The MIC-3355 is a 6U-sized CompactPCI™, all-in-one single board
®
Pentium
processor-based CPU card which complies with PICMG 2.0
R2.1 CompactPCI specifications. The MIC-3355 offers all the functions
of an industrial computer on a single board CPU card. This card
supports an Intel Pentium, Pentium MMX, AMD K5, AMD K6, Cyrix
M1 or Cyrix M2 processor. The card accepts up to 256 MB SDRAM. It
nd
also supports on-board 512 KB PB-SRAM 2
level cache.
The MIC-3355 uses a single-chip solution, allowing on-board DRAM
to be shared with the built-in VGA controller. In this configuration, the
chipset always acts as the arbiter between memory bus masters. This
system ensures efficient memory allocation while substantially
reducing the overall system cost.
nd
On-board features include 512 KB 2
level cache memory, 100/10
Mbps fast Ethernet interface, one RS-232 port, one RS-232/422/485
port, one multi-mode parallel (ECP/EPP/SPP) port, a floppy drive
controller and a keyboard and PS/2 mouse interface. The built-in high
speed PCI IDE controller supports both PIO and bus master modes.
Two IDE channels are available through the J3 connector and one
channel is available through the on-board connector. Up to two IDE
devices can be connected to one channel, including large hard disks,
CD-ROM drives, tape backup drives and other IDE devices. The MIC-
3355 also supports two USB ports and one fast infrared port.
The MIC-3355 also features power management to minimize power
consumption. It complies with the "Green Function" standard and
supports three types of power saving features: Doze mode, Standby
mode and Suspend mode. A watchdog timer can automatically reset
the system or generate an interrupt should the system stop due to a
program bug or EMI.
