5.6 All-in-One 'Vented' tap
HydroTap
Mixer
Connections
MAINS
MIXER
IN
OUT
Clearance
envelope
50mm
Note Neither the braided hoses or the tubes supplied with the tap, booster and ext. filter can be lengthened.
Take time to consider hose lengths when determining the mounting positions for the different options, also
ensure that the chilled and sparkling pipes are covered with the insulation provided.
Page 32 of 40
Installation instructions
MIXER
BOILING
BYPASS
IN
OUT
OUT
280mm
802005UK - Residential (Boiling),chilled and sparkling installation instructions - Aug 2015 - v2.01
Booster
Connections
VENT BYPASS
IN
CHILLED
OUT
Note Mains hose length is 750mm.
Electrical power cable length is 1800mm.
Position the Command-Centre
hose and cable lengths supplied.
(Supplied)
Note All plastic / silicon tubes must be trimmed to
size. They must have a constant fall to the
50mm
External cold isolation valve
(not supplied)
POWER
USB
CABLE
SPARKLING
CO2
OUT
IN
according to the
TM
Command-Centre
.
TM
Male to male adaptor
to T-Piece
(supplied)
T-Piece & Restrictaflow
(supplied)
