1.1.3 Mounting
4 Radome
2 Protective
Material
1 Eye Bolt
Antenna Bottom
Note2: Do not use a rubber gasket on the mounting base. The face of the mounting base
should be flat as possible (tolerance: within 2 mm of the horizontal plane).
If tolerance is more than 2 mm, insert a metal spacer between the antenna bottom
and the mounting base. For earth wiring, see Chapter 2.
Unpacking, visual inspection
Carefully unpack the radome and
check for damage.
Procedure
1. Run lifting rope through eye bolts
2. Cover the portion of the radome
3. Hoist the antenna unit to the
Lifting Rope
(Can be 4. Fix the antenna unit to the
supplied
together with
snackles.)
Flat Washer
Spring Washer
Shackle
Eye Bolt
5. If necessary, replace eye bolts
Note1: Coat all bolts and nuts with
silicone sealant to prevent electrolytic
Mounting Base
corrosion.
7
and shackles.
which contacts the lifting rope with
protective material (rubber mat,
etc.), to prevent damage to the
radome when hoisting it to the
mounting location.
mounting location.
mounting base (see note below)
with nuts, keeping in mind hatch
direction (standard direction is
stern).
Coat here with
silicone sealant.
FIXING OF RADOME
with hex. bolts (supplied).
Mounting Base
10 mm Nut
13 mm Nut
