UPS Devices Managed Over a Remote Connection
A remote UPS is attached to a remote server, such as a ReadyNAS or a Linux server that is
running Network UPS Tools (NUT). The ReadyDATA 5200 monitors and manages the UPS
over the remote connection. The Ethernet connection between the UPS and the ReadyDATA
5200 passes through a switch.
The following figures show scenarios that include a UPS that is managed over a remote
connection. Although dual power supplies and dual UPS devices are not shown in these
figures, for full power protection, each power supply should be connected to a UPS.
ReadyDATA 5200
Linux NUT server
Figure 11. ReadyDATA 5200 with a UPS managed remotely over a Linux NUT server
ReadyDATA OS 1.2
UPS power input
System Maintenance and Monitoring
152
Switch
Remote UPS
Network
Ethernet
Power
USB
