Section 2: Basic Setup & Settings
8. Tap SIZE from the Continuous Mode screen or tap EDIT
Time Mode screen is displayed. The Tube Size screen will be displayed.
a. Select the desired tube size from the available options or SCROLL
a custom tube size.
b. Tap CONFIRM
9. Tap CALIBRATE
10. Tap CALIBRATION VOLUME. The Calibration Volume screen will be displayed.
a. Enter the desired calibration volume using the onscreen keypad. NOTE: The default volume or
greater will ensure the best calibration.
b. Tap CONFIRM
11. Tap FLOW RATE. The Calibration Flow Rate screen will be displayed.
a. Enter the desired flow rate using the onscreen keypad.
b. Tap CONFIRM
NOTE: The drive will adjust the displayed flow rate after calibration is complete.
12. Tap START
13. When calibration is complete use the onscreen keypad to enter the measured volume of fluid from the
tube outlet container.
14. Tap CONFIRM
Complete
tube size, tube volume, and flow rate.
NOTE:
• The estimated accuracy for the selected calibration settings is shown in the Calibration Strength bar on
the Tube Calibration screen. Calibration accuracy can be improved by using a larger calibration volume
and/or altering the flow rate.
• Calibration settings are retained and transferred to other mode screens when entering or leaving the Tube
Calibration screen.
• If the drive is stopped during calibration the calibration will be discarded and the previous mode screen
will be displayed. Empty the container before restarting the procedure.
• Calibration time at the maximum allowable flow rate (default max flow rate) is approximately 10 seconds.
Calibration time at the minimum allowable flow rate (approximately 4% of the maximum flow rate) is 4
minutes. Select a custom tube size for other tubing sizes or lower flow rates (see step 8 above).
• Minimum and maximum flow rates will change after calibration due to a recalculation of the volume of
fluid per pump revolution.
• The best results are obtained after tubing has been run in the pump for approximately 20-30 minutes.
• Steps 9–14 can be repeated as necessary to optimize the accuracy of the tubing calibration.
3-9 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
to save or CANCEL
. The Tube Calibration screen will be displayed.
to save or CANCEL
to save or CANCEL
to begin calibration. NOTE: Calibration progress will be displayed on the touchscreen.
to complete calibration and return to the previous mode screen. Calibration
should now be displayed to indicate that calibration has been completed for the current
and then SIZE if either the Volume or
to discard changes and return to previous screen.
to discard changes and return to the previous screen.
to discard changes and return to the previous screen.
and tap CUSTOM to enter
