Advantech MIO-2263 User Manual

Intel atom soc j1900/e3825 pico-itx sbc, ddr3l, 18/24-bit lvds, vga or hdmi, 1gbe, half-size mini pcie, 4 usb, 2 com, smbus, msata, mioe
Hide thumbs Also See for MIO-2263:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
MIO-2263
Intel® Atom™ SoC J1900/E3825
Pico-ITX SBC, DDR3L, 18/24-bit
LVDS, VGA or HDMI, 1 GbE, Half-
size Mini PCIe, 4 USB, 2 COM,
SMBus, mSATA & MIOe

Advertisement

Table of Contents
loading

Related Manuals for Advantech MIO-2263

Summary of Contents for Advantech MIO-2263

  • Page 1 User Manual MIO-2263 Intel® Atom™ SoC J1900/E3825 Pico-ITX SBC, DDR3L, 18/24-bit LVDS, VGA or HDMI, 1 GbE, Half- size Mini PCIe, 4 USB, 2 COM, SMBus, mSATA & MIOe...
  • Page 2 The documentation and the software included with this product are copyrighted 2014 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
  • Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 4 Packing List Before installation, please ensure the following items have been shipped: Item Part Number  1 MIO-2263 SBC  1 Startup manual  Cables Part Number Description 1700006291 SATA cable 7P 30 cm w/ right angle 1700022444-01 Audio Cable 2*5P-2.0/JACK*2 20cm 1701200220 COM PORT cable 2*10P-2.0/D-SUB 9P(M)*2 22 cm...
  • Page 5 Caution! There is a danger of a new battery exploding if it is incorrectly installed. Do not attempt to recharge, force open, or heat the battery. Replace the battery only with the same or equivalent type recommended by the man- ufacturer. Discard used batteries according to the manufacturer's instructions. MIO-2263 User Manual...
  • Page 6 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 7 Don't touch any components on the CPU card or other cards while the PC is on.  Disconnect power before making any configuration changes. The sudden rush of power as you connect a jumper or install a card may damage sensitive elec- tronic components. MIO-2263 User Manual...
  • Page 8 MIO-2263 User Manual viii...

  • Page 9: Table Of Contents

    3.2.2 Advanced BIOS Features Setup..........20 3.2.3 Chipset Configuration ..............34 3.2.4 Security ..................43 3.2.5 Boot..................... 44 3.2.6 Save & Exit ................. 45 Chapter S/W Introduction & Installation ..47 S/W Introduction..................48 Driver Installation ..................48 MIO-2263 User Manual...
  • Page 10 Appendix C System Assignments......85 System I/O Ports..................86 Table C.1: System I/O Ports ............86 1st MB Memory Map................86 Table C.2: 1st MB Memory Map ..........86 Interrupt Assignments ................87 Table C.3: Interrupt assignments..........87 MIO-2263 User Manual...

  • Page 11: Chapter 1 General Introduction

    Chapter General Introduction This chapter gives background information on the MIO-2263. Sections include:  Introduction  Product Features  Specifications...

  • Page 12: Introduction

    Introduction MIO-2263 is a MI/O-Ultra SBC (Single Board Computer) with Embedded Intel® Atom™ SoC J1900 2.0 GHz and E3825 1.33 GHz Processor. The MIO-2263 can support DDR3L memory up to 8 GB, has one USB 3.0 and 3 USB2.0 compatible ports, one GbE (up to 1000 Mbps) interface, LVDS and VGA or HDMI support, HD (High Definition) audio, and one half size mini-PCIe and MIOe expansion slot.

  • Page 13: Functional Specifications

    Transmission speed up to 480 Mbps (USB 2.0) / 5 Gbps (USB 3.0)  Full ACPI (Advanced Configuration and Power Interface) 3.0  Supports S0, S3, S4, S5 Power Management  Support wake on LAN BIOS AMI EFI 64 Mbit Flash BIOS via SPI MIO-2263 User Manual...

  • Page 14: Mechanical Specifications

    Max in Windows 8 HCT12 (10 minutes):  J1900: 1.04 A @ 12 V (12.48 W) E3825: 0.76 A @ 12 V (9.12 W) 1.2.4.3 RTC Battery Typical Voltage: 3.0 V  Normal discharge capacity: 210 mAh  MIO-2263 User Manual...

