6u compactpci intel pentium 4 processor - m single board computer with vga / dual giga lan / pmc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MIC-3358
®
6U
CompactPCI
Intel
®
Pentium
4 Processor -
M
Single Board Computer with
VGA / Dual Giga LAN / PMC
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIC-3358 and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech MIC-3358

Summary of Contents for Advantech MIC-3358

  • Page 1 MIC-3358 ® CompactPCI Intel ® Pentium 4 Processor - Single Board Computer with VGA / Dual Giga LAN / PMC User’s Manual...
  • Page 2 All other product names or trademarks are properties of their respective owners. Technical Support and Sales Assistance If you have any technical questions about the MIC-3358 or any other Advantech products, please visit our support website at: http://support.advantech.com.tw For more information about Advantech's products and sales information, please visit: http://www.advantech.com.

  • Page 3: Product Warranty

    CE Notification The MIC-3358, developed by Advantech CO., LTD., has passed the CE test for environment specification when shielded cables are used for external wiring. We recommend the use of shielded cables. Product warranty Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for one year from the date of purchase.

  • Page 4: Packing List

    Packing List Before installing your board, ensure that the following materials have been received: • 1 MIC-3358 all-in-one single board computer • 1 Utility CD-ROM disc • 1 CPU Heat sink (Assembled) • 1 CPU thermal dissipation paste • 1 Thermal pad (Assembled) •...

  • Page 5: Table Of Contents

    Table 1.15:J11/J12/J14 PMC Connector Definitions .. 15 Table 1.16:D9 LED Definitions........18 Table 1.17:SW1 Vcore selection definitions ....18 Table 1.18:SW2 Drone mode definitions ..... 19 Figure 1.3:MIC-3358 jumper and connector locations. 20 Figure 1.4:MIC-3358 front panel connector and indicator locations21 Safety Precautions ............21 Installing CPU and Heat Sink ........
  • Page 6 PS/2 Keyboard and Mouse Connector (Rear I/O)... 26 Serial Ports (CN3 and Rear I/O) ........27 Table 2.1:MIC-3358 serial port default settings... 27 Ethernet Configuration (PU1 , Rear I/O and J3)..... 27 USB Connector (CN5/6 and Rear I/O) ......28 PMC Connector (J11, J12, J14) ........
  • Page 7 Wizard"41 Figure 3.19:Click "Next" in the windows..... 42 Figure 3.20:Click "Yes , I have already connected the hardware"42 Figure 3.21:Select "Add a new hardware device" in the installed hardware window43 Figure 3.22:Click Install the hardware that I manually se- lect from a list (Advanced)43 Figure 3.23:Select "Show all devices"...
  • Page 8 J2 Connector..............71 Table B.2:J2 connector ..........71 J3 Connector..............72 Table B.3:J3 connector ..........72 J5 Connector..............73 Table B.4:J5 connector ..........73 System I/O Ports.............. 74 Table B.5:System I/O ports .......... 74 Interrupt Assignments ............. 75 Table B.6:Interrupt assignments ........75 1st MB Memory Map............
  • Page 9 Hardware Configuration...

  • Page 10: Chapter 1 Hardware Configuration

    The new MIC-3358 has been optimized for the Intel® Pentium® 4 Pro- cessor-M and Intel® 845E Chipset. It unveils as a high performance cPCI platforms, delivering compelling system bus speed performance across the 400 MHz with Intel NetBurst™...

  • Page 11: Specifications

    Complete I/O Functions The MIC-3358 offers all the I/O functions of an industrial computer with the rugged Eurocard form factor. The rest of I/O have fully connected to the rear I/O module via user-define connector (J3 and J5) on the back- plane.
  • Page 12 • Controller chips: Two Intel® 82540EM Gigabit Ethernet controller chips provides Dual Gigabit ports • One front RJ-45 Gigabit LAN port • 10 Mbps, 100 Mbps and 1000Mbps auto-switching PCI VGA Interface • Controller: ATI Rage XL • PCI 2.2 compliant, 32bit/33 MHz MIC-3358 User’s Manual...

