2.8 Gyrocompass
Connect the gyrocompass to the GYRO port at the rear of the communication unit by using
NJC-207-PF connector (supplied as installation material for communication unit) and
MPYC-5 cable (Japan Industrial Standard (JIS) cable or equivalent).
NJC-207-PF
gyrocompass
(Synchro)
F.GND
Conductor
2
S =1.25 mm
=1.35 mm
(Sectional view)
Fabrication of MPYC-5
GYRO
S1
1
S1
S2
2
S2
S3
3
S3
4
T
R2
5
R2
R1
6
R1/COM
7
F.GND
Gyrocompass connection
Tape
Armor
Vinyl sheath
Painting
3
25
gyrocompass
(Step-by-step)
29
NJC-207-PF
GYRO
S1
1
S1
S2
2
S2
S3
3
S3
4
T
*
5
R2
COM
6
R1/COM
F.GND
7
F.GND
*: when five lines
