NETGEAR ReadyDATA 5200 Software Manual page 22

For example, a RAID 6 set that has been expanded twice by the addition of two RAID
groups goes from RAID 6+ to RAID 6+0, 2x, and then to RAID 6+0, 3x.
- An expanded RAID 10 set is indicated in the same way as a new RAID 10 set:
RAID 1+0.
The following table explains the RAID nomenclature. The sequential expansion number is
indicated by n, and x just indicates times (for example, 2x is two times).
Table 3. RAID nomenclature on the ReadyDATA 5200
RAID Level New RAID
RAID 0 RAID 0+
RAID 1 RAID 1+
RAID 5 RAID 5+
RAID 6 RAID 6+
RAID 10 RAID 1+0
ReadyDATA OS 1.2
Expanded RAID
RAID 0+
RAID 1+0, nx
RAID 5+0, nx
RAID 6+0, nx
RAID 1+0
Manage Disks and Volumes
22