  • Page 13: Mechanical And Environmental Specifications

    1280x1024 Optional Rear I/O Boards • RIO-3309C NOTE: MIC-3358 does not support MIC-3960 storage carrier board Mechanical and Environmental Specifications • Operating temperature: 0 ~ 55° C (32 ~ 131° F) • Storage Temperature: -20 ~ 80° C (-4 ~ 176° F) •...

  • Page 14: Functional Block Diagram

    1.3 Functional Block Diagram Figure 1.1: MIC-3358 functional block diagram. Note: MIC-3358 does not support shutdown function of ATX power supply. 1.4 Jumpers 1.4.1 Jumper Locations Table 1-1 lists the jumper function. Figure 1-1 illustrates the jumper loca- tion. Read this section carefully before changing the jump setting on your MIC-3358 card.

  • Page 15: Clear Cmos (Jp4)

    Table 1.2: JP1 jumper definition (PMC Module Voltage V(i/o)) 3.3V (Default) Table 1.3: JP2 jumper definitions (PMC Module Voltage Vio) VGA output in Rear IO VGA output in front panel of MIC-3358 Table 1.4: JP7 jumper definitions (CompactFlash™ card) Master Slave (default) 1.4.2 Clear CMOS (JP4)

  • Page 16: Table 1.5:Clear Cmos Jp4

    Table 1-6 lists the function of each con- nector and Figure 1-1 and Figure 1-2 illustrate each connector location. Chapter 2 gives instructions for connecting external devices to your card. Table 1.6: MIC-3358 connector descriptions Number Function 2.5"...

  • Page 17: Table 1.7:Cn1 Ide Connector Definitions

    Table 1.7: CN1 IDE Connector Definitions Signal Signal PRST# PID7 PID8 PID6 PID9 PID5 PID10 PID4 PID11 PID3 PID12 PID2 PID13 PID1 PID14 PID0 PID15 PDRQ# PIOW# PIOR# PRDY CSEL* PACK# PIRQ PDA1 PDIAG#** PDA0 PDA2 PCS1# PCS3# HDD_LED #: active low *: CSEL connected to GND **: PDIAG# has 10K ohm pull-down to GND Chapter 1...

  • Page 18: Table 1.8:Cn2 Compactflash™ Socket Definitions

    Table 1.8: CN2 CompactFlash™ Socket Definitions Signal Signal ID11 ID12 ID13 ID14 ID15 HCS1- HCS3- HIOR- HIOW- HIRQ SANDISK -HRST1 HRDY GDA2 HDA1 HDA0 SANLED ID10 MIC-3358 User’s Manual...

  • Page 19: Table 1.9:Cn3 Rj-45 Com1 Port Definitions

    Table 1.9: CN3 RJ-45 COM1 port Definitions Signal NRLSD1 NRX1 NTX1 NDTR1 NDSR1 NRTS1 NCTS1 Chapter 1...

  • Page 20: Table 1.10:Cn4 Handle Switch Definitions

    Note: Pin 1-2 handle closed Pin 1-3 handle open 2 1 2 1 Battery 63 64 63 64 44 43 15,10,5 11,6,1 Intel 845E PCI-PCIX Bridge Note: Handle closed is normal Figure 1.2: Handle Switch Definitions MIC-3358 User’s Manual...

  • Page 21: Table 1.11:Cn5 Usb 1.1/2.0 Port Definitions

    Table 1.11: CN5 USB 1.1/2.0 port Definitions Signal USB_P2- USB_P2+ Table 1.12: CN6 USB 1.1/2.0 port Definitions Signal USB_P2- USB_P2+ Chapter 1...

  • Page 22: Table 1.13:Cn9 Db-15 Vga Connector Definitions

    Table 1.13: CN9 DB-15 VGA Connector Definitions Signal GREEN BLUE N/C (VGAVCC) VGA_SDA HSYNC VSYNC VGA_SCL Table 1.14: PU1 Gigabit LAN Connector Definitions Signal MDIAX1+ MDIAX1- MIC-3358 User’s Manual...

