Mechanical Drawing; Figure 12: Mechanical Drawing - Quanmax QBOX-100P Series User Manual

Hide thumbs
Table of Contents

Advertisement

Construction
Dimensions (W x D x H)
Weight
Mounting

10.1.1. Mechanical Drawing

Figure 12: Mechanical Drawing

Metal Chassis
145 mm x 94 mm x 60 mm / 5.71" x 3.70" x 2.36"
700 g / 1.54 lb
DIN Rail Mount
QBOX-100P Series - User Guide, Rev. 1.0
(unit: mm)
// 39
