Furuno FELCOM 82A Series Installation Manual page 52

4.4.2 Setting procedure
1) Type of gyrocompass
Gyrocompass
type
AC
synchronous
DC
synchronous
DC step
Full-wave
pulsating current
Half-wave
pulsating current
3) Rotor Voltage (between R1 & R2)
Rotor Voltage
20 to 45 VAC
30 to 70 VAC
40 to 90 VAC
60 to 135 VAC
SW SW SW
1-4 1-5 1-6
OFF OFF OFF
OFF OFF OFF
ON OFF OFF
OFF ON 0FF
ON ON OFF
SW
JP3
2-1
ON #2
OFF #2
ON #1
OFF #1
2) Frequency
JP1 Frequency
#1, #2,
50/60 Hz
#3
#2, #3,
400 Hz
#4
#4, #5,
500 Hz
#6
#4, #5,
DC
#6
#4, #5,
#6
4) Stator Voltage (between S1 & S2)
Stator
Voltage
20 to 45 VAC, or
20 to 60 VDC
30 to 70 VAC, or
40 to 100 VDC
40 to 90 VAC
60 to 135 VAC
44
Remarks
SW SW
1-7 1-8
AC synchronous
pulsating current
OFF OFF
AC synchronous
ON OFF
pulsating current
AC synchronous
OFF ON
pulsating current
DC synchronous
ON ON
DC step
JP2
SW SW
2-2 2-3
ON OFF #2
OFF OFF
#2
#1
ON OFF
#1
OFF OFF