  • Page 23: Table 1.15:J11/J12/J14 Pmc Connector Definitions

    MDIAX2+ MDIAX3+ MDIAX3- MDIAX2- MDIAX4+ MDIAX4- The LED indicator means Left Right 10Mbps flick active/link mode 100Mbps Green 1000Mbps Orange Table 1.15: J11/J12/J14 PMC Connector Definitions J11 PIN SIGNAL PIN# Single Name PIN# Single Name -12V INTC# INTD# INTA# BUSMODE1 INTB# GNT4# REQ4#...
  • Page 24 AD11 C/BE0# V(I/O) REQ64# J12 PIN SIGNAL PIN# Single Name PIN# Single Name +12V TRST# BUSMODE2# +3.3V RST# BUSMODE3# +3.3V BUSMODE4# AD30 AD29 AD26 AD24 +3.3V IDSEL(AD19) AD23 +3.3V AD20 AD18 AD16 C/BE2# TRDY# +3.3V STOP# PERR# MIC-3358 User’s Manual...
  • Page 25 +3.3V SERR# C/BE1# AD14 AD13 AD10 +3.3V +3.3V ACK64# +3.3V J14 Pin Signal PIN# Single Name PIN# Single Name +5Vaux +5Vaux BMC_PWR_ON/OFF BMC_PWROK PMC_OS_SHUTDOWN BMC_BD_SEL# Chapter 1...

  • Page 26: Table 1.16:D9 Led Definitions

    CMM1_SCL CMM1_SDA CMM2_SCL CMM2_SDA BMC_BD_SEL BMC_LEDA BMC_LEDL BMC_TX+ BMC_RX+ BMC_TX- BMC_RX- Table 1.16: D9 LED Definitions Green Power Status Yellow HDD Status Table 1.17: SW1 Vcore selection definitions MIC-3358 User’s Manual...

  • Page 27: Table 1.18:Sw2 Drone Mode Definitions

    It's automatic selection when SW1-1~SW1-6 are all OFF. SW1- 6 SW1- 5 SW1- 4 SW1- 3 SW1- 2 SW1- 1 VCORE AUTO 1.750V 1.700V 1.650V 1.600V 1.550V 1.500V 1.450V 1.400V 1.350V 1.300V 1.250V 1.200V 1.150V 1.100V 1.050V 1.000V 0.975V 0.950V 0.925V 0.900V PS: X means either ON or OFF.

  • Page 28: Figure 1.3:Mic-3358 Jumper And Connector Locations

    Please refer to Appendix B for J1/2/3/5 pin assignments. 2 1 2 1 Battery 63 64 63 64 44 43 15,10,5 11,6,1 Intel 845E PCI-PCIX Bridge Figure 1.3: MIC-3358 jumper and connector locations. MIC-3358 User’s Manual...

  • Page 29: Safety Precautions

    Figure 1.4: MIC-3358 front panel connector and indicator locations 1.6 Safety Precautions Follow these simple precautions to protect yourself from harm and the products from damage. Chapter 1...

  • Page 30: Installing Cpu And Heat Sink

    1.7 Installing CPU and Heat Sink The MIC-3358 supports Intel® Pentium® 4 processor - M . In order to meet critical environmental conditions and the physical space of the MIC-3358 at the same time, Advantech designed a heat sink to fulfill its primary needs.

  • Page 31: Figure 1.5:Complete Assembly With Heat Sink And Hard Disk

    Figure 1.5: Complete assembly with heat sink and hard disk 1.8 Software support The MIC-3358 comes with a utility CD-ROM disc, which includes driv- ers and utility programs of Gigabit Ethernet, IAA and VGA interfaces. The drivers support Windows 2000, XP and NT4.0 Operation systems.
  • Page 32 MIC-3358 User’s Manual...
  • Page 33 Connecting Peripherals...

  • Page 34: Chapter 2 Connecting Peripherals

    2.1 IDE Device (CN1 and Rear I/O) The MIC-3358 provides two IDE (Integrated Device Electronics) chan- nels via CN1 connector in MIC-3358 or via the J3 connector to the rear transition board (RIO-3309C). CN1 connector support one 2.5" IDE HDD in MIC-3358 and two IDE drives can be connected to Secondary IDE connector (CN19) in the rear transition board.

