MIC-3369C
MIC-3369C 6U CompactPCI
Intel® Pentium® M Processor
Board with VGA/Dual Giga LAN/
PMC
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIC-3369C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech MIC-3369C

Summary of Contents for Advantech MIC-3369C

  • Page 1 MIC-3369C MIC-3369C 6U CompactPCI Intel® Pentium® M Processor Board with VGA/Dual Giga LAN/ User’s Manual...
  • Page 2 All other product names or trademarks are properties of their respective owners. Technical Support and Sales Assistance If you have any technical questions about the MIC-3369C or any other Advantech products, please visit our support website at: http://support.advantech.com.tw For more information about Advantech's products and sales information, please visit: http://www.advantech.com.

  • Page 3: Product Warranty

    CE Notification The MIC-3369C, developed by Advantech CO., LTD., has passed the CE test for environment specification when shielded cables are used for external wiring. We recommend the use of shielded cables. Product warranty Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for one year from the date of purchase.

  • Page 4: Packing List

    Packing List Before installing your board, ensure that the following materials have been received: • 1 MIC-3369C all-in-one single board computer • 1 Utility CD-ROM disc • 1 CPU Heat sink (Assembled) • 1 CPU thermal dissipation paste • 1 Thermal pad (Assembled) •...
  • Page 5 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. CAUTION!! Danger of explosion if battery in correctly replaced. The battery need not to be charged. Replace only with Advantech-specified batteries.
  • Page 6 MIC-3369C User’s Manual...

  • Page 7: Table Of Contents

    Chapter 1 Hardware Configuration .........2 Introduction ............... 2 Specifications ..............4 Functional Block Diagram ..........6 Figure 1.1:MIC-3369C functional block diagram..6 Jumpers................7 1.4.1 Jumper Locations............7 Table 1.1:MIC-3369C jumper descriptions ....7 Table 1.2:JP2 jumper (PMC Module Voltage VIO)..7 Table 1.3:JP5 (PCI-to-PCI Bridge &...
  • Page 8 PS/2 Keyboard and Mouse Connector (Rear I/O)... 27 Serial Ports (CN3 and Rear I/O) ........27 Table 2.1:MIC-3369C serial port default settings ..27 Ethernet Configuration (PU1 or Rear I/O or J3) ..... 28 USB Connector (CN4/5 and Rear I/O) ......28 PMC Connector (J11, J12, J13, J14).......
  • Page 9 Chapter 4 Award BIOS Setup.........50 AWARD BIOS Setup............50 Figure 4.1:Setup program initial screen......50 4.1.1 Entering Setup............... 50 4.1.2 Standard CMOS Setup..........51 Figure 4.2:Standard CMOS setup screen...... 51 4.1.3 Advanced BIOS Features Setup ........52 Figure 4.3:Advanced BIOS features setup screen ..52 4.1.4 Advanced Chipset Features Setup ........
  • Page 10 MIC-3369 User’s Manual...
  • Page 11 Hardware Configuration...

  • Page 12: Chapter 1 Hardware Configuration

    ECC DDR200 memory on-board. High Performance Intel Pentium M Processor The MIC-3369C supports a 1.8 GHz Intel Pentium M 745 processor and a 1.6 GHz Pentium M processor with the u-FCPGA package. The Intel Pentium M 745 processor has 2 MB L2 cache and Pentium M 1.6GHz processor has 1MB L2 cache providing high performance.
  • Page 13 MIC-3369C can also operate a peripheral slot in drone mode, so that the peripheral card functions as a stand-alone computer and does not commu- nicate on the CompactPCI bus. PMC (PCI Mezzanine Card) IEEE1386.1 Compliant The MIC-3369C supports one PMC site and compliant with PICMG 2.3 (PCI Mezzanine Card) specification.

  • Page 14: Specifications

    • Controller chip: One controller chip provides master/ drone mode • In Master mode: Supports up to seven bus master peripherals on each bus segment • In Drone mode: Plugs into a peripheral slot as a "drone mode" , whereby it functions as a stand-alone computer. MIC-3369C User’s Manual...
  • Page 15 65K colors 1600x1200 16.7M colors 1280x1024 Note: MIC-3369C does not support MIC-3960 storage carrier board Mechanical and Environmental Specifications • Operating temperature: 0 ~ 55° C (32 ~ 131° F) • Storage Temperature: -20 ~ 80° C (-4 ~ 176° F) •...

