1.18 Base block spider markings and silicone tube positions
underneath).
Installing the All-in-One 'Vented' tap
1.19 All-in-One 'Vented' connections.
• Connect the red and clear silicone tubes & USB
cable to the Command-Centre
• Connect the blue and white plastic pipe supplied
to the Y connector in place on the end of the blue
silicone tube, then connect to the Command-
Centre
as shown.
TM
• Working from inside the cupboard, attach the
braided hoses to the tube extensions (ensure the
seals on the end of the hoses are lubricated).
Check the correct position for mixer and ambient
connections by matching the colours on the
braided hoses with the coloured markings on the
extension tubes. (See adjacent diagram).
• Connect the braided hose with the blue marking to
the 'MIXER IN' on the Command-Centre
• Connect the braided hose with the white marking
to the Restrictaflow.
•
Connect the braided hose with the red marking
to the metal tube, with red marking then to the
'MIXER OUT' on the Command-Centre
• Ensure that all tubes and
hoses are firmly secured.
HydroTap
Mixer
Connections
MAINS
MIXER
IN
OUT
Page 20 of 40
Installation instructions
White marking
Braided hose with
white marking
Red silicone tube
Clear silicone tube
as shown.
TM
.
TM
.
TM
MIXER
BOILING
BYPASS
IN
OUT
OUT
802005UK - Residential (Boiling),chilled and sparkling installation instructions - Aug 2015 - v2.01
(see page 32 for Command-Centre
Braided hose with
white marking -
Restrictaflow on
ambient supply
Braided hose
connection to metal
tube - 'MIXER
OUT' on Command-
Centre
.
TM
Clear silicone
tube - VENT on
Command-Centre
Red silicone tube -
BOILING OUT on
Command-Centre
Booster
Connections
VENT BYPASS
CHILLED
IN
OUT
Blue marking
Braided hose with
blue marking
Braided hose with
red marking
Blue silicone tube
USB cable
installation).
TM
TM
TM
USB
CO2
SPARKLING
IN
OUT
(viewed from
Braided hose with
blue marking - to
MIXER IN'
on Command-
Centre
TM
Blue silicone tube Y
connector
blue plastic pipe to-
STILL OUT
white plastic pipe to-
SPARKLING OUT
on the
Command-Centre
TM
POWER
CABLE