  • Page 35: Serial Ports (Cn3 And Rear I/O)

    10/100/1000Base-TX specifications. Users can select front GbE or rear GbE or 2.16 by BIOS. Users can choice LAN1 connector either via front RJ-45 jack (PU1) in MIC-3358 or rear RJ-45 (CN16) in rear module. Another one Gigabit LAN connector (CN15) has to go through RIO mod- ule (RIO-3309C).

  • Page 36: Usb Connector (Cn5/6 And Rear I/O)

    2.6 USB Connector (CN5/6 and Rear I/O) The MIC-3358 provides two USB (Universal Serial Bus) 2.0 channels either via two front USB ports (CN5 and CN6) in MIC-3358 or via J5 connector to one USB connector (CN8) in real transition board. The USB interface gives complete plug and play, hot attach/detach for up to 127 external devices.
  • Page 37 MIC-3358 help you install and remove the card easily and safely. Fol- low the procedure below to install the MIC-3358 into a chassis: To install a card: 1. Hold the card vertically. Be sure that the card is pointing in the correct direction.
  • Page 38 MIC-3358 User’s Manual...
  • Page 39 Driver Setup...

  • Page 40: Chapter 3

    Microsoft. While users installed Intel INF driver, it will not install USB driver. Please go to "device man- ager" to update USB driver via Advantech CD utility or via Microsoft website. Note: There are no separate USB (version 1.1 and earlier) drivers available for download for Intel®...

  • Page 41: Cmm (Chassis Management Module) Driver

    3.3 CMM (Chassis Management Module) Driver MIC-3358 supports MIC-3924B CMM. Please install driver as following procedure. 3.3.1 Windows 2K Driver Figure 3.1: Right Click "My Computer" and click "Properties" Figure 3.2: Tab "Hardware" and click "Hardware Wizard" Chapter 3...

  • Page 42: Figure 3.3:Click "Next" In Hardware Wizard

    Figure 3.3: click "Next" in Hardware Wizard Figure 3.4: click" Add/Troubleshoot a device" MIC-3358 User’s Manual...

  • Page 43: List

    Figure 3.5: select " Add a new device" in Device windows Figure 3.6: click "No, I want to select the hardware from a list" Chapter 3...

  • Page 44: Figure 3.8:Tab " Have Disk" In Right Bottom

    Figure 3.7: Select "Other devices" in Hardware types windows Figure 3.8: Tab " Have Disk" in right bottom MIC-3358 User’s Manual...

  • Page 45: Figure 3.9:Browse Proper Driver In Cd Rom Device

    Figure 3.9: Browse proper driver in CD ROM device Figure 3.10: click ok in the Wizard windows Chapter 3...
  • Page 46 Figure 3.11: click "ok" in Add New Hardware Wizard Properties" windows Figure 3.12: click "yes" in Creating a Forced Configuration windows MIC-3358 User’s Manual...
  • Page 47 Figure 3.13: click "Next" in Add/Remove Hardware Wizard windows Figure 3.14: Tab "Finish" in Add/Remove Hardware Wizard windows Chapter 3...
  • Page 48 Figure 3.15: click "Yes" to restart your computer Figure 3.16: Go to Device Manager to see available A-IPM drivers MIC-3358 User’s Manual...

  • Page 49: Windows Xp Driver

    3.3.2 Windows XP Driver Figure 3.17: Right click My Computer to select "Properties" Figure 3.18: Tab "Hardware" and click "Add Hardware Wizard" Chapter 3...

  • Page 50: Figure 3.19:Click "Next" In The Windows

    Figure 3.19: Click "Next" in the windows Figure 3.20: Click "Yes , I have already connected the hardware" MIC-3358 User’s Manual...
  • Page 51 Figure 3.21: Select "Add a new hardware device" in the installed hardware window Figure 3.22: Click Install the hardware that I manually select from a list (Advanced) Chapter 3...
  • Page 52 Figure 3.23: Select "Show all devices" in Common hardware types windows Figure 3.24: tab "Have Disk" MIC-3358 User’s Manual...

  • Page 53: Figure 3.25:Select Proper Driver In Cd-Rom

    Figure 3.25: Select proper driver in CD-ROM Figure 3.26: tab A-IPM driver and click "Have Disk" Chapter 3...