  • Page 16: Functional Block Diagram

    Chipset LPC Bus Ultra I/O BIOS CPLD Universal Compact SMSC RageXL PCI Bridge Flash LPC47B27 LAN3 KB/Mouse PCI Bus 64bit/66MHz COM/Printer/FDD Figure 1.1: MIC-3369C functional block diagram. Note: MIC-3369C does not support ATX power supply shutdown function. MIC-3369C User’s Manual...

  • Page 17: Jumpers

    1.4.1 Jumper Locations Table 1-1 lists the jumper function. Figure 1-2 illustrates the jumper loca- tion. Read this section carefully before changing the jumper setting on your MIC-3369C card. Table 1.1: MIC-3369C jumper descriptions Number Function PMC Module voltage VIO...

  • Page 18: Table 1.4:Jp7 (Compactflash Card)

    Table 1.4: JP7 (CompactFlash card) Master Slave (Default) Table 1.5: JP8 (VGA Output) VGA output in Rear IO VGA output in Front panel of MIC-3369C Table 1.6: JP9 (PCI-to-PCI bridge clock frequency) 33MHz 66MHz Table 1.7: JP10 (FSB frequency select) 400MHz 533MHz MIC-3369C User’s Manual...

  • Page 19: Clearing Cmos Memory (Jp6)

    1.4.2 Clearing CMOS Memory (JP6) This jumper is used to erase CMOS data and reset system BIOS informa- tion. Follow the procedures below to clear the CMOS. 1. Turn off the system. 2. Close jumper JP6 (1-2) for about 3 seconds. 3.

  • Page 20: Figure 1.2:Connectors

    Figure 1.2: Connectors Note: The handle is usually closed MIC-3369C User’s Manual...

  • Page 21: Connectors

    On-board connectors link to external devices such as hard disk drives, keyboards, or floppy drives, etc. Table 1.9 lists the function of each con- nector. Chapter 2 gives instructions for connecting external devices to your card. Table 1.9: MIC-3369C connector descriptions Number Function Handle Switch...

  • Page 22: Table 1.11:Cn3 Rj-45 Com1 Port Definitions

    Table 1.11: CN3 RJ-45 COM1 port definitions Signal NRLSD1 NRX1 NTX1 NDTR1 NDSR1 NRTS1 NCTS1 Table 1.12: CN4 USB2.0 port definitions Signal USB_P1- USB_P1+ MIC-3369C User’s Manual...

  • Page 23: Table 1.13:Cn5 Usb2.0 Port Definitions

    Table 1.13: CN5 USB2.0 port definitions Signal USB_P2- USB_P2+ Table 1.14: CN6 IDE port definitions Signal Signal PRST# PID7 PID8 PID6 PID9 PID5 PID10 PID4 PID11 PID3 PID12 PID2 PID13 PID1 PID14 PID0 PID15 PDRQ# PIOW# PIOR# PRDY CSEL* PACK# PIRQ PDA1 PDIAG#**...

  • Page 24: Table 1.15:Cn9 Compactflash Socket Definitions

    *: CSEL connects to GND **: PDIAG# had 10Kohm pull down to GND Table 1.15: CN9 CompactFlash socket definitions Signal Signal ID11 ID12 ID13 ID14 ID15 HCS1 HCS3- HIOR- HIOW- HIRQ SANDISK -HRST1 HRDY GDA2 HDA1 HDA0 SANLED ID10 MIC-3369C User’s Manual...

  • Page 25: Table 1.16:Cn7 Vga Connector Definitions

    Table 1.16: CN7 VGA connector definitions Signal GREEN BLUE N/C (VGAVCC) VGA_SDA HSYNC VSYNC VGA_SCL Table 1.17: PU1 Gigabit LAN connector definitions Signal MDIAX1+ MDIAX1- MDIAX2+ MDIAX3+ MDIAX3- MDIAX2- MDIAX4+ MDIAX4- Chapter 1...