  • Page 15: Environmental Specifications

    HD Audio Line-out AMI BIOS 12Vsb/5Vsb Line-in ALC888S HD Audio Reset Line-out SMBus SMBus RJ45 Intel i210 PCIe x1 USB Hub 2 x USB 2.0 2 x USB2.0 COM1: RS-232/422/485 COM2: RS-232 8-bit GPIO Super I/O Watchdog Timer MIO-2263 User Manual...
  • Page 16 MIO-2263 User Manual...

  • Page 17: Chapter 2 H/W Installation

    Chapter H/W Installation This chapter explains the setup procedures of the MIO-2263 hard- ware, including instructions on setting jumpers and connecting peripherals, as well as switches, indicators and mechanical draw- ings. Be sure to read all safety precautions before you begin the...

  • Page 18: Jumpers

    LCD Power / Auto Power on 2.1.3 Jumper Settings Table 2.2: J1: LCD Power/Auto Power on Part Number 1653003260 Footprint HD_3x2P_79 Description PIN HEADER 3*2P 180D(M) 2.0mm SMD SOUARE PIN Setting Function (1-2) (3-4) (default) +3.3V (5-6) (default) Auto Power On MIO-2263 User Manual...

  • Page 19: Connectors

    Battery 2.2.2 Connector Settings 2.2.2.1 Battery Connector (BH1) MIO-2263 supports Lithium 3 V/210 mAH CR2032 battery with wire via battery con- nector (BH1). Note! How to clear CMOS: (Must follow below steps) 1. Turn off system power 2. Unplug CR2032 battery cable on BH1 3.
  • Page 20 2.2.2.9 Mini PCIe Connector (CN16) MIO-2263 supports a half size mini PCIe slot. PCI Express Mini Card (also known as Mini PCI Express, Mini PCIe, and Mini PCI-E) is a replacement for the Mini PCI form factor based on PCI Express. It is developed by the PCI-SIG. The host device sup- ports both PCI Express and USB 2.0 connectivity.
  • Page 21 2.2.2.11 COM Port Connectors (CN20) MIO-2263 provides two serial ports in 10 x 2pin pin header. COM2 is for RS-232 and COM1 is for RS-232/422/485 functionality. It provides connections for serial devices or a communication network. The pin assignments for the COM port connector can be found in Appendix.

  • Page 22: Mechanical

    2.3.1 Jumper and Connector Locations CN11 CN13 CN27 CN31 CN20 Figure 2.1 Jumper and Connector layout (Top side) CN11 CN19 CN24 CN14 CN29 CN16 CN30 CN33 CN18 CN9 CN15 Figure 2.2 Jumper and connector layout (Bottom side) MIO-2263 User Manual...

  • Page 23: Board Dimensions

    57.70 45.35 34.10 29.41 26.83 3.25 3.25 unit: mm Figure 2.3 Board dimension layout (Top side) 69.60 68.75 62.16 34.55 27.86 15.62 6.83 10.92 10.87 3.63 3.25 3.25 unit: mm Figure 2.4 Board dimension layout (Bottom side) MIO-2263 User Manual...

  • Page 24: Figure 2.7 Board Dimension Layout (Coastline With Optional Dc Jack)

    Figure 2.5 Board dimension layout (coastline with power connector and heatsink) 104.36 16.51 40.56 65.40 83.31 Figure 2.6 Board dimension layout (coastline with Power connector and optional heatspreader) 104.36 46.23 17.27 40.56 65.40 83.31 Figure 2.7 Board dimension layout (coastline with optional DC/jack) MIO-2263 User Manual...

  • Page 25: Figure 2.8 Mi/O Module Height Constraints

    Constraint of components' max. height of MI/O module base on 16 mm height MIOe connector. If needed, there's a 19 mm height con- nector as well. The height of power connector (including of cable) on MIO-2263 should be considered when assembling the system or stacking the MI/O module.

  • Page 26: Figure 2.9 Illustration Of Heat Spreader Assembly

    2.3.2.3 Another Thermal Solution - Heat Spreader MIO-2263 has an optional heat spreader to make whole system more compact. Using a heat spreader to conduct heat to your chassis can help a lot when the sys- tem is extra compact or has limited space for heat convection. Here are some guide-...

  • Page 27: Chapter 3 Bios Settings

    Chapter BIOS Settings...

  • Page 28: Bios Setup

    AMIBIOS has been integrated into many motherboards for over a decade. With the AMIBIOS Setup program, users can modify BIOS settings and control various sys- tem features. This chapter describes the basic navigation of the MIO-2263 BIOS setup screens. AMI's BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration.

