4.4 Setting of Gyro Converter
The AD Converter Board in the Communication Unit accommodate various brands and
specifications of gyrocompasses by means of DIP switches and jumper wires. Below are
the specifications of the gyrocompass it can accommodate. For the location of DIP switch
and jumper settings for various brands of gyrocompass, see page 46.
AC synchro
• Frequency
:
• Rotor Voltage :
• Stator Voltage :
• Gear Ratio
:
DC synchro
• Rotor Voltage :
• Stator Voltage :
• Gear Ratio
:
AD Converter Board
64P1106
Communication Unit, top view (cover removed)
50/60 Hz
400 Hz
(
) VAC
(
) VAC
360x
180x
90x
(
) VDC
(
) VDC
360x
180x
90x
500 Hz
36x
36x
42
