The ReadyDATA 5200 confirms the creation of a LUN with the message "Data Set
successfully created." The new LUN is added to the Shares screen. Basic information is
displayed to the right of the LUN.
View and Change the Properties of a LUN, Including Size
Expansion

To view and change the properties of a LUN:
1. Select Shares.
2. Click the Data Set button (with four cubes,
The Shares screen displays (see the figure in
3. Select the LUN that you want to explore by clicking it.
The color of the LUN turns purple.
4. Right-click the LUN.
A pop-up menu displays:
5. Select Properties.
The Properties pane for the selected LUN displays at the right of the screen (see the next
figure).
ReadyDATA OS 1.2
Step
Manage Shares and LUNs
95
).
4).