  • Page 29: Entering Setup

    BIOS supports your CPU. If there is no number assigned to the patch code, please contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that your CPU's system status is valid.

  • Page 30: Advanced Bios Features Setup

    3.2.2 Advanced BIOS Features Setup Select the Advanced tab from the MIO-2263 setup screen to enter the Advanced BIOS Setup screen. Users can select any item in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. Users can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 31 OS. ACPI Sleep State  Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Lock Legacy Resources  Enables or Disables Lock of Legacy Resources MIO-2263 User Manual...
  • Page 32 3.2.2.2 Super I/O Configuration Serial Port 1 Configuration  Set Parameters of Serial Port 1 (COMA) Serial Port 2 Configuration  Set Parameters of Serial Port 2 (COMB) MIO-2263 User Manual...
  • Page 33 3.2.2.3 H/W Monitor Pc Health Status  This page displays all the information about system Temperature/Voltage. MIO-2263 User Manual...
  • Page 34 S5 RTC Wake Settings Wake system with Fixed Time  Enable or disable System wake on alarm event. Selecting FixedTime, system will wake on the hr:min:sec specified. Selecting DynamicTime, System will wake on the current time + Increase minute(s). MIO-2263 User Manual...
  • Page 35 Serial Port Console Redirection Console Redirection  This item allows users to enable or disable console redirection for Microsoft Windows Emergency Management Services (EMS). Console Redirection  This item allows users to configure console redirection detail settings. MIO-2263 User Manual...
  • Page 36 OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3.) Intel Virtualization Technology  When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. Power Technology  Enables power management features. MIO-2263 User Manual...
  • Page 37 3.2.2.7 PPM Configuration CPU C state Report  Enable/Disable CPU C state report to OS Max CPU C-state  This option controls Max C states that the processor will support S0ix  Enable/Disable CPU S0ix state MIO-2263 User Manual...
  • Page 38 SATA Speed Support  SATA Speed Supports Gen1 or Gen2 SATA ODD Port  SATA ODD is Port0 or Port1 SATA Mode  Select IDE / AHCI Serial-ATA Port 0  Enable / Disable Serial ATA Port 0 MIO-2263 User Manual...
  • Page 39 3.2.2.9 Miscellaneous Configuration OS Selection  OS Selection to choose Windows 8.X / Windows 7 MIO-2263 User Manual...
  • Page 40  Controls the execution of UEFI and Legacy Storage OpROM Video  Controls the execution of UEFI and Legacy Video OpROM Other PCI devices  Determines OpROM execution policy for devices other than Network, Storage, or Video MIO-2263 User Manual...
  • Page 41 Enables or Disables BIOS support for security device. OS will not show Security Device. TCG EFI protocol and INT1A interface will not be available. MIO-2263 doesn’t include TPM device. If the client require TPM function of MIO- 2263, please contact with Advantech.Co. directly for more details.
  • Page 42 Maximum time the device will take before it properly report itself to the host con- troller. “Auto” uses default value: for a Root port it is 100 ms, for a hub port the delay is taken from hub descriptor. MIO-2263 User Manual...
  • Page 43 Send EOP Message before entering the OS. TXE Unconfiguration Perform  Revert TXE settings to factory defaults. Intel(R) AT  Enable/Disable BIOS AT code from running. Intel(R) AT Platform PBA  Enable/Disable BIOS AT code from running. MIO-2263 User Manual...

