Zip HydroTap G4 Boiling, chilled sparkling Command-Centre Installation Instructions Manual page 18

(see page 31 for Command-Centre
1.14 Base block spider markings and silicone tube positions
underneath).
Installing the All-in-One 'Mains' tap
1.15 All-in-One 'Mains' connections
• Connect the red and clear silicone tubes & USB
cable to the Command-Centre
• Connect the blue and white plastic pipe supplied
to the Y connector in place on the end of the blue
silicone tube, then connect to the Command-
Centre as shown.
TM
• Working from inside the cupboard, attach the
braided hoses to the tube extensions (ensure the
seals on the end of the hoses are lubricated).
Check the correct position for hot and ambient
connections by matching the colours on the
braided hoses with the coloured markings on the
copper extension tubes. (See adjacent diagram).
• The braided hose with the blue markings must be
connected to the ambient mains supply.
• The braided hose with the red markings must be
connected to the hot mains supply.
• Do not over tighten the braided hoses.
• Ensure that all tubes and hoses are firmly
secured.
MAINS MIXER
IN OUT
Page 18 of 40
Installation instructions
connections)
TM
Blue marking
Braided hose with
blue marking
Red silicone tube
Clear silicone tube
as shown.
TM
MIXER BOILING BYPASS
IN OUT OUT
802005UK - Residential (Boiling),chilled and sparkling installation instructions - Aug 2015 - v2.01
Braided hose with blue
marking - ambient
domestic supply.
Clear silicone
tube - VENT on
Command-Centre
TM
Red silicone tube -
BOILING OUT on
Command-Centre
TM
VENT BYPASS
CHILLED
IN
OUT
(viewed from
Red marking
Braided hose with
red marking
Blue silicone tube
USB cable
Braided hose
with red marking
- hot domestic
supply.
Blue silicone tube
Y connector
blue plastic pipe to-
STILL OUT
white plastic pipe to-
SPARKLING OUT
on the
Command-Centre
USB
POWER
CO2 SPARKLING
CABLE
IN OUT
TM
