Section 4: Service & Maintenance

Color-Coded Three-Stop Tubing

Color-Coded Three-Stop Tubing suitable for use with cassettes:
3-45 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
Color-Coded Stops
ORANGE/BLACK/ORANGE
ORANGE/RED/ORANGE
ORANGE/BLUE/ORANGE
WHITE/BLUE/WHITE
RED/BLUE/RED
BROWN/BLUE/BROWN
BROWN/BLACK/BROWN
ORANGE/GREEN/ORANGE
GREEN/YELLOW/GREEN
ORANGE/YELLOW/ORANGE
WHITE/YELLOW/WHITE
ORANGE/WHITE/ORANGE
BLACK/BLACK/BLACK
ORANGE/ORANGE/ORANGE
WHITE/BLACK/WHITE
WHITE/WHITE/WHITE
WHITE/RED/WHITE
RED/RED/RED
RED/GRAY/RED
GRAY/GRAY/GRAY
YELLOW/YELLOW/YELLOW
YELLOW/BLUE/YELLOW
BLUE/BLUE/BLUE
BLUE/GREEN/BLUE
GREEN/GREEN/GREEN
PURPLE/PURPLE/PURPLE
PURPLE/BLACK/PURPLE
PURPLE/ORANGE/PURPLE
PURPLE/WHITE/PURPLE
BLACK/WHITE/BLACK
MM ID
0.13
0.19
0.25
0.28
0.31
0.33
0.36
0.38
0.44
0.51
0.57
0.64
0.76
0.89
0.95
1.02
1.09
1.14
1.22
1.33
1.42
1.52
1.65
1.75
1.85
2.06
2.29
2.54
2.79
3.17