  • Page 44: Chipset Configuration

    3.2.3 Chipset Configuration North Bridge  Details for North Bridge items. LVDS Config Select  Detail for display items. MIO-2263 User Manual...
  • Page 45 3.2.3.1 North Bridge Intel IGD Configuration  Config Intel IGD settings. Graphics Power Management Control  Graphics Power Management Control options LCD Control  LCD Control Max TOLUD  Maximum value of TOLUD MIO-2263 User Manual...
  • Page 46 Select DVMT 5.0 total graphic memory size used by the internal graphics device. Aperture Size  Select the aperture size GTT Size  Select the GTT size IGD Thermal  Enable/Disable IGD thermal Spread Spectrum clock  Enable/Disable spread spectrum clock MIO-2263 User Manual...
  • Page 47 3.2.3.3 Graphics Power Management Control RC6 (Render Standby)  Check to enable render standby support. MIO-2263 User Manual...
  • Page 48 Select the video device which will be activated during POST. This has no effect if external graphics are present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on the primary dis- play. LVDS Panel Type  MIO-2263 User Manual...
  • Page 49 Enable or Disable boot option for LAN1 controller. PCIE Wake  Enable or Disable PCIE to wake the system from S5. Restore AC Power Loss  Select AC power state when the power is re-applied after a power failure. Serial IRQ Mode  MIO-2263 User Manual...
  • Page 50 Enabled = Azalia will be unconditionally Enabled. Auto = Azalia will be enabled if present disabled otherwise. Azalia HDMI Codec  Enable/Disable internal HDMI codec for Azalia HDMI Port B  Enable/Disable HDMI Port B HDMI Port C  Enable/Disable HDMI Port C MIO-2263 User Manual...
  • Page 51 Control the USB EHCI (USB 2.0) functions. One EHCI controller must always be enabled. USB Per Port Control  Control each of the USB ports (0~3). Enable: Enable USB per port; Disable: Use USB port X settings. MIO-2263 User Manual...
  • Page 52 3.2.3.8 PCI Express Configuration PCI Express Port 0  Enable or Disable the PCI Express Port 0 in the chipset. Hot Plug  Enable or disable PCI Express Hot Plug. Speed  Configure PCIe port speed MIO-2263 User Manual...

  • Page 53: Security

    3.2.4 Security Select Security Setup from the MIO-2263 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>:...

  • Page 54: Boot

    Fast Boot  Enables or disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options. Boot Option #1  Sets the system boot order. MIO-2263 User Manual...

  • Page 55: Save & Exit

    This item allows you to save the changes done so far as user defaults. Restore User Defaults  This item allows you to restore the user defaults to all the options. Boot Override  Boot device select can override your boot priority. MIO-2263 User Manual...
  • Page 56 MIO-2263 User Manual...

  • Page 57: Chapter 4 S/W Introduction & Installation

    Chapter S/W Introduction & Installation...

  • Page 58: S/W Introduction

    S/W Introduction The mission of Advantech Embedded Software Services is to "Enhance quality of life with Advantech platforms and Microsoft® Windows® embedded technology.” We enable Windows embedded software products on Advantech platforms to more effec- tively support the embedded computing community. Customers are freed from the hassle of dealing with multiple vendors (Hardware suppliers, System integrators, Embedded OS distributor) for projects.

  • Page 59: Software Apis

    However, due to the inaccuracy among many commercially available hardware mon- itoring chips, Advantech has developed a unique scheme for hardware monitoring - achieved by using a dedicated micro-processor with algorithms specifically designed for providing accurate, real-time and reliable data content; helping protect your sys- tem in a more reliable manner.

  • Page 60: Susi Installation

    If a previous version is located, please see the [Maintenance Setup] section. If it is not located, an alternative window appears. Click Next. MIO-2263 User Manual...

  • Page 61: Susi Sample Programs

    You can click function tabs to select test functions respectively. Some function tabs will not show on the test application if your platform does not support such functions. For a complete support list, please refer to Appendix A. We describe the steps to test all functions of this application. MIO-2263 User Manual...
  • Page 62 Key in the pin numbers you want to write. Pin numbers start from '0'. – Key in the value either '0' or '1' in (R/W) Result field to write the output pin you chose above step. – Click the WRITE GPIO DATA button to write the GPIO output pin. MIO-2263 User Manual...
  • Page 63 Key in the slave device address in the Slave address field. – Key in the register offset in the Register Offset field. – Click the READ SMBus DATA button and a byte of data from the device will be shown on the Result field. MIO-2263 User Manual...
  • Page 64 Key in all the desired data in the Result field in hexadecimal format, divided by commas, for example, 0x50,0x60,0x7A. – Click the WRITE SMBus DATA button and all of the data will be written to the device through the SMBus. MIO-2263 User Manual...
  • Page 65 Move the slider in increments, using either the mouse or the direction keys, or click the UP button to increase the brightness. – Move the slider in decrements, using either the mouse or the direction keys, or click the DOWN button to decrease the brightness. MIO-2263 User Manual...
  • Page 66 Before the timer counts down to zero, you can reset the timer by clicking the REFRESH button. After you click this button, the Timeout Countdown field will display the value of the SET TIMEOUT field.  If you want to stop the watchdog timer, just click the STOP button. MIO-2263 User Manual...
  • Page 67 If certain data values are not supported by the platform, the correspondent data field will be grayed-out with a value of 0. For more details on MIO-2263 software API, please contact your dealer or Advantech MIO-2263 User Manual...
  • Page 68 MIO-2263 User Manual...

