Section 3: Operation

CONTINUOUS MODE

In Continuous Mode the pump will operate at a selected rpm and/or flow rate until stopped by the user.

Continuous Mode Run Screen

The Continuous Mode Run screen is accessed by selecting CONTINUOUS from the Mode Selection screen.
A. Mode Name Banner
D. Tube Size
H. Flow Direction
A. MODE NAME BANNER: Tap the Mode Name Banner to return to the Mode Selection screen.
B. CUMULATIVE VOLUME: Displays the current cumulative volume of fluid that has been pumped. To
reset the cumulative volume: Press and hold CUMULATIVE VOLUME RESET
changes to zero.
C. FLOW RATE: Displays the current flow rate in the unit of measurement selected by the user. Tap to
access the Flow Rate screen.
D. SIZE: Tap to access the Tube Size screen.
E. CALIBRATE: Tap to access the Calibration screen (for further information see
page 3-8). Once calibration has been completed for the current tube size Calibration Complete
be displayed.
F. PRIME: Press and hold to prime the pump drive (for further information see
on page 3-7).
G. START/STOP: Tap START to begin operation. Once operation has commenced STOP
displayed.
H. FLOW DIRECTION: Tap DIRECTION to select either clockwise
3-16 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
F. Prime
B. Cumulative Volume
C. Flow Rate
E. Calibrate
G. Start/Stop
I. Screen Lock
J. Settings
until the display
"Tube Calibration" on
"Priming the Pump
will be
or counterclockwise
will
Drive"
.
