Make sure that DIN rail mounting clamp is in the upright position.
3.
Clip the top of the DIN rail clamp into the DIN rail and push the bottom of the DIN rail firmly until it clamps onto
the bottom of the DIN rail.
Figure 10: Clamping the QBOX-100P Series onto the DIN rail
For a sufficient air circulation around the device, we recommend keep a proper
clearance and not mount / operate any other devices within the clearance around the
QBOX-100P Series.
QBOX-100P Series - User Guide, Rev. 1.0
// 32
