Section 3: Operation
b. Tap CONFIRM
Edit screen.
8. If required, tap ANTI-DRIP. The Anti-Drip screen will be displayed (for further information see
Drip" on page 3-27).
a. Tap ON or OFF to enable or disable the Anti-Drip feature.
b. If enabled, enter the desired degrees of reverse rotation using the onscreen keypad. NOTE: Typical
values range from 5 to 45 degrees.
c. Tap CONFIRM
Edit screen.
9. Tap CONFIRM
10. Tap DIRECTION to select either clockwise
11. Tap START
STOP is tapped.
12. If required, adjustments can be made to any of the Volume Mode option settings during operation. To
make any adjustments:
a. Tap PAUSE
b. Tap CONTINUE

Saving Volume Mode Settings as a New Program

Changes made to mode parameters can be saved as a new program for easier access to frequently used settings.
To save mode parameters to a new program:
1. If required, edit the Volume Mode settings as desired.
2. Tap MODE NAME BANNER to return to the Mode Selection screen.
3. Tap NEW PROGRAM. NOTE: If NEW PROGRAM is not displayed on the Mode Selection screen tap
SCROLL
4. Tap VOLUME. The Volume New Program screen will be displayed with the last settings used in the
Volume Mode.
5. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
6. Tap CONFIRM to save or DELETE to cancel.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection screen.
• If there are multiple programs tapping SCROLL
3-26 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
to save or CANCEL
to save or CANCEL
to return to the Volume Mode Run screen.
. The pump will now operate until the batch total is completed or until PAUSE
and then repeat steps 2–10 above.
to complete the pump operation once the desired changes have been made.
to view additional pages.
to discard changes and return to the Volume Mode
to discard changes and return to the Volume Mode
or counterclockwise
will display additional pages.
"Anti-
flow direction.
or
