Figure 23: Bios Advanced Menu - H/W Monitor - Quanmax QBOX-100P Series User Manual

Figure 23: BIOS Advanced Menu - H/W Monitor

Main Advanced
PC Health Status
CPU Temperature
System Temperature
CPU Fan Speed
+VCORE
+VIN
+3VCC
+3VSB
+VBAT
+5VA
+3VA
BIOS SETUP UTILITY
Power
: +37 C
: +37 C
: N/A
: +0.912 V
: +12.096 V
: +3.328 V
: +3.344 V
: +3.216 V
: +5.064 V
: +3.280 V
Version 2.18.1263. Copyright (C) 2019, American Megatrends, Inc.
QBOX-100P Series - User Guide, Rev. 1.0
Boot Security
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Save & Exit
// 56