  • Page 69: Appendix Apin Assignments

    Appendix PIN Assignments...

  • Page 70: Jumper Setting

    SMBus Battery Table A.3: J1: LCD Power/Auto Power On Part Number 1653003260 Footprint HD_3x2P_79 Description PIN HEADER 3*2P 180D(M) 2.0mm SMD SOUARE PIN Setting Function (1-2) +5 V (3-4) (default) +3.3 V (5-6) (default) Auto Power On MIO-2263 User Manual...
  • Page 71 PJ_3P_DCJ-RPBT5NW-25 Description Pin Name +VIN 12V Power Input ( 2 x 3 pin support by request) Part Number 1655000025 Footprint WF_3x2P_79_BOX_D Description Pin Name +12V +12V +12V DDR3L SO-DIMM Part Number 1651002083 Footprint DDR3_204P_AS0A626-JA Description Pin Name MIO-2263 User Manual...
  • Page 72 PIN HEADER SMD 5*2P 180D(M) 2.0 mm Pin Name +5 V GPIO4 GPIO0 GPIO5 GPIO1 GPIO6 GPIO2 GPIO7 GPIO3 CN11 Part Number 1654000055 Footprint DBVGA-VF5MS Description D-SUB Conn. 15P 90D(F) DIP 070242FR015S200ZU Pin Name GREEN BLUE DDAT HSYNC VSYNC DCLK MIO-2263 User Manual...
  • Page 73 HMDP_TX2+ HMDP_TX2- HMDP_TX3+ HMDP_TX3- HMDP_DCLK HMDP_DDAT +5V Power Hot Plug Detect CN13 Front Panel Part Number 1653004883 Footprint HD_3x2P_79_RA_21N22050 Description Pin Name Power Button Pin1 Power LED+ Power/Reset Button Pin2 HDD LED+ Reset Button Pin1 HDD LED- MIO-2263 User Manual...
  • Page 74 CN14 SATA Part Number 1654011616-01 Footprint SATA_7P_WATF-07DBN6SB1U Description Pin Name CN15 mSATA Part Number 1654002538 Footprint MINIPCIE_HALF_PICO_ITX Description Pin Name +3.3V +1.5V MIO-2263 User Manual...
  • Page 75 +3.3V CN15 mSATA Part Number 1654002538 Footprint MINIPCIE_HALF_PICO_ITX Description Pin Name +1.5V SMB_CLK SMB_DAT +3.3V +3.3V +1.5V +3.3V MIO-2263 User Manual...
  • Page 76 CN16 Mini PCIe Part Number 1654002538 Footprint MINIPCIE_HALF_PICO2600 Description Pin Name WAKE# +3.3VSB +1.5V REFCLK- REFCLK+ PERST# PERn0 +3.3VSB PERp0 MIO-2263 User Manual...
  • Page 77 CN16 Mini PCIE Part Number 1654002538 Footprint MINIPCIE_HALF_PICO2600 Description Pin Name +1.5 V SMB_CLK PETn0 SMB_DAT PETp0 USB D- USB D+ +3.3 VSB +3.3 VSB +1.5 V +3.3 VSB MIO-2263 User Manual...
  • Page 78 1653005260 Footprint HD_5x2P_79_N10 Description PIN HEADER 2*5P 180D(M) 2.0 mm SMD IDIOT-PROOF Pin Name +5 V +5 V A_D- B_D- A_D+ B_D+ CN19 External USB2.0+USB3.0 Part Number 1654010199 Footprint USB_13P_UEA1112C-UHS6-4F Description Pin Name SSRX- SSRX+ SSTX- SSTX+ MIO-2263 User Manual...
  • Page 79 CN20 COM1/COM2 Part Number 1653003720 Footprint HD_10x2P_79_RA Description Pin Name DCD1# DSR1# RXD1 RTS1# TXD1 CTS1# DTR1# RI1# DCD2# DSR2# RXD2 RTS2# TXD2 CTS2# DTR2# RI2# MIO-2263 User Manual...
  • Page 80 CN24 Gigabit Ethernet Part Number 1652004356 Footprint RJ45_14P_RT7-194AAM1A Description Pin Name BI_DA+(GHz) BI_DA-(GHz) BI_DB+(GHz) BI_DC+(GHz) BI_DC-(GHz) BI_DB-(GHz) BI_DD+(GHz) BI_DD-(GHz) CN27 HD Audio Part Number 1653003719 Footprint HD_5x2P_79_RA_21N22050 Description Pin Name LOUTR LINR LOUTL LINL MIC1R MIC1L MIO-2263 User Manual...
  • Page 81 CN29 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description Pin Name PCIE_RX0+ PCIE_TX0+ PCIE_RX0- PCIE_TX0- PCIE_RX1+ PCIE_TX1+ PCIE_RX1- PCIE_TX1- MIO-2263 User Manual...
  • Page 82 MIO-2263 User Manual...
  • Page 83 CN29 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description Pin Name PCIE_CLK+ LOUTL PCIE_CLK- LOUTR AGND SMB_CLK SCI# SMB_DAT PCIE_WAKE# RESET# SLP_S3# CLK33M LPC_AD0 DDP_HPD LPC_AD1 LPC_AD2 DDP_AUX+ LPC_AD3 DDP_AUX- LPC_DRQ#0 MIO-2263 User Manual...
  • Page 84 MIO-2263 User Manual...
  • Page 85 CN29 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description Pin Name LPC_SERIRQ DDP_D0+ LPC_FRAME# DDP_D0- USB0_D+ DDP_D1+ USB0_D- DDP_D1- USB1_D+/USB_SSTX+ DDP_D2+ USB1_D-/USB_SSTX- DDP_D2- DDP_D3+ DDP_D3- USB_OC# MIO-2263 User Manual...
  • Page 86 MIO-2263 User Manual...
  • Page 87 CN29 MIOe Part Number 1654006235 Footprint BB_40x2P_32_1625x285_2HOLD Description Pin Name +12VSB +12VSB +5VSB +5VSB +5VSB +5VSB MIO-2263 User Manual...
  • Page 88 Pin Name +12V ENABKL CN31 18/24 bits LVDS Panel Part Number 1655000753 Footprint WF14P_49_BOX_RA_85204-14001 Description Pin Name LVDS0_CLK- LVDS0_CLK+ LVDS0_D3- LVDS0_D3+ LVDS0_D2- LVDS0_D2+ LVDS0_D1- LVDS0_D1+ LVDS0_D0- LVDS0_D0+ +5 V or +3.3 V +5 V or +3.3 V MIO-2263 User Manual...
  • Page 89 CN33 SMBus Part Number 1655904020 Footprint FPC4V-125M Description Wafer SMT 1.25 mm S/T type 4P 180D(M) 85205-04001 Pin Name SMB_DAT SMB_CLK +5 V MIO-2263 User Manual...
  • Page 90 MIO-2263 User Manual...