  • Page 54: Figure 3.27:Click " Next

    Figure 3.27: Click " Next" Figure 3.28: Click "Finish" MIC-3358 User’s Manual...
  • Page 55 Figure 3.29: Go to My computer to see "A-IPM drivers" Chapter 3...
  • Page 56 MIC-3358 User’s Manual...
  • Page 57 Award BIOS Setup...

  • Page 58: Chapter 4 Award Bios Setup

    Turn on the computer and check for the "patch code". If there is a number assigned to the patch code, it means that the BIOS support your CPU. If there is no number assigned to the patch code, please contact Advantech's application engineer to obtain an up-to-date patch code file. This will ensure that your CPU's system status is valid.

  • Page 59: Standard Cmos Setup

    4.1.2 Standard CMOS Setup The items in Standard CMOS Setup Menu are divided into 11 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item.

  • Page 60: Figure 4.3:Advance Bios Features Setup Screen

    This category speeds up Power On Self Test (POST) after you power on the computer. If this is set to Enabled, BIOS will shorten or skip some check items during POST. Enabled (default) Enable quick POST Disabled Normal POST MIC-3358 User’s Manual...
  • Page 61 First/Second/Third Boot Device and Boot Other Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. The settings are Floppy, LS120, HDD- 0, SCSI, CDROM, HDD-1, HDD-2, HDD-3, ZIP100, USB-FDD, USB- ZIP, USB-CDROM, USB-HDD, LAN and Disabled.

  • Page 62: Security Option

    The options includes 1.1 and 1.4. Default is 1.4 OS Select For DRAM > 64MB Allows OS2® to be used with > 64 MB of DRAM. Settings are Non-OS/ 2 (default) and OS2. Set to OS/2 if using more than 64MB and running OS/2®. MIC-3358 User’s Manual...

  • Page 63: Advance Chipset Features Setup

    Small logo (EPA) show Default is Disabled. 4.1.4 Advance Chipset Features Setup The Advanced Chipset Features Setup option is used to change the values of the chipset registers. These registers control most of the system options in the computer. Choose the "ADVANCED CHIPSET FEATURES" from the Main Menu and the following screen will appear.

  • Page 64: Dram Data Integrity Mode

    You can reserve this area of system memory for ISA adapter ROM. When this area is reserved, it cannot be cached. The user information of periph- erals that need to use this area of system memory usually discusses their memory requirements. The settings are: Enabled and Disabled (Default). MIC-3358 User’s Manual...

  • Page 65: Integrated Peripherals

    Delayed Transaction The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI spec- ification version 2.1. The settings are: Enabled (Default) and Disabled. 4.1.5 Integrated Peripherals Figure 4.5: Integrated Peripherals setup screen Chapter 4...
  • Page 66 Select Enabled if you use USB KB/Mouse in DOS mode. Init Display First User can choose display priority on either peripheral PCI slot or on board VGA chip. There are 2 options: PCI slot (Default) and On board. MIC-3358 User’s Manual...
  • Page 67 SMBus Connector Users can select IPMI source and application as below. Source connected CMM PCF8584T MIC-3924B Hardware Monitor 83782D MIC-3924A BMC (PMC type) (Reserved) CMM (Reserved) There are 3 options: MIC-3924B (Default), MIC-3924A and CMM. LAN 1 Connector The item allows you to choice LAN1 connective way. There are 3 options: Front (Default), 2.16 and Rear LAN 2 Connector The item allows you to choice LAN2 connective way.

  • Page 68: Power Management Setup

    4.1.6 Power Management Setup The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. Figure 4.6: Power management setup screen MIC-3358 User’s Manual...

  • Page 69: Pnp/Pci Configuration Setup

    ACPI Function This category allows you to select ACPI power management effective or not. The options: Enabled (Default) and Disabled. 4.1.7 PNP/PCI Configuration Setup This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components.

  • Page 70: Pc Health Status

    Figure 4.8: PC Health setup screen Current CPU Temp./ Vcpu-core/Vtt/+3.3V/+5V/+12V/-12V/VBAT This show system health status. 4.1.9 Load Optimized Defaults When you press <Enter> on this item, you get a confirmation dialog box with a message similar to: MIC-3358 User’s Manual...