  • Page 26: Table 1.18:Pmc (J11/12/J13/J14) Connectors

    PIN# Single Name PIN# Single Name -12V INTC# INTD# INTA# BUSMODE1 INTB# GNT4# REQ4# V(I/O) AD31 AD28 AD27 AD25 C/BE3# AD22 AD21 AD19 V(I/O) AD17 FRAME# IRDY# DEVSEL# LOCK# SDONE# SBO# V(I/O) AD15 AD12 AD11 C/BE0# V(I/O) MIC-3369C User’s Manual...
  • Page 27 REQ64# J12 PIN SIGNAL PIN# Single Name PIN# Single Name +12V TRST# BUSMODE2# +3.3V RST# BUSMODE3# +3.3V BUSMODE4# AD30 AD29 AD26 AD24 +3.3V IDSEL(AD19) AD23 +3.3V AD20 AD18 AD16 C/BE2# TRDY# +3.3V STOP# PERR# +3.3V SERR# C/BE1# AD14 AD13 AD10 +3.3V +3.3V ACK64#...
  • Page 28 AD55 AD54 AD53 AD52 AD51 AD50 AD49 AD48 AD47 AD46 AD45 V(I/O) AD44 AD43 AD42 AD41 AD40 AD39 AD38 AD37 AD36 AD35 AD34 AD33 V(I/O) AD32 J14 PIN SIGNAL PIN# Single Name PIN# Single Name +5Vaux +5Vaux MIC-3369C User’s Manual...

  • Page 29: Table 1.19:D8 Led Definitions

    BMC_PWR_ON/OFF BMC_PWROK PMC_OS_SHUTDOWN BMC_BD_SEL# CMM1_SCL CMM1_SDA CMM2_SCL CMM2_SDA BMC_BD_SEL BMC_LEDA BMC_LEDL BMC_TX+ BMC_RX+ BMC_TX- BMC_RX- Table 1.19: D8 LED definitions Green Power Status Yellow HDD Status Table 1.20: SW1 Drone Mode definitions SW-1 selects PCI-to-PCI bridge EEPROM enabled or disabled. When you set to "ON", it is enabled.
  • Page 30 Figure 1.3: MIC-3369C Jumper and connector locations MIC-3369C User’s Manual...

  • Page 31: Figure 1.4:Front Panel Connector/Indicator Locations

    Figure 1.4: Front panel connector/indicator locations 1.6 Safety Precautions Follow these simple precautions to protect yourself from harm and the products from damage. 1. To avoid electric shock, always disconnect the power from your PC chassis before you work on it. Don't touch any components on the CPU card or other cards while the PC is on.

  • Page 32: Installing Cpu And Heat Sink

    1.7 Installing CPU and Heat Sink The MIC-3369C supports the Intel Pentium M processor. In order to meet critical environmental conditions and the physical space of the MIC- 3369C at the same time, Advantech has designed a heatsink to fulfill its primary needs.

  • Page 33: Figure 1.5:Complete Assembly, Heatsink And Hdd

    Figure 1.5: Complete assembly, heatsink and HDD 1.8 Software support The MIC-3369C comes with a utility CD-ROM disc, which includes drivers and utility programs for Gigabit Ethernet, IAA and VGA inter- faces. The drivers support Windows 2000, XP and NT 4.0 Operation sys- tems.
  • Page 34 MIC-3369C User’s Manual...
  • Page 35 Connecting Peripherals...

  • Page 36: Chapter 2 Connecting Peripherals

    2.1 IDE Device (CN6 and Rear I/O) The MIC-3369C provides two IDE (Integrated Device Electronics) chan- nels via a CN6 connector in the MIC-3369C or via the J3 connector to the rear transition board (RIO-3309C or RIO-3309S). CN6 connector support one 2.5"...

  • Page 37: Ps/2 Keyboard And Mouse Connector (Rear I/O)

    2.5 Serial Ports (CN3 and Rear I/O) The MIC-3369C offers one serial port: COM1 in RS-232. With limited front panel access, one COM1 (CN3) can be connected via a RJ-45 to RS- 232 adaptor and COM2 (CN9) interface has to be connected via rear I/O module (RIO-3309C or RIO-3309S).

  • Page 38: Ethernet Configuration (Pu1 Or Rear I/O Or J3)

    2.7 USB Connector (CN4/5 and Rear I/O) The MIC-3369C provides two USB (Universal Serial Bus) 2.0 channels either via two front USB ports (CN4 and CN5) in MIC-3369C or via J5 connector to one USB connector (CN8) in rear transition board. The USB interface gives complete plug and play, hot attach/detach for up to 127 external devices.