  • Page 91: Wdt & Gpio

    Appendix WDT & GPIO...

  • Page 92: Watchdog Timer Sample Code

    + 65h; mov al,080h out dx,al ;==================================================== ;66H ;WDT timer time-out value ;bit[7:0]=0~255 ;==================================================== mov dx,SCH3114_IO + 66h mov al,01h out dx,al ;==================================================== ;bit[0] status bit R/W ;WD timeout occurred =1;WD timer counting = 0 MIO-2263 User Manual...

  • Page 93: Gpio Sample Code

    ; 1 = HIGH ; 0 = LOW ;==================================================== mov dx,SCH3114_IO + 23h ;GPIO 0 mov al,00h ;Set GPIO 0 as output type out dx,al mov dx,SCH3114_IO + 4Bh mov al,01h ;Set GPIO 0 as high value. out dx,al .exit MIO-2263 User Manual...
  • Page 94 MIO-2263 User Manual...

  • Page 95: Appendix C System Assignments

    Appendix System Assignments...

  • Page 96: System I/O Ports

    Addr. Range (Hex) Device A0000h - BFFFFh IntelQ® HD Graphics A0000h - BFFFFh PCI Bus C0000h - DFFFFh PCI Bus E0000h - FFFFFh PCI Bus 90400000 - 905FFFFF Intel® Trusted Execution Engine Interface E0000000 - FEFFFFFF System resources MIO-2263 User Manual...

  • Page 97: Interrupt Assignments

    Communications Port (COM2) IRQ4 Communications Port (COM1) IRQ5 Available IRQ6 Available IRQ7 Available IRQ8 Internal RTC or HPET IRQ9 Microsoft ACPI-Compliant System IRQ10 Available IRQ11 SMBus Port IRQ12 Available IRQ13 Numeric data processor IRQ14 SATA controller IRQ15 SATA controller MIO-2263 User Manual...
  • Page 98 No part of this publicati on may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2014...