  • Page 71: Set Password

    Load Optimized Defaults (Y/N) ? N Pressing 'Y' loads the default values that are factory settings for optimal performance system operations. 4.1.10 Set Password To change, confirm, or disable the password, choose the "PASS-WORD SETTING" option form the Setup main menu and press [Enter]. The password can be at most 8 characters long.
  • Page 72 MIC-3358 User’s Manual...
  • Page 73 Programming the Watchdog Timer...

  • Page 74: Programming The Watchdog Timer

    Appendix A A.1 Programming the Watchdog Timer To program the watchdog timer, you must write a program which writes a value to I/O port address 443 (hex). This output value represents time interval. The value range is from 01 (hex) to FF (hex), and the related time interval is 1 sec.
  • Page 75 1070 RETURN 2000 REM Subroutine #2, your application task • • • 2090 RETURN. Chapter A...
  • Page 76 MIC-3369 User’s Manual...
  • Page 77 Pin Assignments...

  • Page 78: B.1 J1 Connector

    C/BE[2]# AD[21] +3.3V AD[20] AD[19] C/BE[3]# AD[23] AD[22] AD[26] V(I/O) AD[25] AD[24] AD[30] AD[29] AD[28] AD[27] REQ0# +3.3V CLK0 AD[31] RST# GNT0# IPMB_PWR Healthy# V(I/O) INTP INTS INTA# INTB# INTC# INTD# -12V TRST# +12V #: Low active MIC-3358 User’s Manual...

  • Page 79: J2 Connector

    B.2 J2 Connector Table B.2: J2 connector CLK6 CLK5 RSV (SMBB_SDA) RSV (SMBB_SCL) PRST# REQ6# GNT6# REQ5# GNT5# AD[35] AD[34] AD[33] AD[32] AD[38] V(I/O) AD[37] AD[36] AD[42] AD[41] AD[40] AD[39] AD[45] V(I/O) AD[44] AD[43] AD[49] AD[48] AD[47] AD[46] AD[52] V(I/O) AD[51] AD[50] AD[56]...

  • Page 80: J3 Connector

    FD_WGATE# FD_HDSEL# FD_DS0# GND PE SLCT FD_STEP# FD_MTR0# FD_WDATA# GND ERR- ACK- FD_RDATA# FD_WRTPRT# FD_TRK0# GND STB- AFD- FD_DRVEN0 FD_INDEX# FD_DSKCHG# GND GND LPTD5 LPTD6 LPTD7 BUSY FD_DRVEN1 GND LPTD0 LPTD1 LPTD2 LPTD3 LPTD4 #: Low active MIC-3358 User’s Manual...

  • Page 81: J5 Connector

    B.4 J5 Connector Table B.4: J5 connector GND ICH_RX+ ICH_RX- ICH_TX+ ICH_TX- GND BMC_RX+ BMC_RX- BMC_TX+ BMC_TX- GND GND USBD1- GND USBD0- USBD1+ VGA_RED GND USBD0+ VGA-H GND GND RIO_REQ7# VGA_GRE GND USB_OC0# RIO_GNT7# VGA-V GND USB_OC1# RIOINSTALL# RIO_HW_SW VGA_BLUE GND GND NRLSD1 NRI1 RIO_HW_LED...

  • Page 82: System I/O Ports

    ATI Technologies Inc. Rage XL PCI 3F0-3F5 Standard floppy disk controller 3F6-3F6 Primary IDE channel 3F7-3F7 Standard floppy disk controller 3F8-3FF Communication port (COM1) 447-44A A-IPM driver 4D0-4D1 Motherboard resources 800-87F Motherboard resources A79-A79 ISAPNP read data port 0D00-FFFF PCI bus MIC-3358 User’s Manual...

  • Page 83: Interrupt Assignments

    4000-40BF Motherboard resources 5000-501F Intel® 82801DB/DBM SMBus controller -24C3 C000-C0FF ATI Technologies Inc. Rage XL PCI C400-C43F Intel® 82540EM based network connection #2 C800-C83F Intel® 82540EM based network connection CC00-CC3F Intel® PRO/100 VE network connection D000-D01F Intel® 82801DB/DBM USB universal host controller - 24C4 D400-D41F Intel®...
  • Page 84 MIC-3358 User’s Manual...