  • Page 39: Card Installation

    Improper installation of a card can easily damage the backplane of the chassis. The install/eject handles of the MIC-3369C help you install and remove the card easily and safely. Follow the procedure below to install the MIC-3369C into a chassis: To install a card: 1.
  • Page 40 MIC-3369C User’s Manual...
  • Page 41 Driver Setup...

  • Page 42: Chapter 3

    Microsoft for USB driver support. Intel manufactures the host controller but the driver is from Microsoft. While users installed Intel INF driver, it will not install USB driver. Please go to "device man- ager" to update USB driver via Advantech CD utility or via Microsoft website. Note: There are no separate USB (version 1.1 and...

  • Page 43: Cmm (Chassis Management Module) Driver

    3.3 CMM (Chassis Management Module) Driver MIC-3369C supports MIC-3924B CMM. Please install the driver accord- ing to the following procedure. 3.3.1 Windows 2K Driver Figure 3.1: R. Click "My Computer" --> "Properties" Figure 3.2: Tab "Hardware">"Hardware Wizard" Chapter 3...

  • Page 44: Figure 3.3:Click "Next" In Hardware Wizard

    Figure 3.3: Click "Next" in Hardware Wizard Figure 3.4: Click "Add/Troubleshoot a device" MIC-3369 User’s Manual...

  • Page 45: Figure 3.5:Select "Add A New Device

    Figure 3.5: Select "Add a new device" Figure 3.6: Click "No, I want to select...” Chapter 3...

  • Page 46: Figure 3.7:Select "Other Devices

    Figure 3.7: Select "Other devices" Figure 3.8: Tab "Have Disk" at bottom MIC-3369 User’s Manual...

  • Page 47: Figure 3.9:Browse For Driver

    Figure 3.9: Browse for driver Figure 3.10: Click OK Chapter 3...

  • Page 48: Figure 3.11:Click "Ok" In Add New Hardware

    Figure 3.11: Click "OK" in Add New Hardware Figure 3.12: Click "Yes" in Forced Configuration MIC-3369 User’s Manual...

  • Page 49: Figure 3.13:Click "Next" In Add/Remove Hardware

    Figure 3.13: Click "Next" in Add/Remove Hardware Figure 3.14: Tab "Finish" in Add/Remove Hardware Chapter 3...

  • Page 50: Figure 3.15:Click "Yes" To Restart Your Computer

    Figure 3.15: Click "Yes" to restart your computer Figure 3.16: Browse A-IPM drivers MIC-3369 User’s Manual...

  • Page 51: Windows Xp Driver

    3.3.2 Windows XP Driver Figure 3.17: Right-click “My Computer”>”Properties" Figure 3.18: "Hardware">"Add Hardware Wizard" Chapter 3...

  • Page 52: Figure 3.19:Click "Next

    Figure 3.19: Click "Next" Figure 3.20: Click "Yes" MIC-3369 User’s Manual...

  • Page 53: Figure 3.21:Select "Add A New Hardware Device

    Figure 3.21: Select "Add a new hardware device" Figure 3.22: Click “Install the hardware...” Chapter 3...

  • Page 54: Figure 3.23:Select "Show All Devices

    Figure 3.23: Select "Show all devices" Figure 3.24: Tab "Have Disk" MIC-3369 User’s Manual...

  • Page 55: Figure 3.25:Browse For Driver

    Figure 3.25: Browse for driver Figure 3.26: Tab “A-IPM driver”>"Have Disk" Chapter 3...

  • Page 56: Figure 3.27:Click "Next

    Figure 3.27: Click "Next" Figure 3.28: Click "Finish" MIC-3369 User’s Manual...

  • Page 57: Figure 3.29:"My Computer">"A-Ipm Drivers

    Figure 3.29: “My computer”>"A-IPM drivers" Chapter 3...
  • Page 58 MIC-3369 User’s Manual...
  • Page 59 Award BIOS Setup...

  • Page 60: Chapter 4 Award Bios Setup

    Turn on the computer and check for the "patch code". If there is a number assigned to the patch code, it means that the BIOS supports your CPU. If there is no number assigned to the patch code, please contact Advantech's application engineer to obtain an up-to-date patch code file. This will ensure that your CPU's system status is valid.

  • Page 61: Standard Cmos Setup

    4.1.2 Standard CMOS Setup The items in Standard CMOS Setup Menu are divided into 11 categories. Each category includes may include one or more setup items, or none at all. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn>...

