Section 3: Operation
a. Enter the desired number of dispenses in a batch using the onscreen keypad. NOTE: If required,
tap INFINITE ∞ to select an infinite number of dispense cycles. If infinite is selected, the pump
will run continuously.
b. Tap CONFIRM
Program screen.
10. If required, tap ANTI-DRIP. The Anti-Drip screen will be displayed (for further information see
Drip" on page 3-27).
a. Tap ON or OFF to enable or disable the Anti-Drip feature.
b. If enabled, enter the desired degrees of reverse rotation using the onscreen keypad. NOTE: Typical
values range from 5 to 45 degrees.
c. Tap CONFIRM
Program screen.
11. Tap CONFIRM to save or DELETE to discard changes.
NOTE:
• Once saved, new programs are added in alphabetical order to the bottom of the Mode Selection screen.
• If there are multiple programs tapping SCROLL

Adding a New Program: Remote Mode

To add a new Remote Mode program:
1. Tap NEW PROGRAM from the Mode Selection screen. The New Program screen will be displayed.
NOTE: If NEW PROGRAM is not displayed on the Mode Selection screen tap SCROLL
additional pages.
2. Tap REMOTE. The Remote New Program screen will be displayed.
3. Tap PROGRAM1. If required, delete the characters using the back arrow on the onscreen keypad and
then enter the desired program name (up to 8 characters).
4. Tap INPUT. The Remote Type screen will be displayed.
5. Tap the desired remote type from the available list.
6. If using either ANALOG: VOLTAGE or ANALOG: CURRENT:
a. Select the desired current or voltage operating range from the available list.
b. Tap CONFIRM
screen.
7. Tap SIZE. The Tube Size screen will be displayed.
a. Select the desired tube size from the available list or SCROLL
custom tube size using the onscreen keypad.
b. Tap CONFIRM
Program screen.
8. Tap DIRECTION to select either clockwise
3-36 Masterflex REGLO Digital Pump Drive with Advanced Connectivity
to save or CANCEL
to save or CANCEL
to save or CANCEL
to save or CANCEL
to discard changes and return to the Volume New
to discard changes and return to the Volume New
will display additional pages.
to cancel and return to the Remote New Program
and tap CUSTOM to enter a
to discard changes and return to the Remote New
or counterclockwise
"Anti-
to view
flow direction.
