / Line Cord (5 X 20 mm) Fuse- Do Not Substitute Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual... -
Page 17: Replacement Parts
Part Number Brushes (set of 2) 07520-04 Jumper Kit (set of 2) 07555-90 Fuse (75211-12) T4.0A 250V; 5 × 20 mm 77500-26 Fuse (75211-17) T2.0A 250V; 5 × 20 mm 77500-26 Cleaning WARNING: Remove power from the pump before any cleaning operation is started. -
Page 19: Accessories
Accessories Section 4 Description Part Number Footswitch with 6 ft. DB-9 male connector 77595-35 Handheld Remote Controller 07528-80 DB-9 External Control Connector 07595-45 DB-9 Remote Control Cable, 25 ft. 07595-47 Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual... -
Page 21: Specifications
Dimensions (L x W x H): 9.09 in x 7.23 in x 5.29 in (231 × 184 × 134.5 mm) Weight: 9.46 lbs. (4.26 kg) Enclosure Rating: IP 22 per IEC 60529 Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual... - Page 22 Powder coated steel enclosure and cover, ABS plastic and vinyl Compliance: Conforms to ANSI/UL 61010-1, 3rd edition and CSA-C22.2 No. 61010-1-12 (For CE Mark): EN61010-1 (EU Low Voltage Directive) and EN61326-1 (EU EMC Directive) Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual...
-
Page 23: Warranty
Warranty, Product Return and Section 6 Technical Assistance Warranty Use only MASTERFLEX precision tubing with MASTERFLEX pumps to ensure optimum performance. Use of other tubing may void applicable warranties. This product is warranted against defects in material or workmanship, and... -
Page 24: Product Return
Any damages resulting from improper packaging are your responsibility. Technical Assistance If you have any questions about the use of this product, contact the the Manufacturer or authorized seller. Masterflex MASTERFLEX ® Gear Pump Drive Operating Manual... - Page 26 US & Canada only *EN809 manufactured by: Toll Free 1-800-MASTERFLEX | 1-800-637-3739 Cole-Parmer Instrument Company Outside US & Canada 28W092 Commercial Avenue, Barrington, IL 60010 techinfo@masterflex.com | www.masterflex.com 1-847-549-7600 | 1-847-381-7050...