  • Page 62: Advanced Bios Features Setup

    4.1.3 Advanced BIOS Features Setup The "Advance BIOS FEATURES" screen will appear after the BIOS FEATURES SETUP item is chosen from the CMOS SETUP UTILITY Menu. This screen allows the user to configure the board according to his particular requirements. Below are some major items that are provided in the BIOS FEATURES SETUP screen: Figure 4.3: Advanced BIOS features setup screen Virus Warning...

  • Page 63: Swap Floppy Drive

    Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power on the computer. If this is set to Enabled, BIOS will shorten or skip some check items during POST. Enabled (default) Enable quick POST Disabled Normal POST First/Second/Third Boot Device and Boot Other Device...

  • Page 64: Gate A20 Option

    Gate A20 Option Normal The A20 signal is controlled by keyboard con- troller or chipset hardware. Fast(default) The A20 signal is controlled by port 92 or chipset specific method. Typematic Rate Setting Key strokes repeat at a rate determined by the keyboard controller. When enabled, the typematic rate and typematic delay can be selected.

  • Page 65: Advanced Chipset Features Setup

    OS Select For DRAM > 64MB Allows OS2® to be used with > 64 MB of DRAM. Settings are Non-OS/ 2 (default) and OS2. Set to OS/2 if using more than 64MB and running OS/2. Small logo (EPA) show Default is Disabled. 4.1.4 Advanced Chipset Features Setup The Advanced Chipset Features Setup option is used to change the values of the chipset registers.
  • Page 66 Video BIOS Cacheable Select Enabled allows caching of the video BIOS, resulting in better sys- tem performance. However, if any program writes to this memory area, a system error may result. The settings are: Enabled and Disabled (Default). MIC-3369 User’s Manual...

  • Page 67: Figure 4.5:Dram Timing Control Setup Screen

    Memory Hole At 15M-16M You can reserve this area of system memory for ISA adapter ROM. When this area is reserved, it cannot be cached. The user information of periph- erals that need to use this area of system memory usually discusses their memory requirements.

  • Page 68: Integrated Peripherals

    Active to Precharge Delay This field let you select active to precharge delay. The settings are: 7, 6 and 5 DRAM RAS# to CAS# Delay This field lets you insert a timing delay between the CAS and RAS strobe signals, used when DRAM is written to, read from, or refreshed. Fast gives faster performance;...

  • Page 69: Figure 4.7:Onchip Ide Device Setup Screen

    Figure 4.7: OnChip IDE Device setup screen IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/writes per sector the drive can support.

  • Page 70: Figure 4.8:Onboard Device Setup Screen

    IDE Primary/Secondary Master/Slave UDMA Ultra DMA/33 implementation is possible only if your IDE hard drive supports it and the operating environment includes a DMA driver (Win- dows 95 OSR2 or a third-party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/33 and Ultra DMA/66 and Ultra DMA/100, select Auto to enable BIOS support.

  • Page 71: Figure 4.9:Superio Device Setup Screen

    SMBus Connector Users can select IPMI source and application as below. Source connected CMM PCF8584T MIC-3924B Hardware Monitor 83782D MIC-3924A BMC (PMC type) (Reserved) CMM (Reserved) There are 3 options: MIC-3924B (Default), MIC-3924A and CMM. LAN 1 Connector The item allows you to choice LAN1 connective way. There are 3 options: Front (Default), 2.16 and Rear LAN 2 Connector The item allows you to choice LAN2 connective way.

  • Page 72: Onboard Parallel Port

    Onboard Serial Port 1/Port 2 Select an address and corresponding interrupt for the first and second serial ports. The Serial Port 1 settings are: 3F8/IRQ4 (Default), 2E8/ IRQ3, 3E8/IRQ4, 2F8/ IRQ3, Disabled, Auto. The Serial Port 2 settings are: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/ IRQ3 (Default), Disabled, Auto.

  • Page 73: Power Management Setup

    ECP Mode Use DMA The options: 1 and 3 (Default) 4.1.6 Power Management Setup The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. Figure 4.10: Power management setup screen ACPI Function This category allows you to select ACPI power management effective or...

  • Page 74: Pnp/Pci Configuration Setup

    4.1.7 PNP/PCI Configuration Setup This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.

  • Page 75: Pc Health Status

    When resources are controlled manually, assign each system interrupt a type, depending on the type of device using the interrupt. PCI/VGA Palette Snoop Leave this field at Disabled. The settings are Enabled, Disabled (Default). 4.1.8 PC Health Status This section shows the Status of you CPU, Fan, Warning for overall sys- tem status.

  • Page 76: Save & Exit Setup

    To change, confirm, or disable the password, choose the "PASS-WORD SETTING" option form the Setup main menu and press [Enter]. The password can be at most 8 characters long. Remember, to enable this fea- ture. You must first select the Security Option in the Advance BIOS FEA- TURES SETUP to be either "Setup"...
  • Page 77 Programming Watch- dog Timer...

  • Page 78: Appendix A Programming The Watchdog Timer

    Appendix A Programming the Watchdog Timer A.1 Programming the Watchdog Timer To program the watchdog timer, you must write a program which writes a value to I/O port address 443 (hex). The output value represents a time interval. The value range is from 01 (hex) to FF (hex), and the related time intervals are 1 sec.
  • Page 79 Pin Assignments...

  • Page 80: B.1 J1 Connectors

    Appendix B Pin Assignments B.1 J1 Connectors Table B.1: J1 connector REQ64# ENUM# +3.3V AD[1] V(I/O) AD[0] ACK64# +3.3V AD[4] AD[3] AD[2] AD[7] +3.3V AD[6] AD[5] +3.3V AD[9] AD[8] M66EN C/BE[0]# AD[12] V(I/O) AD[11] AD[10] +3.3V AD[15] AD[14] AD[13] SERR# +3.3V C/BE[1]# +3.3V...

  • Page 81: J2 Connector

    B.2 J2 Connector Table B.2: J2 connector CLK6 CLK5 RSV (SMBB_SDA) RSV (SMBB_SCL) PRST# REQ6# GNT6# REQ5# GNT5# AD[35] AD[34] AD[33] AD[32] AD[38] V(I/O) AD[37] AD[36] AD[42] AD[41] AD[40] AD[39] AD[45] V(I/O) AD[44] AD[43] AD[49] AD[48] AD[47] AD[46] AD[52] V(I/O) AD[51] AD[50] AD[56]...

  • Page 82: J3 Connector

    B.3 J3 Connector Table B.3: J3 connector MDIA0+ MDIA0- MDIA2+ MDIA2- MDIA1+ MDIA1- MDIA3+ MDIA3- MDIB0+ MDIB0- MDIB2+ MDIB2- MDIB1+ MDIB1- MDIB3+ MDIB3- SDD0 SDD2 SDD1 SDD3 SDD12 SDD4 SDD7 SDD5 SDD9 SDD13 SDD6 SDD8 SDD15 SDD14 SDIOR# SDD10 SDD11 IDE_PDLED RSV SDIOW# SDDREQ#...

  • Page 83: J5 Connector

    B.4 J5 Connector Table B.4: J5 connector Pin Z 22 GND BASE_RX+ BASE_RX- BASE_TX+ BASE_TX- 21 GND BMC_RX+ BMC_RX- BMC_TX+ BMC_TX- 20 GND USBD4- 19 GND USBD3- USBD4+ J4_RED 18 GND USBD3+ J4_CRT_H 17 GND RIOREQ7# RIO_CLK7 J4_GREEN 16 GND USBOC3# RIOGNT7# J4_CRT_V...
  • Page 84 070-071 System CMOS / real time clock 081-083 Direct memory access controller 087-087 Direct memory access controller 089-08B Direct memory access controller 08F-091 Direct memory access controller 090-091 PCI bus 093-09F PCI bus 0A0-0A1 Programmable interrupt controller 0A2-0BF PCI bus 0C0-0DF Direct memory access controller 0D0-0EF...

  • Page 85: Interrupt Assignments

    B.6 Interrupt Assignments Table B.6: Interrupt assignments Interrupt# Interrupt source IRQ 0 (ISA) System timer IRQ 1 (ISA) PC/AT enhanced PS/2 keyboard (101/102-Key) IRQ 3 (ISA) Communications port (COM2) IRQ 4 (ISA) Communications port (COM1) IRQ 8 (ISA) System CMOS / real time clock IRQ 12 (ISA) Microsoft PS/2 mouse IRQ 13 (ISA)
  • Page 86 MIC-3369 User’s Manual...
